Advantech PPC-V106T-AC
Vehicle Mount Terminal
A l l t r a d e m a r k s , b r a n d n a m e s , a n d b r a n d s a p p e a r i n g h e r e i n a r e t h e p r o p e r t y o f t h e i r r e s p e c t i v e o w n e r s .
• C r i t i c a l a n d e x p e d i t e d s e r v i c e s
• I n s t o c k / R e a d y - t o - s h i p
Artisan Scientific Corporation dba Artisan Technology Group is not an affiliate, representative, or authorized distributor for any manufacturer listed herein.
$
1095
.00
In Stock
Qty Available: 1
Used and in Excellent Condition
Open Web Page
https://www.artisantg.com/75998-1
• We b u y y o u r e x c e s s , u n d e r u t i l i z e d , a n d i d l e e q u i p me n t
• F u l l - s e r v i c e , i n d e p e n d e n t r e p a i r c e n t e r

Advertisement

loading
Need help?

Need help?

Do you have a question about the PPC-V106T-AC and is the answer not in the manual?

Questions and answers

Summary of Contents for Advantech PPC-V106T-AC

  • Page 1 Advantech PPC-V106T-AC Vehicle Mount Terminal 1095 In Stock Qty Available: 1 Used and in Excellent Condition Open Web Page https://www.artisantg.com/75998-1 A l l t r a d e m a r k s , b r a n d n a m e s , a n d b r a n d s a p p e a r i n g h e r e i n a r e t h e p r o p e r t y o f t h e i r r e s p e c t i v e o w n e r s .
  • Page 2 PPC-V106 Fanless Vehicle Mounted Terminal with 10.4" TFT LCD User’s Manual Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com...
  • Page 3 SMI is a trademark of Silicon Motion, Inc. Creative is a trademark of Creative Technology LTD. All other product names or trademarks are properties of their respective owners. For more information on this and other Advantech products, please visit our websites at: http://www.advantech.com http://www.advantech.com.tw For technical support and service, please visit our support website at: http://service.advantech.com.tw/eservice...
  • Page 4 FCC Class B This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interfer- ence when the equipment is operated in a residential environment.
  • Page 5: Packing List

    Packing List Before you begin installing your card, please make sure that the following materials have been shipped: • PPC-V106 series panel PC • Accessories for PPC-V106 - Warranty card - Power cord: For AC Model: US type AC power cord. For DC Model: DC power inlet cable (180cm) -"Drivers, Utilities and User Manual"...
  • Page 6: Additional Information And Assistance

    Additional Information and Assistance Step 1. Visit the Advantech web site at www.advantech.com or www.advantech.com.tw where you can find the latest informa- tion about the product. Step 2. Contact your distributor, sales representative, or Advantech's cus- tomer service center for technical support if you need additional assistance.
  • Page 7: Safety Instructions

    Safety Instructions 1. Read these safety instructions carefully. 2. Keep this User's Manual for later reference. 3. Disconnect this equipment from any AC outlet before cleaning. Use a damp cloth. Do not use liquid or spray detergents for cleaning. 4. For plug-in equipment, the power outlet socket must be located near the equipment and must be easily accessible.
  • Page 8: Wichtige Sicherheishinweise

    Wichtige Sicherheishinweise 1. Bitte lesen sie Sich diese Hinweise sorgfältig durch. 2. Heben Sie diese Anleitung für den späteren Gebrauch auf. 3. Vor jedem Reinigen ist das Gerät vom Stromnetz zu trennen. Verwenden Sie Keine Flüssig-oder Aerosolreiniger. Am besten dient ein angefeuchtetes Tuch zur Reinigung.
  • Page 9 DISCLAIMER: This set of instructions is given according to IEC704-1. Advantech disclaims all responsibility for the accuracy of any statements contained herein. PPC-V106 User Manual viii Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com...
  • Page 10: Table Of Contents

