3 Ratings

3.1 Absolute Maximum

Symbol Description
VINMax Maximum input voltage from VIN pad
VUSBMax Maximum input voltage from USB connector
PMax Maximum Power Consumption

3.2 Thermal

Symbol Description
TST Storage Temperature
TOP Operating Temperature (excluding Wireless module)
TOPw Operating Temperature (including Wireless module)

3.3 Recommended Operating Conditions

Symbol Description
VIN Input voltage from VIN pad
VUSB Input voltage from USB connector
V3V3 3.3V output to user application
I3V3 3.3V output current available for user application
VIH Input high-level voltage
VIL Input low-level voltage
IOH Max Current at VDD-0.4 V, output set high
IOL Max Current at VSS+0.4 V, output set low
VOH Output high voltage, 8 mA
VOL Output low voltage, 8 mA
10 / 25 Arduino® Portenta H7 / Rev. 01 - 25/11/2021
Arduino® Portenta H7
Min Typ
-0.3 -
-0.3 -
- -
Min Typ
-40
-40
-10
Min Typ
4.5 5
4.5 5
3.1
- -
2.31 -
0 -
2.7 -
0 -
Max Unit
21 V
21 V
5000 mW
Max Unit
85 °C
85 °C
55 °C
Max Unit
5.5 V
5.5 V
V
1000 mA
3.3 V
0.99 V
8 mA
8 mA
3.3 V
0.4 V
