3-5. UPS Setting

Parameter 1
88
888 888
Parameter 2
01: Output voltage setting
Interface
0 1
02: Frequency Converter enable/disable
Interface
02
CF
12
Parameter 3
230
Vac
O U T P U T
EnA
There are three parameters to set up the UPS.
Parameter 1:
It's for program alternatives.
Refer to below table. Parameter 2 and parameter 3 are the
setting options or values for each program.
Setting
Parameter 3: Output voltage
For 200/208/220/230/240 VAC models, you may choose the
following output voltage:
200: presents output voltage is 200Vac
208: presents output voltage is 208Vac
220: presents output voltage is 220Vac
230: presents output voltage is 230Vac (Default)
240: presents output voltage is 240Vac
Setting
Parameter 2 & 3: Enable or disable converter mode. You may
choose the following two options:
CF ENA: converter mode enable
CF DIS: converter mode disable (Default)
