SCANMASKIN 18
MANUAL

Advertisement

Chapters

loading
Need help?

Need help?

Do you have a question about the 18 and is the answer not in the manual?

Questions and answers

Summary of Contents for SCANMASKIN 18

  • Page 1 SCANMASKIN 18 MANUAL...
  • Page 2 Vi gratulerar! Tack för att ni valt Scanmaskin som leverantör. Vi önskar er lycka till med er nya Scanmaskin 18 och hoppas att den skall motsvara era förväntningar. Scanmaskin Sverige AB Box 187 437 22 Lindome Sverige Telefon: +46 (0) 31 99 49 70 www.scanmaskin.se...
  • Page 3 Scanmaskin 18 får endast användas till slipning av horisontella ytor godkända av Scanmaskin Sverige AB. Om Scanmaskin 18 används till andra ändamål eller hanteras på ett annat vis än beskrivet i denna användarmanual så avsäger sig Scanmaskin Sverige AB allt ansvar.
  • Page 4: Table Of Contents

    Manuell transport ....................16 Lyftning ......................... 16 Demontering av maskin ..................17 Inuti fordon ......................17 Handhavande ......................18 Försiktighetsåtgärder ..................18 Maskinens funktion ....................18 Manöverdon ......................19 Uppstart ........................ 19 Stopp ........................19 Kontrollpanel ......................20 Sliphastighet ......................20 Rotationsriktning ....................
  • Page 5 SCANMASKIN 18 SVENSKA Underhåll ........................22 Säkerhetsåtgärder ....................22 Daglig inspektion före bruk .................. 22 Service- och inspektionsschema ................. 22 Byte av Scan-On-fästskiva ................... 23 Rengöring av maskinen ..................23 Felsökning ......................24 5.6.1 Vanliga problem ..................... 24 5.6.2 Alarm- och felkoder ..................25 Reservdelar ........................
  • Page 6: Specifikationer

    För att finna vilka specifikationer som rör din maskin, kontrollera informations- skylten som sitter fast på maskinens framdel. Anslut aldrig Scanmaskin 18 annan spänning eller fas än den som anges i denna specifikation. Strömkällan måste vara avsäkrad enligt ”Extern säkring” i denna specifikation;...
  • Page 7: Mekaniska Specifikationer

    Bauta 2019-06-17 Erik Karjula Tabell 11 B Ljud- & Vibrationsvärden 1.3 Mekaniska specifikationer Modell Scanmaskin 18 Slipdiameter 450 mm (18”) Diameter på sliptallrik 150 mm (6”) Hastighet för sliptallrik 300-1100 rpm Vikt 95 kg (210 lbs) Sliphuvud Frigående Tabell 12 Mekaniska specifikationer...
  • Page 8: Verktyg

    Figur 14 Scan-On-fästskiva med verktyg. 1.5 Användningsområde Scanmaskin 18 är uteslutande konstruerad för bearbetning av horisontella ytor. Scanmaskin 18 får inte användas för andra ändamål än de som anges i denna bruksanvisning. Tillverkaren tar inte ansvar för skador eller personskador orsaka- de av felaktig användning av Scanmaskin 18.
  • Page 9: Leveransomfattning

    SCANMASKIN 18 SVENSKA 1.6 Leveransomfattning Följande är inkluderat med Scanmaskin 18 vid leverans. • Användarmanual • 5 mm insexnyckel • Nyckel till elskåpet Maskiner som säljs utanför Europa kommer antingen att vara utrustade med ett elintag som följer lokal standard eller ett passande kontaktdon som sitter i elintaget.
  • Page 10: Säkerhetsföreskrifter

    Undersök arbetsytan efter skruvar eller andra hårda föremål som sitter i ytan. Använd inte maskinen om det sitter fast främmande föremål i ytan, dessa föremål måste tas bort innan maskinen används. Läs “2.3 Organisationsåtgärder” och “2.5 Säkerhet vid användning av maskinen” noggrant innan maskinen tas i bruk! www.scanmaskin.se...
  • Page 11: Organisationsåtgärder

    För att kunna utföra servicearbete på korrekt vis så måste de rätta verktygen användas för ändamålet. Reparationer får endast utföras av Scanmaskin Sverige AB certifierade servicetekniker. Under vissa förhållanden kan sliparbete orsaka gnistor. Personal som arbetar med maskinen måste därför vara medvetna om brandrisken och hur man hanterar en brandolycka på...
  • Page 12: Personalval Och Kvalifikationer

