LU BRICATION AND MAI NTENANCE
F U EL F I L TER
Dra i n i n g the F i lter:
D ra i n the d iese l fuel f i l ter
when water i s v isi b l e i n the sed i ment bow l .
Clean i n g the F ue l F i l te r :
every 1 00 h o u rs by r i ns i ng in a co ntainer of
clean d i ese l f ue l .
1 . Be s u re th ere i s adequate f u el i n the f ue l ta n k ,
c l ,?se the fuel sh ut-off va l ve, F igu re 5, then
rem ove the fuel sed i men t bowl , F ig u re 40.
Fig ure 40
F u e l Filter
-
2. Open the f u e l sh u t-off va l ve u n t i l a l l water has
been removed and on l y fuel flows fro m the
f i l ter.
3. I nsta l l the fuel sed i ment bowl and b l eed the
system as outl i ne d u n de r " B l eed i n g the F ue l
Syste m . "
Chan ging the F ue l F i l ter:
fi l ter every 200 h o u rs.
1 . C l ose the sh u t-off va l ve, F i g u re 5.
2 . Re move the sed i m ent bow l , F i gure 40.
3. Open the fuel shut-off va l ve to d ra i n any
rem a i n ing water from the ta n k .
4 . D iscard the o l d el ement a n d i nsta l l a new
e lement.
5. I nsta l l and sec u re l y
bowl .
6. Open the f u e l s h u t-off va l ve so f u el wi l l f l ow to
the f i l ter.
30
C l ea n the f ue l f i l ter
Cha nge t h e d iese l fuel
tighten the sed i ment
7. B l eed the fuel f i l ter a n d i nject i o n p u m p as cov-
ered u nd er " B leed i ng the F u e l Syste m . "
B L EED I N G T H E F U EL SYSTEM
B l eed the f u e l system after it has been d ra i n ed :
•
I f a new f i l ter e l ement h as been i n sta l l e d ,
•
I f t h e tracto r h a s r u n o ut of f ue l ,
•
I f the l i nes l ead i n g to o r from the f i l ter h ave
been d i sco nnecte d ,
•
I f t h e i nject i on p u m p h a s been rem oved a n d
rei nsta l l ed .
B leed the f u e l system as fo l l ows:
1 . Be su re th ere i s adeq uate fuel in the fuel tan k .
2 . Open the fuel sh ut-off va l ve .
3 . Open t h e b l eed screws at the to p o f the f u e l
fi l ter ( F igure 40 ) a nd l et t h e a i r b u b b l es escape
from the screws. Then t ig hten b l eed screws.
4. Open the b l eed screw at the p u m p ( F ig u re 41 )
and let the a i r b u b b les esca pe , then c l ose the
b leed screw.
5. Push the hand th rott l e to the h ig h speed posi­
t i on . Tu r(l the · en g i n e over for a few seco nds to
bleed the h i gh p ressu re f u e l tube.
N OTE:
I f the tracto r d oes not start after
com p l et i ng the above b l eed i ng
fuel l i nes to each i njector may have to be
l oosened w h i l e cra n k i n g the eng i ne to com p l ete
b l eed i n g of the system . Tig h te n l i n es at i nj ec­
tors after co m pl et i ng b l ee d i n g .
Figure 4 1
Fuel System Bleed Screw
-
'
p ro ced u re, the