    Contents Chapter 1 General Information ........2 Introduction ............... 2 General Specifications............2 LCD Specifications ............5 Dimensions................ 6 Chapter 2 System Setup.............8 A Quick Tour of the Panel PC .......... 8 Figure 2.1:Front View of the Panel PC......8 Figure 2.2:Right Side of Panel PC........8 Figure 2.3:Rear Side View of the Panel PC....
  • Page 11 Table 4.3:Clear CMOS / External RTC (JP1) ....26 COM-port Interface............26 4.4.1 COM2 RS-232/422/485 Setting (JP5) ......26 Table 4.4:COM2 RS-232/422/485 setting (JP5)... 26 Table 4.5:Serial port default settings ......27 4.4.2 COM1/COM2/COM3/ Pin 9 Output Setting (JP4)..28 Table 4.6:COM1/2/3 Pin 9 Output Setting(JP4)...
  • Page 12 10.1.3 Environmental specifications........49 10.2 Installation of Touchscreen Drivers ........ 49 10.2.1 Installation for Windows 98/ME ........50 10.2.2 Installation for Windows 2000/XP ....... 51 10.3 Further Information ............51 Appendix A Programming the Watchdog Timer .....54 Programming the Watchdog Timer......... 54 Appendix B Pin Assignments ..........58 Inverter Power Connector (CN10) ........
  • Page 13 PPC-V106 User Manual Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com...
  • Page 14 General Information This chapter gives background information on the PPC-V106 panel Sections include: • Introduction • General Specifications • LCD Specifications • Dimensions Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com...
  • Page 15: Chapter 1 General Information

    Chapter 1 General Information 1.1 Introduction PPC-V106 is fanless and comes with a VIA Eden low-power CPU for higher reliability and performance. The ruggedized aluminum enclosure without ventilation holes makes PPC-V106 waterproof and dust proof. A variable power source suits vehicles such as forklifts and trucks, which typically operate anywhere from 12 to 48 VDC.
  • Page 16 • Front panel: IP65/NEMA4 compliant • Enclosure: Ruggedized aluminum without ventilation holes Standard PC functions • CPU: Embedded VIA Eden 800 MHz CPU • BIOS: Award 256 KB Flash BIOS, supports Plug & Play, APM • System Chipset: VIA CLE266 and VT8235 CD •...
  • Page 17 • Display type: Simultaneously supports CRT and flat panel displays (EL, LCD and gas plasma) Audio function • Chipset: Integrated in VT8235CD South Bridge • Audio controller: AC97 Ver. 2.0 compliant interface, Multi stream Direct sound and Direct Sound 3D acceleration •...
  • Page 18: Lcd Specifications

    With current technology, it is impossible to completely eliminate defective pixels. Advantech is actively working to improve this technology. Chapter 1 Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com...
  • Page 19: Dimensions

    1.4 Dimensions PPC-V106 User Manual Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com...
  • Page 20 System Setup This chapter details system setup on the PPC-V106 Panel PC. Sections include: • A Quick Tour of the Panel PC • Installation procedures • Running the BIOS Setup Program Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com...
  • Page 21: Chapter 2 System Setup

    Chapter 2 System Setup 2.1 A Quick Tour of the Panel PC Before you start to set up the panel PC, take a moment to become familiar with the locations and purposes of the controls, drives, connectors and ports, which are illustrated in the figures below. When you place the panel PC upright on the desktop, its front panel appears as shown in Figure 2-1 Figure 2.1: Front View of the Panel PC...
  • Page 22 When you turn the Panel PC around and look at its rear cover, you will find VESA standard holes and others for mounting. There are no ventila- tion holes, as shown in Figure 2-3. Figure 2.3: Rear Side View of the Panel PC The I/O section is at the bottom of the panel PC, as shown in Fig.
  • Page 23: Installation Procedures

    2.2 Installation Procedures 2.2.1 Connecting the Power Cord There are two kinds of power supplies for the PPC-V106 series, AC and For AC model : The Panel PC can only be powered by an AC electrical outlet (100 ~ 250 volts, 50 ~ 60 Hz).
  • Page 24: Running The Bios Setup Program

    2.3 Running the BIOS Setup Program Your panel PC is likely to have been properly set up and configured by your dealer prior to delivery. You may still find it necessary to use the panel PC's BIOS (Basic Input-Output System) setup program to change system configuration information, such as the current date and time or your type of hard drive.
  • Page 25: Installing System Software

