Somfy RTS Motor Programming Instructions
Motor Programming Instructions have been rewritten by
https://www.AVOutlet.com
We rewrite the Somfy instructions in an effort to make things a little easier to follow. There are
however some subtle differences in the motors. Please refer to the included Somfy motor
specific instructions if something is not working. Feel free to let us know if something is found to
be incorrect.
Please Read and Follow These Instructions.
Please use the motor programming instructions provided here. The remote control
instructions can be used for reference but they are not as easy to follow. A copy of the
Somfy instructions are also provided for your reference.
Please read installation instructions and programming instructions completely prior to
proceeding with installation and programming. Failure to do so can result in damage to the
motor and or the shade.
Be prepared to stop the shade during programming. The programming step where you set the
first stop limit (upper or lower whichever you do first) will activate the motor to move without
stopping on its own. You will need to stop the motor at the next stop limit using the remote as
indicated. Failure to stop the shade can result in shade or motor damage.
The motors MUST be installed in the tube and the assembly must be mounted into brackets to
be able to program the motor.
Only apply power to the motor being programmed regardless if the other motors have been
programmed or not. This will prevent inadvertent interaction with other motors. This is not
possible for motors with built-in batteries like the R28WF, ST30WF etc. Motors with built-in
batteries must be put to sleep.
We recommend mapping out the installation before proceeding. This will reduce set-up time and
make life easier. Decide the channels and or additional remotes to be assigned to each shade
in the installation. Each shade should be completely programmed before moving to the next.
Have the necessary remotes and controls ready prior to proceeding.
All motors programmed to the same RTS channel will operate at the same time. If you want
individual control of the motor, you must use separate channels on multi-channel remotes or
separate single channel remotes
The remote controls are generally considered to be dummy devices as they do not store any
motor or programming information. The motors are the intelligent devices. The motors store the
shade operation limits in their memory and the motors also memorize the specific remotes or
channels assigned to control them. Each motor can have up to 12 remotes or channels
controlling them.
th
Note: The Telis 4 Remote Control is a 5 Channel Remote control. The 5
channel is all lights
th
on. The 5
channel by default is not a group channel. This channel is not automatically
assigned and must be programmed.

Advertisement

loading
Need help?

Need help?

Do you have a question about the Sonesse 30 RTS and is the answer not in the manual?

Questions and answers

Summary of Contents for SOMFY Sonesse 30 RTS

  • Page 1 Motor Programming Instructions have been rewritten by https://www.AVOutlet.com We rewrite the Somfy instructions in an effort to make things a little easier to follow. There are however some subtle differences in the motors. Please refer to the included Somfy motor specific instructions if something is not working.
  • Page 2 Please read the previous page before proceeding. Step 1 - Assign a RTS Channel to the Motor 1-A) Select the RTS remote control and channel you want to use. 1-B) Press and Hold both the UP and DOWN buttons simultaneously until the motor jogs, then release.
  • Page 3 Optional Programming Tasks These procedures can be done at any time after initial programming, but we do recommend performing all desired additional tasks before moving onto the next shade. All shades not being programmed should have the power disconnected be put to sleep. Set the Customer Preferred MY Intermediate Position 1) Using the remote, position the shade to the location you would like as your intermediate customer preferred position...
  • Page 4 Adjusting the Upper Limit 1) Move the shade to its current upper limit position and let it stop. 2) Press and Hold the UP and DOWN buttons simultaneously until the motor jogs, then release. A jog is a movement in both directions. 3) Adjust to a new upper limit position.
  • Page 5 1) Disconnect power for 2 seconds. 2) Connect power for 5 seconds. Note: Somfy recommends 10-15 seconds but we found 5 seconds to work better. 3) Disconnect power for 2 Seconds 4) Connect power and then leave it on. The motor will rotate in one direction if the shade is between limits or will jog if at one of the programmed stops.
  • Page 6 Intentionally blank...
  • Page 7 ® Sonesse 30 RTS www.AVOutlet.com...
  • Page 8: General Safety Instruction

    • Any use outside the sphere of application specified by Somfy is not approved. Such use, or any failure to comply with the instructions given herein will invalidate the warranty, and Somfy refuses to accept liability.
  • Page 9: Installation

    1) Mount the motorized tube on the end bracket (c). 2) Mount the motorized tube on the motor bracket (d). Wiring Connect the power cable to the motor. Copyright © 2008 Somfy SAS. All rights reserved - V0 - 10/2008 www.AVOutlet.com...
  • Page 10 Recording the RTS control point Press the programming button on the back of the RTS control point until the motor jogs. The RTS control point address is permanently recorded. Copyright © 2008 Somfy SAS. All rights reserved - V0 - 10/2008 www.AVOutlet.com...
  • Page 11 3) Delete the MY position To delete the MY position, move to this position and press the MY button until the shade jogs. Copyright © 2008 Somfy SAS. All rights reserved - V0 - 10/2008 www.AVOutlet.com...
  • Page 12 Press the MY and DOWN buttons simultaneously. The shade moves to the Sun disappearing position. Press and hold the MY button until the shade jogs. The sun disappearing position is deleted. Copyright © 2008 Somfy SAS. All rights reserved - V0 - 10/2008 www.AVOutlet.com...
  • Page 13 4) To tilt the slats, press and hold the UP or DOWN button or use the scroll of the remote control until the slats reach the desired position. Copyright © 2008 Somfy SAS. All rights reserved - V0 - 10/2008 www.AVOutlet.com...
  • Page 14 Quickly press the RTS sensor (C) PROG button to add or delete: the shade jogs and the RTS sensor is programmed or deleted from the motor. Copyright © 2008 Somfy SAS. All rights reserved - V0 - 10/2008 www.AVOutlet.com...
  • Page 15 (MY or down limit) if no sun disappearing position has been memorised. The Wind function is not compatible with this motor. Copyright © 2008 Somfy SAS. All rights reserved - V0 - 10/2008 www.AVOutlet.com...
  • Page 16 UP button to increase the speed or DOWN button to decrease the speed. 3) To confirm the new speed, press and hold the MY button until the shade jogs. Copyright © 2008 Somfy SAS. All rights reserved - V0 - 10/2008 www.AVOutlet.com...
  • Page 17 3) Press and hold the UP or DOWN button to move the shade to the new desired position. 4) To confirm the new limit press and hold the MY button until the shade jogs. Copyright © 2008 Somfy SAS. All rights reserved - V0 - 10/2008 www.AVOutlet.com...
  • Page 18 Erasing the memory of the motor To reset the motor, press the prog button on the motor head until the shade jogs 3 times. All the settings are erased. Copyright © 2008 Somfy SAS. All rights reserved - V0 - 10/2008 www.AVOutlet.com...
  • Page 19 • The crown is properly fitted to the tube. • The end-limits of the motor are properly adjusted. • Verify that the shade is within the recommended weight limit. Copyright © 2008 Somfy SAS. All rights reserved - V0 - 10/2008 www.AVOutlet.com...
