- Page 1 All manuals and user guides at all-guidesbox.com CC3200 SimpleLink™ Wi-Fi and IoT Solution ® with MCU LaunchPad Hardware User's Guide Literature Number: SWRU372B June 2014 – Revised January 2015...
-
Page 2: Table Of Contents
The CC3200 Code Examples .................... CC3200 Application Notes ......................The Community ......................Known Limitations ....................Hardware Limitations .......................... Revision History .......................... Revision History Table of Contents SWRU372B – June 2014 – Revised January 2015 Submit Documentation Feedback Copyright © 2014–2015, Texas Instruments Incorporated... - Page 3 ......................Jumper Settings ....................... UART Signals ........................SOP Lines ....................Miscellaneous Settings ........................ Push Buttons ......................... LEDs ......................... Change Log SWRU372B – June 2014 – Revised January 2015 List of Figures Submit Documentation Feedback Copyright © 2014–2015, Texas Instruments Incorporated...
-
Page 4: Introduction
Backchannel universal asynchronous receiver/transmitter (UART) through USB to PC • On-board chip antenna with U.FL for conducted testing SimpleLink, LaunchPad, Code Composer Studio are trademarks of Texas Instruments. ARM® Cortex is a trademark of ARM Limited. ARM, Cortex are registered trademarks of ARM Limited. -
Page 5: What's Included
ICES-003 Class A compliant. Hardware Description Figure 1. CC3200 LaunchPad EVM Overview SWRU372B – June 2014 – Revised January 2015 CC3200 SimpleLink™ Wi-Fi and IoT Solution with MCU LaunchPad ® Hardware Submit Documentation Feedback Copyright © 2014–2015, Texas Instruments Incorporated... -
Page 6: Block Diagram
Can be powered externally, with 2xAA or 2xAAA alkaline batteries working down to 2.3V typical (typ) CC3200 SimpleLink™ Wi-Fi and IoT Solution with MCU LaunchPad SWRU372B – June 2014 – Revised January 2015 ® Hardware Submit Documentation Feedback Copyright © 2014–2015, Texas Instruments Incorporated... -
Page 7: Connecting A Boosterpack
CC3200 device. Figure 4. JTAG Headers SWRU372B – June 2014 – Revised January 2015 CC3200 SimpleLink™ Wi-Fi and IoT Solution with MCU LaunchPad Hardware ® Submit Documentation Feedback Copyright © 2014–2015, Texas Instruments Incorporated... -
Page 8: I2C Connections
Open : Isolate the sensors from the CC320 Short : Connect the accelerometer interrupt to the CC3200 on GPIO13 CC3200 SimpleLink™ Wi-Fi and IoT Solution with MCU LaunchPad SWRU372B – June 2014 – Revised January 2015 ® Hardware Submit Documentation Feedback Copyright © 2014–2015, Texas Instruments Incorporated... -
Page 9: Power Connections
SWRU372B – June 2014 – Revised January 2015 CC3200 SimpleLink™ Wi-Fi and IoT Solution with MCU LaunchPad ® Hardware Submit Documentation Feedback Copyright © 2014–2015, Texas Instruments Incorporated... -
Page 10: Uart Signals
Short 2-3: Route the signals to the FTDI for Flash programming. CC3200 SimpleLink™ Wi-Fi and IoT Solution with MCU LaunchPad SWRU372B – June 2014 – Revised January 2015 ® Hardware Submit Documentation Feedback Copyright © 2014–2015, Texas Instruments Incorporated... -
Page 11: Sop Jumpers
Note: SOP[2:0] corresponds to J15, J16, and J17, in the LaunchPad schematic design. Figure 7. SOP Jumpers SWRU372B – June 2014 – Revised January 2015 CC3200 SimpleLink™ Wi-Fi and IoT Solution with MCU LaunchPad ® Hardware Submit Documentation Feedback Copyright © 2014–2015, Texas Instruments Incorporated... -
Page 12: Miscellaneous Settings
To observe the Network Processor (NWP), MAC Logs. SOP2 Isolation Isolate SOP2 (GPIO_25) from the 20 pin connector CC3200 SimpleLink™ Wi-Fi and IoT Solution with MCU LaunchPad SWRU372B – June 2014 – Revised January 2015 ® Hardware Submit Documentation Feedback Copyright © 2014–2015, Texas Instruments Incorporated... -
Page 13: Push Buttons
When pushed, the GPIO_22 will be pulled to VCC. GPIO_13 When pushed, the GPIO_13 will be pulled to VCC. SWRU372B – June 2014 – Revised January 2015 CC3200 SimpleLink™ Wi-Fi and IoT Solution with MCU LaunchPad ® Hardware Submit Documentation Feedback Copyright © 2014–2015, Texas Instruments Incorporated... - Page 14 GPIO_10 and GPIO_11 are used as I2C also. So whenever the pull-ups are enabled, the LEDs would glow. CC3200 SimpleLink™ Wi-Fi and IoT Solution with MCU LaunchPad SWRU372B – June 2014 – Revised January 2015 ® Hardware Submit Documentation Feedback Copyright © 2014–2015, Texas Instruments Incorporated...