    2.4 Installing System Software Recent releases of operating systems from major vendors include setup programs which load automatically and guide you through hard disk preparation and operating system installation. The guidelines below will help you determine the steps necessary to install your operating system on the panel PC hard drive.
  • Page 26: Installing The Drivers

    Note: The drivers and utilities used for the PPC-V106 panel PCs are subject to change without notice. If in doubt, check Advantech's website or contact our application engineers for the latest informa- tion regarding drivers and utlities. Chapter 2...
  • Page 27 PPC-V106 User Manual Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com...
  • Page 28 Hardware and Peripheral Installation This chapter details the installation of the PPC-V106 panel PC hardware. Sections include: • Overview of Hardware Installation and Upgrading • Installing the 2.5" Hard Disk Drive (HDD) • Installing the Universal Arm • Placing the Rubber Seal Artisan Technology Group - Quality Instrumentation ...
  • Page 29: Chapter 3 Hardware And Peripheral Installation

    Chapter 3 Hardware and Peripheral Installation 3.1 Overview of Hardware Installation and Upgrading The panel PC consists of a PC-based computer that is housed in a rugge- dized aluminum enclosure. Any maintenance or hardware upgrades can be completed after removing both panels.. Warning! Do not remove the ruggedized aluminum covers until you have verified that no power is flowing...
  • Page 30 Place the HDD inside the HDD bracket and tighten four screws (#1) from both sides of the HDD bracket. HDD (Bottom up) Pin 1 The HDD cable (1 x 44-pin to 1 x 44-pin) is next to the HDD bracket. Connect the HDD cable to the HDD. Make sure that the red wire corresponds to Pin 1 on the connector, which is labelled on the board.
  • Page 31 Note 3 HDD installation procedures for the PPC-V106 is subject to change without notice. If in doubt, check Advantech's website. (www.advantech.com) or contact our application engineers for the latest information. PPC-V106 User Manual Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com...
  • Page 32: Installing The Universal Arm

    3.3 Installing the Universal Arm Press latches at the same time and then rotate support-1 until you can see both of the screw holes. Rotate support-2 until the angle is the same as support-1. Use four M4x8L screws and attach the U-Arm with the PPC-V106. Use latches adjust the angle of PPC-V106 (every 14.4°...
  • Page 33: Placing The Rubber Seal

    3.4 Placing the Rubber Seal To ensure that your PPC-V106, the supplied rubber seal must be placed correctly between the front bezel and back cover. Please note the direc- tion of the seal. The mark should be up. Marked Flat (UP) Figure 3.2: Placing the Rubber Seal PPC-V106 User Manual Artisan Technology Group - Quality Instrumentation ...
  • Page 34: Jumper Settings And Connectors

    Jumper Settings and Connectors This chapter tells how to set up the panel PC hardware, including instruc- tions on setting jumpers and connecting peripherals, switches and indicators. Be sure to read all the safety precautions before you begin the installation proce- dures.
  • Page 35: Chapter 4 Jumper Settings And Connectors

    Chapter 4 Jumper Settings and Connectors 4.1 Setting Jumpers You can configure your panel PC to match the needs of your application by setting jumpers. A jumper is the simplest kind of electrical switch. It consists of two metal pins and a small metal clip (often protected by a plastic cover) that slides over the pins to connect them.
  • Page 36: Jumpers And Switches

    4.1.1 Jumpers and Switches The motherboard of the panel PC has a number of jumpers that allow you to configure your system to suit your applications. The table below lists the function of each of the boardís jumpers. Table 4.1: Jumpers and their functions Label Function CMOS clear for external RTC...
  • Page 37: Connectors

    4.1.3 Connectors Onboard connectors link the panel PC to external devices such as hard disk drives or floppy drives. The table below lists the function of each of the board ís connectors. Table 4.2: Panel PC connectors Label Function Power input connector Flat panel display connector (Reserved) LVDS connector SIR connector (Reserved)
  • Page 38: Locating Connectors

    4.1.4 Locating Connectors Figure 4.2: Locating Connectors on the PPC-V106 Motherboard 4.2 CPU Installation The CPU is embedded on the motherboard, so there are no settings for frequency ratio or voltage. Chapter 4 Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com...
  • Page 39: Cmos Clear For External Rtc (Jp1)

