F2 (LIST):
F3 (COPY):
Enter the name of an existing label already in memory and press the
'enter' key. A new label is then created with the same data as the
source label, which allows immediate editing of the new label
format. The F3 copy feature will also copy the current field to the
next field when the cursor is at the farthest left position of the
Create/Modify Label Screen.
F4 (KILL):
F5 and ALT-S: Calls up the System Maintenance Screen. All system
36
Creating Labels Using Internal Batch Software
Displays a library listing of every label format and/or
graphic image loaded in the current memory module. F2
can be used only when the prompt is in the Label Name
position of the Create/Modify or Print Screens.
Used in the Create/Modify Label Screen only. Enter a
new Label Name, then press the F3 key. The message
below will appear.
LABEL NAME:________________
NEW LABEL NAME:__________________
Used in the Create/Modify Label Screen only. Enter an
existing label name, followed by the F4 key. The
message "Remove Label? (Y/N)" will appear. Answer
yes or no with the Y or N key. If Y, the label is
permanently removed from the memory module , if the
Write Protect Switch is 'off'. When creating or
modifying a label format, the F4 Kill Feature also
deletes a single format line one at a time. Move the
cursor to the farthest left position of the screen, then
press F4. The current line will be deleted.
maintenance functions are described in Section 3.5.