    Slå på och av maskinen i enlighet med den här användarmanualen. Innan maskinen slås på se till att ingen kan bli utsatt för fara när maskinen startar. Maskinen får endast startas i upprätt läge. Stäng inte av eller ta bort ventilationsrelaterade anordningar när maskinen är igång! www.scanmaskin.se...
  • Page 13: Elsäkerhet

    SCANMASKIN 18 SVENSKA Alla personer i maskinens närhet måste bära hörselskydd, skyddsglasögon och säkerhetsskor. Utöver detta så måste maskinoperatören bära åtsittande skyddskläder. Förlängningskablar måste vara märkta och godkända för den totala kraftåtgången av maskinen och följa allmänna och lokala bestämmelser.
  • Page 14: Kablar

    3. Vänta tills alla rörliga delar stannat helt 4. Koppla ur huvudströmmen 5. Säkra upp så ingen oavsiktlig start kan förekomma Koppla alltid ur huvudströmmen till maskinen vid maskinen för att förhindra att någon oavsiktligt kopplar in huvudströmmen medan arbete på maskinen utförs. www.scanmaskin.se...
  • Page 15: Säkerhet Som Rör Service

    SCANMASKIN 18 SVENSKA 2.8 Säkerhet som rör service Sätt maskinen i avstängt och säkert läge innan arbete på den påbörjas. Läs ”2.7 Definition av ”Avstängt och säkert läge””. Arbeta aldrig på maskinen när huvudströmmen är ansluten! Alla delar måste ha stannat helt innan något arbete påbörjas!
  • Page 16: Transport

    3.3 Lyftning Innan lyft av maskinen påbörjas, läs“2.9.2 Lyftning”  Ta loss verktygen enligt instruktionerna i “4.10 Verktygsbyte”.  Sätt fast de remmar som används för att lyfta maskinen vid de två lyftpunkterna som visas i “Figur31”.  Lyft maskinen. Figur 31 Lyftpunkter www.scanmaskin.se...
  • Page 17: Demontering Av Maskin

    SCANMASKIN 18 SVENSKA 3.4 Demontering av maskinen Om maskinen måste transporteras i ett begränsat utrymme kan den demonteras till två delar. På varje sida av sliphuvudet/motorn finns två tappar, varje tapp spärras av en låsklämma. För att demontera maskinen, lossa motorkabeln; ta bort låskläm- morna och tapparna.
  • Page 18: Handhavande

    Växelhuset har tre sliphuvuden som roterar i motsatt riktning i förhållande till växelhuset. Varje sliphuvud är utrustat med en Scan-on-fästskiva och varje skiva håller det verktyg som används. Se ”Figur 41”. Figur 41 Illustrerar sliphuvudenas rotation i förhållande till växelhuset. www.scanmaskin.se...
  • Page 19: Manöverdon

    Se ”4.1 Försiktighetsåtgärder” innan du startar maskinen. Hur maskinen startas: 1. Se till att maskinen är utrustad med korrekt verktyg från Scanmaskin. 2. Se till att huvudströmkabeln och stoftavskiljarens slangar är anslutna till maskinen. 3. Starta stoftavskiljaren om sådan används.
  • Page 20: Kontrollpanel

    Använd omkopplaren ”L/R” för att ändra slipskivornas riktning. Maskinen kommer först att göra ett mjukt stopp och sedan en mjuk start. Säkert avstängt läge Vid underhåll eller verktygsbyte måste maskinen ställas till ”Avstängt och säkert läge”. Se ”2.7 Definition av ”Avstängt och säkert läge”” för ytterligare information. www.scanmaskin.se...
  • Page 21: Verktygsbyte

    SCANMASKIN 18 SVENSKA 4.10 Verktygsbyte Innan verktygen byts, läs “2.8 Säkerhet som rör service”. Denna illustration visar hur man byter verktygen. Figur 43 Hur man fäster slipsegmenten på Scan-On-fästskivan 1 Sätt in verktyget i den bredaste änden 2 Dra verktyget utåt från skivan 3 Verktyget sitter nu fast på...
  • Page 22: Underhåll

     Se över maskinen så ingen annan skada har uppstått. 5.3 Service- och inspektionsschema Dagligen  Kontrollerar hjulen  Kontrollera sliphuvudet  Syna maskinen efter skador  Rengör filter Efter 12 timmars användning  Dra åt alla skruvar 5.4 Byte av Scan-On-fästskiva Följ dessa steg för att byta Scan-On-fästskivan www.scanmaskin.se...
  • Page 23: Rengöring Av Maskinen