    4.3 CMOS Clear for External RTC (JP1) Warning: To avoid damaging the computer, always turn off the power supply before setting “Clear CMOS”. Set the jumper back to “Normal opera- tion” before turning on the power supply. Table 4.3: Clear CMOS / External RTC (JP1) *Normal operation (default) Clear CMOS 4.4 COM-port Interface...
  • Page 40 The IRQ and the address ranges for COM1, COM2, COM3 and COM4 are fixed. However, if you wish to disable the port or change these parameters later you can do this in the system BIOS setup. The table overleaf shows the default settings for the panel PC’s serial ports.
  • Page 41: Com1/Com2/Com3/ Pin 9 Output Setting (Jp4)

    4.4.2 COM1/COM2/COM3/ Pin 9 Output Setting (JP4) Table 4.6: COM1/2/3 Pin 9 Output Setting(JP4) Normal (default) +5 V output +12 V output NOTE: Pins 1, 3 and 5 are for COM1 Pins 2, 4 and 6 are for COM2 Pins 7, 9 and 11 are for COM3 When enabling this function, you should remove a jumper from JP3 as shown in table 4.7.
  • Page 42 Table 4.7: JP3 Setting Normal (default) Remove jumper from pin 1 and 2 to make pin 9 on COM1 a power output. Remove jumper from pin 3 and 4 to make pin 9 on COM2 a power output. Remove jumper from pin 5 and 6 to make pin 9 on COM3 a power output.
  • Page 43: Vga Interface

    4.5 VGA Interface The panel PC's AGP VGA interface can drive conventional CRT dis- plays. It is also capable of driving a wide range of flat panel displays, including electroluminescent (EL), gas plasma, passive LCD and active LCD displays. The board has two connectors to support these displays simultaneously: one for standard CRT VGA monitors, and one for flat panel displays.
  • Page 44 VIA Chipset This chapter provides information on Intel chipset configuration • Introduction • Further information Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com...
  • Page 45: Chapter 5 Via Chipset

    For further information about the AGP/VGA installation in PPC-V106, including driver updates, troubleshooting guides and FAQ lists, visit the following web sites: VIA website: www.via.com.tw Advantech websites: www.advantech.com PPC-V106 User Manual Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com...
  • Page 46 AGP SVGA Setup • Introduction • Installation of SVGA Driver for Windows 98/ME for Windows 2000/XP • Further Information Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com...
  • Page 47: Chapter 6 Agp Svga Setup

    Chapter 6 AGP SVGA Setup 6.1 Introduction The PPC-V106 has an onboard integrated VGA chipset The specifica- tions and features are described as follows: 6.1.1 Chipset The VIA CLE266 boasts a complete integrated VIA 128-bit 2D/3D graphics engine with a high quality video processing unit including MPEG-2 decoding, video scaling and Alpha Blending.
  • Page 48: Installation For Windows 98/Me

    For further information about the AGP/SVGA installation in your PPC- V106, including driver updates, troubleshooting guides and FAQ lists, visit the following web resources: VIA website: www.via.com.tw Advantech website:www.advantech.com Chapter 6 Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com...
  • Page 49 PPC-V106 User Manual Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com...
  • Page 50 PCI Bus Ethernet Interface This chapter provides information on Ethernet configuration. • Introduction • Installation of Ethernet Driver - for Windows 98/ME - for Windows 2000/XP • Further Information Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com...
  • Page 51: Chapter 7 Pci Bus Ethernet Interface

    Chapter 7 PCI Bus Ethernet Interface 7.1 Introduction The PPC-V106 is equipped with a high performance 32-bit Ethernet chipset which is fully compliant with IEEE 802.3 100 Mbps CSMA/CD standards. It is supported by major network operating systems. It is also both 100Base-T and 10Base-T compatible.
  • Page 52: Installation For Windows 98/Me

    7.2.1 Installation for Windows 98/ME If the Operating System's New Hardware Wizard prompts you with "New Hardware Found" for the "PCI Ethernet Controller", you should click "Next" until "Finish" is clicked, without specifying location of the driver. You will see "PCI Ethernet Controller" in the Device Manager.
  • Page 53: Further Information