-
Page 15: Power
The LaunchPad is designed such that it can be powered by the USB connection or by external 2xAA/2xAAA batteries. SWRU372B – June 2014 – Revised January 2015 CC3200 SimpleLink™ Wi-Fi and IoT Solution with MCU LaunchPad ® Hardware Submit Documentation Feedback Copyright © 2014–2015, Texas Instruments Incorporated... -
Page 16: Powering From Usb
Figure J12 (shorted) J13 (shorted) Figure 9. Powering From USB CC3200 SimpleLink™ Wi-Fi and IoT Solution with MCU LaunchPad SWRU372B – June 2014 – Revised January 2015 ® Hardware Submit Documentation Feedback Copyright © 2014–2015, Texas Instruments Incorporated... -
Page 17: Measure Cc3200 Current Draw
GPIO of the CC3200 is driving a high current load like LED, then that is also included in this measurement. SWRU372B – June 2014 – Revised January 2015 CC3200 SimpleLink™ Wi-Fi and IoT Solution with MCU LaunchPad ® Hardware Submit Documentation Feedback Copyright © 2014–2015, Texas Instruments Incorporated... -
Page 18: Measuring Low Power
4. Measure the current. (Keep in mind that if the current levels are fluctuating, it may be difficult to get a stable measurement. It is easier to measure quiescent states.) CC3200 SimpleLink™ Wi-Fi and IoT Solution with MCU LaunchPad SWRU372B – June 2014 – Revised January 2015 ® Hardware Submit Documentation Feedback Copyright © 2014–2015, Texas Instruments Incorporated... -
Page 19: Measuring Active Power
4. An ammeter can also be used for this measurement, but the results may be erroneous due to the switching nature of the current. SWRU372B – June 2014 – Revised January 2015 CC3200 SimpleLink™ Wi-Fi and IoT Solution with MCU LaunchPad ® Hardware Submit Documentation Feedback Copyright © 2014–2015, Texas Instruments Incorporated... -
Page 20: Rf Connections
Resistor mounted towards U.FL Murata connector Figure 14. Board Set for Conducted Testing CC3200 SimpleLink™ Wi-Fi and IoT Solution with MCU LaunchPad SWRU372B – June 2014 – Revised January 2015 ® Hardware Submit Documentation Feedback Copyright © 2014–2015, Texas Instruments Incorporated... -
Page 21: Design Files
The Software Development Kit (SDK) to use with the CC3200 LaunchPad can be obtained from http://www.ti.com/tool/cc3200sdk. SWRU372B – June 2014 – Revised January 2015 CC3200 SimpleLink™ Wi-Fi and IoT Solution with MCU LaunchPad ® Hardware Submit Documentation Feedback Copyright © 2014–2015, Texas Instruments Incorporated... -
Page 22: Software Examples
There are many application notes with practical design examples and topics located at the SimpleLink(TM) Wi-Fi(R) main wiki page, and the main landing page. CC3200 SimpleLink™ Wi-Fi and IoT Solution with MCU LaunchPad SWRU372B – June 2014 – Revised January 2015 ® Hardware Submit Documentation Feedback Copyright © 2014–2015, Texas Instruments Incorporated... -
Page 23: The Community
When the device enters Hibernate state, these pins can be floating and high currents can be drawn by the serial flash. SWRU372B – June 2014 – Revised January 2015 CC3200 SimpleLink™ Wi-Fi and IoT Solution with MCU LaunchPad ® Hardware Submit Documentation Feedback Copyright © 2014–2015, Texas Instruments Incorporated... -
Page 24: Revision History
5 of this chapter. 3.1.2 For EVMs annotated as FCC – FEDERAL COMMUNICATIONS COMMISSION Part 15 Compliant: CAUTION Revision History SWRU372B – June 2014 – Revised January 2015 Submit Documentation Feedback Copyright © 2014–2015, Texas Instruments Incorporated... - Page 25 Antenna types not included in this list, having a gain greater than the maximum gain indicated for that type, are strictly prohibited for use with this device. Concernant les EVMs avec antennes détachables SWRU372B – June 2014 – Revised January 2015 Revision History Submit Documentation Feedback Copyright © 2014–2015, Texas Instruments Incorporated...
- Page 26 EVM, including without limitation any warning or restriction notices. The notices contain important safety information related to, for example, temperatures and voltages. 4.3 Safety-Related Warnings and Restrictions: Revision History SWRU372B – June 2014 – Revised January 2015 Submit Documentation Feedback Copyright © 2014–2015, Texas Instruments Incorporated...
- Page 27 CONTRACT OR ANY OTHER LEGAL THEORY, AND EVEN IF THE EVM FAILS TO PERFORM AS DESCRIBED OR EXPECTED. Limitations on Damages and Liability: SWRU372B – June 2014 – Revised January 2015 Revision History Submit Documentation Feedback Copyright © 2014–2015, Texas Instruments Incorporated...
- Page 28 County, Texas. Notwithstanding the foregoing, any judgment may be enforced in any United States or foreign court, and TI may seek injunctive relief in any United States or foreign court. Revision History SWRU372B – June 2014 – Revised January 2015 Submit Documentation Feedback Copyright © 2014–2015, Texas Instruments Incorporated...
- Page 29 IMPORTANT NOTICE Texas Instruments Incorporated and its subsidiaries (TI) reserve the right to make corrections, enhancements, improvements and other changes to its semiconductor products and services per JESD46, latest issue, and to discontinue any product or service per JESD48, latest issue.