    SCANMASKIN 18 SVENSKA  Se till att maskinen är försatt i ”avstängt och säkert läge” som är beskrivet i ”2.7 Definition av ”Avstängt och säkert läge””  Luta bak maskinen och säkra den.  Ta bort eventuella verktyg enligt ”4.10 Verktygsbyte”.  Lossa de 3 st skruvarna som håller fast Scan-On-fästskivan.
  • Page 24: Felsökning

     Se till att kabeln inte är för lång. Om kabeln är för lång, använd en kabel med högre klassning och en elcentral närmare maskinen. Maskinen vibrerar mycket  Sliphastigheten är för hög  Sänk hastigheten  Verktygen är skadade  Kontrollera verktygen  Byt verktygen vid behov Tabell 51 Vanliga fel www.scanmaskin.se...
  • Page 25: Alarm- Och Felkoder

     Frekvensomriktarens inre temperatur  Kontrollera ventilationsfläktarna överskrider 120°C (248°F). Detta kan bero på  Kontrollera fläktarnas filter defekt ventilation i elskåpet.  Kontakta Scanmaskin Sweden AB Internt fel  Kontakta Scanmaskin Sweden AB Skyddsjordsfel • Kabeln som leder till motorn har skadats  Kontrollera motorkabeln...
  • Page 26: Reservdelar

    Reservdelar 6.1 Växelhus www.scanmaskin.se...
  • Page 27: Mittaxel

    SCANMASKIN 18 SVENSKA 6.2 Mittaxel www.scanmaskin.se...
  • Page 28: Spindelaxel

    6.3 Spindelaxel www.scanmaskin.se...
  • Page 29: Sliphuvud

    SCANMASKIN 18 SVENSKA 6.4 Sliphuvud www.scanmaskin.se...
  • Page 30: Garanti

    6. Scanmaskin förbehåller sig rättigheten att ändra konstruktionen eller att genom- föra förbättringar utan skyldighet att uppdatera tidigare tillverkade produkter. 7. Alla garantireparationer ska utföras av Scanmaskin eller av en verkstad som är auktoriserad av Scanmaskin. Kostnader för reparationer som har utförts av en oauktoriserad verkstad kommer inte att ersättas av Scanmaskin.
  • Page 31: Eu-Deklaration

    SCANMASKIN 18 SVENSKA 8 EU-deklaration Försäkran om CE-överensstämmelse Tillverkare Scanmaskin Sweden AB Adress Heljesvägen 10 427 36 Lindome, Sverige Produkt Golvslipmaskin Produktnamn Scanmaskin 18 Serienummer _______________ Produkten uppfyller följande EU-riktlinjer Maskindirektiv 2006/42/EG 2004/108/EG 2006/95/EG Harmoniserade standarder EN ISO 13850 EN ISO 12100-1/-2 EN ISO 60204-1 Utfärdandeplats...
  • Page 32 We congratulate! Thank you for choosing Scanmaskin as a supplier. We wish you the best of luck with yours new Scanmaskin 18 and hope that it will meet your expectations. Scanmaskin Sweden AB Scanmaskin Sweden AB Box 187 SE- 437 22 Lindome. Sweden Phone: +46 (0) 31 99 49 70 www.scanmaskin.com...
  • Page 33 Scanmaskin 18 may only be used for grinding horizontal surfaces approved by Scanmaskin Sweden AB. If Scanmaskin 18 is used for other purposes or handled in ways other than that described in this User Guide, Scanmaskin Sweden AB disclaims all responsibility.
  • Page 34 Operation of machine ................... 50 Control device ....................... 51 Start up ......................... 51 Stop ........................51 Control panel ......................52 Grinding speed ..................... 52 Rotation direction ....................52 Safety off position ....................52 4.10 Grinding ........................ 52 4.11 Changing tools ..................... 53 www.scanmaskin.com...
  • Page 35 SCANMASKIN 18 ENGLISH Maintenance ....................... 54 Precautions ......................54 Daily inspection prior to operation ............... 54 Maintenance and inspection list ................55 Grinding disc replacement / assembly ..............55 Cleaning the machine ..................55 Trouble shooting ....................56 5.6.1 Common faults ....................56 5.6.2...
  • Page 36: Specifications

    To find the specifications that apply to your machine, check the information plate on the electrical cabinet door. Never connect the Scanmaskin 18 to any other voltage or number of phases than described in this specification. The power source must be fused according to “External fuse” in this specification;...
  • Page 37: Mechanical Specifications