    7.3 Further Information Realtek website: www.realtek.com.tw Advantech website: www.advantech.com PPC-V106 User Manual Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com...
  • Page 54 Audio • Introduction • Installation of Audio Driver Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com...
  • Page 55: Chapter 8 Audio

    Chapter 8 Audio 8.1 Introduction The ALC202 is an 18-bit, full duplex AC'97 2.2 compatible stereo audio CODEC designed for PC multimedia systems, including host/soft audio and AMR/CNR based designs. The ALC202 AC'97 CODEC supports multiple CODEC extensions with independent variable sampling rates and built-in 3D effects.
  • Page 56 USB 2.0 This chapter describes how to install the USB 2.0 driver Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com...
  • Page 57: Chapter 9 Usb 2.0

    Chapter 9 USB 2.0 9.1 Installation of USB 2.0 Driver Before installing the audio driver, please take note of the procedures detailed below. You must know which operating system you are using in your PPC-V106, and then refer to the corresponding installation proce- dure Important : The following Windows illustrations are exam-...
  • Page 58: Driver Installation For Windows 2000

    9.3 Driver Installation for Windows 2000 Install Service Pack 3 or above before running the setup program. Open the Device Manager and check if there is a “Universal Serial Bus (USB) Controller” under “Other devices”. Execute the setup program by double click on the “SETUP.exe” file in \PPC-V106\USB2.0 The screen shows the VIA Software License Agreement.
  • Page 59: Driver Installation For Windows Me / 98 / 98Se

    2.0 Host Controller Driver” by selecting the “Uninstall” button. This will completely remove the driver from the system. 9.5 Further Information VIA web site : http://www.via.com.tw Advantech website: www.advantech.com PPC-V106 User Manual Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com...
  • Page 60 Touchscreen • Introduction • Installation of Touchscreen Drivers for Windows 98/ME for Windows 2000/XP Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com...
  • Page 61: Chapter 10 Touchscreen

    For more detailed information, please visit the following websites: www.dynapro.com www.3m.com/us/electronics_mfg/touch_systems www.elotouch.com Advantech Co.,Ltd. reserves the right to alter the touchscreen at any time without notice. 10.1.2 General specifications Please refer to Chapter 1, Section 1.2 of this manual. PPC-V106 User Manual...
  • Page 62: Environmental Specifications

    10.1.3 Environmental specifications Temperature:-10° ~ 50° C (operating) -40° ~ 71° C (storage) Relative humidity: 90 RH at 35° C (operating) 90 RH at 35° C for 240 hours, non-condensing (storage) Chemical resistance: The active area of the touchscreen is resistant to the following chemicals when exposed for a period of one hour at a tempera- ture of 21°...
  • Page 63: Installation For Windows 98/Me

    10.2.1 Installation for Windows 98/ME To install the software to PPC-V106, your PPC-V106 must have Win- dows 98/Me system running and installed PenMount Series Interface control board already. If you have an older version of PenMount Win- dows 98/Me driver installed in your PPC-V106, please remove it first. You will find out "Unknown Device"...
  • Page 64: Installation For Windows 2000/Xp

    The next screen is "Hardware Installation" , select " Continue Anyway" The next screen is "InstallShield Wizard Completed", Select "Finish" 10.3 Further Information Dynapro websites: www.dynapro.com www.3m.com/us/electronics_mfg/touch_systems Advantech websites: www.advantech.com www.advantech.com.tw Salt website: www.salt.com.tw Chapter 10 Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com...
  • Page 65 PPC-V106 User Manual Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com...
  • Page 66 Programming the Watchdog Timer The PPC-V106 is equipped with a watchdog timer that resets the CPU or generates an interrupt if processing comes to a standstill for any reason. This feature ensures system reliability in industrial standalone or unmanned environments. Artisan Technology Group - Quality Instrumentation ...
  • Page 67: Appendix A Programming The Watchdog Timer

