QUICK PROGRAMMING GUIDE FOR DRAPERY RTS MOTORS
DESCRIPTION
Glydea 35e RTS, Glydea 60e RTS,
Irismo™ 35 Mini DC, Irismo™ 45 WireFree RTS
● Motor placement left or right and/or upside
down installation
● New touch motion
● Comes in Dry contact with optional RTS
plug-in module
BEFORE YOU BEGIN
Manually move drapery to a middle position along the track.
This allows for movement of the motor in either direction.
CONNECT POWER TO MOTORS
Glydea® motors are equipped
with an integrated 120V AC
NEMA power plug with a 10
ft. cable
PROGRAMMING THE RTS CONTROL POINT
STEP 1: Press and hold the OPEN/UP
simultaneously on the RTS transmitter until the drapery jogs.
STEP 2: Briefly press OPEN/UP
automatically runs to record both hard stop positions.
CHECKING THE DIRECTION OF OPERATION
STEP 1: Press the RTS transmitter OPEN/UP
- If the drapery opens, the direction of rotation is correct, go to STEP 3.
- If the drapery closes, the direction of rotation is incorrect, go to STEP 2.
STEP 2: Press the
rotation has been modified. Press the OPEN/UP
direction of rotation.
STEP 3: Recording the RTS Transmitter: Press the
PROGRAMMING BUTTON on the back of the RTS transmitter until
the drapery jogs. The RTS transmitter is now recorded.
Press the OPEN/UP
operate drapery.
or CLOSE/DOWN
(STOP) button until the drapery jogs: the direction of
button or CLOSE/DOWN
77
Standard Mounting Inverse Mounting
Irismo
equipped with a plug-in
low voltage (24V DC)
transformer.
Irismo
45 WireFree RTS is equipped with
TM
a rechargeable (26.5V DC) battery.
and CLOSE/DOWN
button.
button to check the
35 Mini DC is
TM
buttons
, the drapery
button to
