3 Ratings

3.1 Recommended Operating Conditions

The table below provides a comprehensive guideline for the optimal use of the Nano Matter, outlining typical
operating conditions and design limits. The operating conditions of the Nano Matter are largely a function based on
its component's specifications.
Parameter
USB Supply Input Voltage
Supply Input Voltage
Operating Temperature
1
Nano Matter powered through the IN5V pin (+5 VDC).

3.2 Power Consumption

The table below summarizes the power consumption of the Nano Matter in different test cases. Notice that the
board's operating current will depend greatly on the application.
Typical Mode Current Consumption²
2
Nano Matter powered through the IN5V pin (+5 VDC), running a Matter color lightbulb example.
To use the Nano Matter in low-power mode, the board must be powered through the pin IN5V.
6 / 17
1
Parameter
Symbol
V
USB
V
IN
T
OP
Symbol
I
NM
Arduino® Nano Matter
Arduino® Nano Matter
Min Typ Max
- 5.0
- 5.0 5.5
-40 -
Min Typ
- 16
Unit
- V
V
85 °C
Max Unit
- mA
