Device Login Via Management Port - UNIVIEW IPSAN Series Quick Manual

1. Log in to the device through the management port.
2. Set the service port IP.
3. Configure failover (for dual controller device).
4. Create a RAID group/RAID LUN.
5. Create logical resources.
6. Create a target and add an initiator.
7. Assign Storage Area Network (SAN) resources.
8. Configure the initiator (with Windows client as an example).
9. View disks assigned (with Windows 10 as an example).

3.3 Device Login via Management Port

1. Open your browser, enter the default storage management port IP address (eg.
http://192.168.0.1) in the address bar to go to the WEB client.
Management port
NOTE!

Compatible browser versions: IE11, Chrome 60 or higher, Firefox 60 or higher,
Edge 79 or higher.

For a dual controller device, the default management port IP address for lower
controller is http://192.168.0.1, for upper controller is http://192.168.0.2.
(1) If no VMS is installed, enter http://
Login via Management Port
（With IP address 192.168.0.X/24 network segment）
Management workstation
Management port IP
13
in the address bar.
