5.8.1 Status indication
There are three LED indicators on the front panel to provide router status information. The
ETH port has two additional LEDs that provide information about the port status.
Caption
Color
State
PWR
Green
Blinking
On
Fast blinking
DAT
Red
Blinking
WAN
Yellow
LED goes out
1x per one sec.
LED goes out
1x per two sec.
LED goes out
1x per five sec.
ETH
Green
On
Off
ETH
Yellow
On
Blinking
Off
The status indication of the WAN LED is updated every 10 seconds.
Description
Router is ready
Starting of the router
Updating firmware
Communication in progress on the radio channel
Signal strength is from –50 dBm to –69 dBm
Signal strength is from –70 dBm to –89 dBm or differ-
ence between neighbouring cells is exactly 3 dBm
Signal strength is from –90 dBm to –113 dBm or differ-
ence between neighbouring cells is smaller than 3 dBm
Selected 100 Mbps
Selected 10 Mbps
The network cable is connected
Data transmission
The network cable is not connected
Table 5: Status indication
