Pro-OX 8500 Iron Filter Installation & Start-Up Guide
Thank you for purchasing a Clean Water System! With proper installation and a
little routine maintenance your system will be providing iron free water for
many years.
Please review this start‐up guide entirely before beginning to install your system
and follow the steps outlined for best results.
USE PAPER MASK AND VENTILATE AREA TO AVOID BREATHING DUST DURING
Questions?
Call us toll‐free: 1‐888‐600‐5426 or 1‐831‐462‐8500
Email us: support@cleanwaterstore.com
See more information on our website: www.cleanwaterstore.com/resources
PRO-OX MEDIA CONTAINS DUST.
INSTALLATION
Clean Water Made Easy
http://www.cleanwaterstore.com
Advertisement
Related Manuals for Clean Water Systems Pro-OX 8500
Summary of Contents for Clean Water Systems Pro-OX 8500
- Page 1 Clean Water Made Easy http://www.cleanwaterstore.com Pro-OX 8500 Iron Filter Installation & Start-Up Guide Thank you for purchasing a Clean Water System! With proper installation and a little routine maintenance your system will be providing iron free water for many years.
-
Page 2: Table Of Contents
Pro-OX 8500 Iron Filter Installation & Startup Guide Table of Contents Packing List ............................3 Pre-Installation ............................ 4 Best Practices for Piping & Drain Installation ..................4 How Your Iron Filter Works ........................5 Assembly and Installation Instructions ....................7 Programming ........................... -
Page 3: Packing List
Pro-OX 8500 Iron Filter Installation & Startup Guide Packing List Iron Filter 1.0 Cubic Foot Size Quantity 1 Canature 85HE control valve with bypass assembly and pipe connector kit (1” or 3/4”)* Quantity 1 10” x 44” standard filter tank with distributor tube... -
Page 4: Pre-Installation
Pro-OX 8500 Iron Filter Installation & Startup Guide Pre-Installation 1. Review your packing list and make sure you have received all the parts before beginning installation. 2. If you will be turning off the water to your house and you have an electric water heater, shut off the power to the water heater before beginning installation in case the water heater is accidentally drained. -
Page 5: How Your Iron Filter Works
Pro-OX 8500 Iron Filter Installation & Startup Guide 85 HE has quick-release couplings that make it easy to put the iron filter on bypass and remove the filter system from the piping. 6. The drain line tubing (not supplied) is connected to a drain from the drain outlet using flexible ½” ID tubing. - Page 6 Pro-OX 8500 Iron Filter Installation & Startup Guide Fig. 2 Typical Pro-OX piping installation with ball valve and hose bib after the filter. Filter strainer is — optional, and useful if there is sand or grit in the water. The 25/1 micron filter after is optional, and used when there is very fine sediment or colloidal particles over 1 micron present.
-
Page 7: Assembly And Installation Instructions
Pro-OX 8500 Iron Filter Installation & Startup Guide Assembly and Installation Instructions 1. Unscrew by hand the entire Canature 85HE control valve from top of tank if it was shipped screwed on. Make sure distributor tube is capped; if it is not, wrap it with electrical or duct tape. This will ensure you don’t accidentally pour gravel or Pro-OX media into the distributor tube. - Page 8 Pro-OX 8500 Iron Filter Installation & Startup Guide 7. See how the Canature bypass valve is connected. Items 2 are the pipe connectors, and items 3 are the red clips that hold the pipe connectors to the bypass valve. To put the system into bypass or service mode, don’t remove the red clips, just turn the red knobs (items 1).
-
Page 9: Programming
Pro-OX 8500 Iron Filter Installation & Startup Guide 11. Connect some flexible tubing from the drain connection on the Canature 85HE control valve to a suitable drain such as a septic tank or sewer drain. It is OK to run the drain line up and over the Canature 85HE, up to 4 feet above the top of the tank. - Page 10 Pro-OX 8500 Iron Filter Installation & Startup Guide 14. Press the Manual Regen button for 3 seconds, until it beeps. This will begin a manual backwash (regeneration) of your system. 15. Now you can slowly turn the bypass valve to the service position. Do NOT remove the red clips on the bypass valve in order to do so.
-
Page 11: Maintaining Your Pro-Ox Filter System
Pro-OX 8500 Iron Filter Installation & Startup Guide Maintaining Your Pro-OX Filter System Your Pro-OX 8500 iron filter requires very little maintenance. Simply replace the Pro-OX media every 6-10 years for best results. If your water has a lot of hydrogen sulfide odor or iron and manganese levels over 10 PPM (parts per million), a chlorine feed pump may be needed to inject a small amount of chlorine before the well pressure tank and iron filter. - Page 12 Pro-OX 8500 Iron Filter Installation & Startup Guide Initial Backwash Media Lifted Into Control Head Sometimes, when doing the Initial Backwash, the media gets lifted up into the control head. You can tell this happened because you will have little or no flow, either going out to drain while in the backwash positon, or when in the service positon.
