Datamax Allegro 2 Operator's Manual page 41

Function
Handshake:
Mode:
Data Bits:
Stop Bits:
Parity:
Baud Rate:
Keys:
Blk End:
Auto NL:
CR:
Compatible:
3. Select Stand-Alone Labeling Software Mode
The Printer is shipped in the RS-232 mode for use with PCs. To
use the CRT, turn Dip Switch S1-7 to the 'on' position and
insert the 256K Flash Module into the Printer before turning the
power on. Plug the module into the module slot as described in
Section 1.6. Ensure that the lettering is facing toward the front
of the Printer. When the Printer is turned on it will recognize
that the module has been formatted as an Internal Batch
Software Module and will run the Internal Batch Program. If the
module has not been formatted, the following screen will
appear:
BATCH SYSTEM INITIALIZATION
INSERT Flash MEMORY MODULE AND PRESS:
I: INITIALIZE NEW MODULE.
ENTER: ENTER BATCH SYSTEM.
Esc:
Allegro2
Creating Labels Using Internal Batch Software
Default
Settings
none
FDX
8
1
none
9600
US
US/CR
on
CR
LINK MC 2
Table 3-1 LINK CRT Default Settings
EXIT TO RS-232 MODE.
Function Settings
F1 CTRL W
F2 CTRL X
F3 CTRL Y
F4 CTRL Z
F5 ALT S
F6 ALT P
F7 ALT I
F8 ALT X
F9 ALT F
33