    Appendix A Programming the Watchdog Timer A.1 Programming the Watchdog Timer To program the watchdog timer, you must write a program which writes I/ O port address 440 (hex). The output data is a time interval value. The value range is from 01 (hex) to 3F (hex), and the related time interval is from 1 sec.
  • Page 68 ;----------------------------------------------------------------------------- ; Configurate logical device 8, configuration register CRF6 | ;----------------------------------------------------------------------------- MOV DX,2EH MOV AL,07H ; point to Logical Device Number Reg. OUT DX,AL MOV DX,2FH MOV AL,08H ; select logical device 8 OUT DX,AL MOV DX,2EH MOV AL,30H ;Set watch dog activate or inactivate OUT DX,AL MOV DX,2FH MOV AL,01H ;...
  • Page 69 ;------------------------------------------ ; Exit extended function mode | ;------------------------------------------ MOV DX,2EH MOV AL,AAH PPC-V106 User Manual Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com...
  • Page 70 Pin Assignments This appendix contains information on PPC-V106’s pin assignments. Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com...
  • Page 71: Appendix B Pin Assignments

    Appendix B Pin Assignments B.1 Inverter Power Connector (CN10) Table B.1: Inverter power connector (CN10) Signal +12V ENAVEE +5 V B.2 Internal Speaker Connector (CN14) Table B.2: Internal speaker connector (CN14) Signal Speaker out_L - Speaker out_L + Speaker out_R - Speaker out_R + PPC-V106 User Manual Artisan Technology Group - Quality Instrumentation ...
  • Page 72: Floppy Drive Connector (Cn16) Reserved

    B.3 Floppy Drive Connector (CN16) Reserved Table B.3: Floppy drive connector (CN16) Signal Signal VCC (+5 V) STEP INDEX VCC (+5 V) WRITE ENABLE DRIVE SELECT VCC (+5 V) WRITE DATA DISK CHANGE TRACK 0 WRITE PRO- TECT MOTOR ON READ DATA DIRECTION DENSITY...
  • Page 73: Ide Hard Disk Drive Connector (Cn15)

    B.4 IDE Hard Disk Drive Connector (CN15) Signal Signal IDE RESET # DATA 7 DATA 8 DATA 6 DATA 9 DATA 5 DATA 10 DATA 4 DATA 11 DATA 3 DATA 12 DATA 2 DATA 13 DATA 1 DATA 14 DATA 0 DATA 15 SIGNAL GND...
  • Page 74: Ir Connector (Cn8) Reserved

    B.5 IR Connector (CN8) Reserved Signal IR_RX IR_TX B.6 LVDS Connector (CN4) Signal Signal LVDS_NO LVDS_P0 LVDS_N1 LVDS_P1 LVDS_N2 LVDS_P2 LVDS_CN1 LVDS_CP1 VDDSAFE * VDDSAFE * * VDDSAFE can choose +5V or +12V output via JP2 Appendix B Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com...
  • Page 75: Flat Panel Display Connector (Cn2) (Reserved)

    B.7 Flat Panel Display Connector (CN2) (Reserved) Signal Signal VDDSAFE * VDDSAFE * VDDSAFE * VDDSAFE * Vcon SHFCLK FPVS * VDDSAFE can FPDE FPHS choose +5V or +12V ENAVEE ENAVEE output via JP2 PPC-V106 User Manual Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com...
  • Page 76: Com1

    B.8 COM1 Signal B.9 COM2 Signal RS-232 RS-422 RS-485 DATA- DATA+ Appendix B Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com...
  • Page 77: Com3

    B.10 COM3 Signal B.11 COM3 Connector (CN 26) Signal PPC-V106 User Manual Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com...
  • Page 78: Com 4 Connector (Cn 23)

    B.12 COM 4 Connector (CN 23) Signal B.13 USB Port Signal DATA- DATA+ Appendix B Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com...
  • Page 79: Parallel Port Connector (Cn11)

    B.14 Parallel Port Connector (CN11) Table B.4: Parallel Port Connector (CN8) Signal Signal STROBE* ACK* BUSY SLCT AUTOFD* ERR* INIT* SLCTINI* * low active PPC-V106 User Manual Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com...
  • Page 80: Vga Connector

    B.15 VGA Connector Signal GREEN BLUE SPDAT HSYNC VSYNC SPCLK Appendix B Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com...
  • Page 81 PPC-V106 User Manual Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com...
