LU BRICATION AND MAINTENANCE
•
I f a battery is being i nsta l led, M A K E C E R ­
T Al N that the posi tive
f i rst a n d that the n egat i ve ter m i na l is co n nected
to gro u nd . R everse polar i ty wi l l destroy the
rect if ier d i odes i n the a l te rnato r.
VOLTAGE R E G U LATOR
The vo l tage reg u l a to r au to matica l l y contro l s the
a l ternator charg i n g rate. No attempt shou l d be
made to ad j u st the sett i ng of the reg u l ato r.
Figure 55
Voltage Regu lator
-
I f the charge i n d icato r wa rn i n g l ig h t i n d icates
that the a l tern ato r is not charg i ng the battery ,
check the fan be l t an d the w i r i ng co n nect i o ns. I f
these are sa ti sfacto ry and
co n t i n ues to i n d i cate no charge, co nsu l t your
Ford Tractor E q u i p ment Dea l e r .
F U SE BOX
The fuse box is shown i n F i g u re 56 . Remove the
fuse box cover by removing two screws and meta l
cover. The p l astic f use cover is easi I y rem oved by
pu l l ing i t off. A spa re 5 A M P a n d 1 5 AM P fuse
a re swred i n the bo x . A lways rep lace b l own fuses
with the spec i fied fu se .
3 8
(+)
ca b l e is co n n ected
INSTRUMENT
PANEL
the warn i ng l i ght
Figure 56
Fuse Box
-
H E AD LAMP
S h o u l d a hea d l a m p fa i l u re occu r , the b u l b m u st
be re place d . To change the b u l b ;
1 . Remove four screws secu r i ng the h ead l a m p
cover to fender, F i g u re 57.
2. Tu rn the socket to a l ign the in d e x tab a n d
rem ove t h e socket from the h ousi ng, F i g u re 58 .
3. Remove the b u l b .
4 . I nsta l l new b l u b i n the socket a n d i n sta l l the
soc ket w ith b u l b i n the h o us i n g .
Figure 5 7
Headla m p Assembly
-
SPARE FUSES