    Grinding plate diameter 150 mm 6” Grinding plate speed 300 – 1100 rpm Mass 95 kg (210 lbs) Gear barrel Free running Table 12 Mechanical specifications Dimensions of Scanmaskin 18 Width 460 mm 18.1” Height 1030 mm 40.6” Depth 810 mm 31.9”...
  • Page 38: Tools

    1.5 Range of application Scanmaskin 18 is exclusively designed to process horizontal surfaces. Scanmaskin 18 must not be used or other purposes than stated in this user guide. The manufacturer will not be liable for damage or injury resulting from incorrect usage of Scanmaskin 18. Failure to follow the directions in this user guide will void the warranty.
  • Page 39: Overview

    Read “2.6 Electrical safety” before connecting any included connectors. 1.6 Overview Figur 16 Overview of Scanmaskin 18 Item Description Reference 520147 Handle 520082 4.3 Control Device...
  • Page 40: Safety Regulations

    Check the work area for screws or other hard objects in the concrete. Don’t use the machine if there are any foreign objects stuck into the surface. Such objects must removed prior to operation of machine. Read “2.3 Organizational measures” and “2.5 Safety regarding operation of ma- chine” thoroughly before operation! www.scanmaskin.com...
  • Page 41: Organizational Measures

    SCANMASKIN 18 ENGLISH 2.3 Organizational measures The user guide is to be kept near the location where the machine is being operated and must be within reach at all times. In addition to this user guide general and legal regulations regarding accident pre- vention and environmental protection must be complied with as per local regulations.
  • Page 42: Personnel Selection And Qualification

    To perform maintenance work correctly it is imperative to be equipped with the proper tools for the task in question. Repairs may only be made by Scanmaskin Sweden AB certified service technicians. Some grinding work may generate sparks under certain circumstances. Personnel working with the machine must therefore be aware of the risk of fire and how to handle a fire situation properly.
  • Page 43: Safety Regarding Operation Of Machine

    SCANMASKIN 18 ENGLISH 2.5 Safety regarding operation of machine Do not allow any method of working that impairs safety! Recognized official procedures have to be used to ensure the machine is operated in safe and best conditions. Only operate the machine when all safety devices and related safety equipment are present and operational! Check the machine visually for any damage and defects at least once a day.
  • Page 44: Electrical Safety

    Only start work after you are familiar with the electrical engineering regula- tions that apply to the local area. Only use voltage seekers that comply with the regulations when troubleshoot- ing. From time to time check voltage seekers to ensure that they are opera- tionally efficient. www.scanmaskin.com...
  • Page 45: Cables

    SCANMASKIN 18 ENGLISH 2.6.1 Cables Only use cables that are marked and rated according to the specifications in “1.1 Electrical specifications”. Don’t use excessive length of the cables. If a very long cable is needed we recommend that you use a cable rated for more current and connect it to a distribution central near the machine.
  • Page 46: Safety Regarding Maintenance

    2.9.1 Manual transport When transporting the machine manually be observant about ramps and/or edges. Follow local traffic regulations for the work site to prevent accidents. Failure to comply with these regulations may cause injuries or damages. www.scanmaskin.com...
  • Page 47: Lifting

    SCANMASKIN 18 ENGLISH 2.9.2 Lifting The machine must be secured according to local safety regulations before lifted. No person is allowed beneath a lifted machine! The machine must be lifted according to the instructions in “3.3 Lifting”. Observe the machines point of bal- ance before lifting! Failure to comply with these regulations may cause injuries or dam- ages.
  • Page 48: Transport

    Before attempting to lift the machine, read “2.9.2 Lifting”  Detach the tools according to the instructions in “4.11 Changing tools”.  Fasten the straps used for lifting at the two handles as shown in “Figure 3-1”.  Lift the machine. Figure 31 Lifting points www.scanmaskin.com...
  • Page 49: Separation Of Machine

    SCANMASKIN 18 ENGLISH 3.4 Separation of machine If the machine needs to be transported in a limited space it can be separated into two parts. On each side of the grinding head / motor assembly there is two pins, each fastened by a locking clip.
  • Page 50: Operation

    The gear barrel has got three grinding heads that rotates in the opposite direction of the gear barrel. Each grinding head is equipped with a Scan-on plate where each plate hold the tools used. See “Figure 4-1”. Figure 41 Illustrates the rotation of the grinding heads versus the gear barrel. www.scanmaskin.com...
  • Page 51: Control Device

    4.3 Control device Figure 4.2 Control device. Item Function Description Stop Stops the Scanmaskin 18 Start Starts Scanmaskin 18 Table 4.1 Description of control device. 4.4 Start up See ”4.1 Precautions” before starting the machine. How to start the machine: 1.
  • Page 52: Control Panel

