PWS 472 Product manual
Operation manual
Version 1.0

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the PWS 472 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Advantech PWS 472

Summary of Contents for Advantech PWS 472

  • Page 1 PWS 472 Product manual Operation manual Version 1.0...
  • Page 2 Matters needing attention Battery precautions Battery life depends on the type of battery and how it is used. The battery life can be extended by avoiding the battery in a state that is completely electrically powered, which is prone to damage the battery. A few full discharges are more damaging than often charging the batteries.

  • Page 3: Table Of Contents

    Catalog Matters needing attention................Ⅰ 1. Parts ....................1 2. Introduction..................1 2.1 Product overview..............2 2.2 SIM card and SD card installation........3 2.3 Battery charging..............3 2.4 Data transfers between PC............ 4 2.5 Check the battery and enter the power use menu... 4 3.

  • Page 4: Parts

    1. Parts USB Connecting line PWS 472 terminal (Standard USB to Micro USB) Battery Power adapter Wristband 2. Introduction PWS-472 based on Android development, with four core processors and 5-inch high-resolution screen, the use of industrial grade design and development with waterproof, dustproof, anti-fall, can replace the large capacity batteries, with more than 8 hours of endurance.

  • Page 5: Product Overview

    2.1 Product overview 1. Main screen 7. Microphone 2. Push-button 8. Scan engine 3. Power button 9. Camera 4. Scan button 10. Fill-in light 5. Receiver 11. Battery cover 13. Back cover screw 6. LED lamp 12. Speaker 08. Scan window 14.

  • Page 6: Sim Card And Sd Card Installation

    2.2 SIM card and SD card installation Assembly of batteries, SD cards and SIM cards Use a screwdriver counterclockwise to loosen the two screws on the battery lid. 2. Open the rear cover and remove the battery。 You can now use the Micro SD card slot and the SIM card slot. （SIM card support Mobile/Unicom 4G）...

  • Page 7: Data Transfers Between Pc

    3. Plug the AC charger into the power outlet. 2.4 Data transfers between PC 1. Connect a standard USB connector to the PC's USB port. 2. Connect the micro USB connector in the connector to the micro USB port at the bottom of the device. 3.
  • Page 8 2Enter settings 3 Select battery.

  • Page 9: Basic Operation

    3. Basic operation 3.1 Application program How do I open the application interface? On the main screen, click button can. How to connect WiFi, BT? Click "Settings"-"WLAN" in your application to open WiFi and select the network you want to connect to. In the application, tap Settings-Bluetooth to open Bluetooth, and then select the device that you want to connect to the pairing.
  • Page 10 Call function Call Processing/dial-up call 1 On the main screen ， click dial button. 2 Select dial interface 3 Enter the phone number for the listener, and then click the call. To remove a number, click the Delete button. Hang up Click Hook button.
  • Page 11 Application List The following illustration shows a common application sequence Call, you can directly use the T9 keyboard to Telephone dial the phone, or through the T9 keyboard to search for contacts, you can quickly dial back to call records. Send and receive SMS, SMS content support sending Information text or inserting pictures, facial expressions,...

  • Page 12: Barcode Scanner

    3.2 Barcode scanner 1. The native system automatically turns on scanning service. 2. The native scan service is divided into two modes: One is analog keyboard message, that is, open any edit area/input area to press the scan button to scan input. One is the messaging mechanism, which needs to modify associated reception mechanism...
  • Page 13 In the system settings, locate the WLAN roaming as follows: Click enter: WLAN roaming switch: Turn on/off roaming switches Toggle Signal Threshold: Set the trigger signal value for roaming Toggle Signal Difference: Sets the difference between the current signal and the roaming AP signal.

  • Page 14: Rfid Sensing

    3.4 RFID Sensing 1. Tap the TagInfo.

  • Page 15: Product Specification

    四、 Product specification Processor Cortex-A53, 64 bit, Quad core, 1.3GHz Internal storage Flash Memory 16GB Audio system Loudspeaker and microphone, handset Display Size / type 5 inch HD Large color touch screen Max Resolution HD (1280 X 720) brightness (cd/m² 450 cd/m²LED Backlight Touch screen Multi-Touch Capacitive touch screen Application program interface...
  • Page 16 FCC Caution. This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.
