Datamax Allegro 2 Operator's Manual page 105

Media
Width:
Length:
Thickness:
Type:
Supply Roll:
Optional Front Rewind:
Label Material:
Thermal -Transfer Ribbons: Standard widths are 25mm, 38mm, 51mm, 64mm,
Media Sensing:
Note: The reflective sensor mark must be carbon based. The sensor
is infrared and will reflect off of a plain black mark.
Allegro2
Specifications
0.75" (19mm) to 4.65" (118mm); 4.25"
(108mm) maximum recommended
0.50" (13mm) to 99.99" (2539mm)
0.0025" (0.0635mm) to 0.0100" (0.254mm)
Roll-fed, die-cut continuous or fan-fold labels,
tags or tickets; most direct thermal or thermal
transfer materials
8" (203mm) maximum diameter on 1.5" (38mm)
to 3" (76mm) cores
8" (152mm) maximum O.D. capacity (full supply
roll)
Thermal transfer plain-coated papers, vinyl,
Mylar, metalized paper, nonwoven fabric, fine
woven fabric, thermal-visible light scannable
paper, infrared scannable paper, thermal ticket/tag
stock, thermally sensitive plastic stock.
76mm, 89mm, 110mm; 1182' (360m) length
Moveable "see-through" for die-cut labels and
reflective for tags with black striping
F-3