    4.6 Control panel Figure 4.3 Control panel of Scanmaskin 18 Text Description Article no. SPEED Selects speed 596009 + 596008 Selects rotation direction 596001 + 596022 + 596020 Table 4.2 Description of the control panel. 4.7 Grinding speed Use the “SPEED” dial to adjust the rotation speed of the grinding discs between the intervals described in chapter 1.
  • Page 53: Changing Tools

    SCANMASKIN 18 ENGLISH 4.11 Changing tools Before changing tools, read “2.8 Safety regarding maintenance”. This illustration shows how to change the tools. Figure 4-3 How to fit the diamond segments on the Scan-On plate 1 Insert the segment at the widest part of the slot...
  • Page 54: Maintenance

     Inspect the wheels for damage.  Inspect the grinding heads. Dirt between the Scan-On plate and the grinding hub can impair the flexibility of the grinding head.  If any screws appears loose, tighten them.  Look over the machine for any other damage. www.scanmaskin.com...
  • Page 55: Maintenance And Inspection List

    SCANMASKIN 18 ENGLISH 5.3 Maintenance and inspection list Daily  Inspect the wheels  Inspect the grinding heads  Look for any other damage Every 300 hours  Demount the motor and the machine house cover. Change grease on the gearing 53002. Make sure that the sealing 530028 is in good condition.
  • Page 56: Trouble Shooting

     Measure that all three phases are pres- ent and at full voltage near the machine  Internal error  Contact Scanmaskin Sweden AB The machine only  The motor is overheated  Wait until the motor is cool again operates while the  The control device is damaged...
  • Page 57: Error Codes

    120°C (248°F). This could be caused by  Inspect the filters to the fans faulty ventilation in the electrical cabinet.  Contact Scanmaskin Sweden AB Internal error  Contact Scanmaskin Sweden AB Protective earth • The cable to the motor has been damaged  Inspect the motor cable...
  • Page 58: Spare Parts

    Spare parts 6.1 Gear Barrel www.scanmaskin.com...
  • Page 59 520142 GEAR HOUSING 520151 DRIVE BELT SC-450 520143 LOWER PLATE 520134 SPACER for AXLE, FLEX TOOL HOLDER, Scanmaskin 18, Scan Combiflex 450/500/650/700/800 583032 V-RING 65 FLEX TOOL HOLDER 520067 FLEX TOOL HOLDER Scan Combiflex 450/500/Scanmaskin 18 590006 SCAN-ON FASTENING DISCS, Scan Combiflex 450/500/Scanmaskin 18...
  • Page 60: Centre Axis

    6.2 Centre Axis www.scanmaskin.com...
  • Page 61 SCANMASKIN 18 ENGLISH Centre Axis Scanmaskin 18 Article number Description 520040 CENTER AXEL 530018 BEARING 6210-RS1, Scan Combiflex 330/450/500/ Scanmaskin 18 910304 CIRCLIP SGA 30 520122 UPPER ROTATING BEARING BOX 570087 V-RING V-100A Scanmaskin 18/Scan Combiflex 450/500 520120 CENTRAL BEARING BOX...
  • Page 62: Spindle Axis

    6.3 Spindle Axis www.scanmaskin.com...
  • Page 63 SCANMASKIN 18 ENGLISH Spindle Axis Scanmaskin 18 Article number Description 520126 BEARING BOX SM-18/450/500/650/700/800 570104 BEARING 6206 SM-18/SC-450/500/650/700/800/1000 520125 GRINDING AXLE SC-450/SM-18 520153 GEARWHEEL GRINDING AXLE SC-450 910203 PARALLEL KEY 8x7x25 570104 BEARING 6206 SM-18/SC-450/500/650/700/800/1000 520126 BEARING BOX SM-18/450/500/650/700/800 www.scanmaskin.com...
  • Page 64: Grinding Head

    6.4 Grinding head www.scanmaskin.com...
  • Page 65 EXCHANGE KIT FLEX TOOL HOLDER (1 DISC) 590062 EXCHANGE KIT FLEX TOOL HOLDER (2 DISC) 590063 EXCHANGE KIT FLEX TOOL HOLDER (3 DISC) 520161 TAPER LOCK BUSHING 25mm FLEX TOOL HOLDER, 18/450/500/800/ 580161 CENTRAL HUB FLEX TOOL HOLDER 583032 V-RING 65 FLEX TOOL HOLDER 520134 SPACER for AXLE, FLEX TOOL HOLDER, 18/450/500/650/700/800 www.scanmaskin.com...
  • Page 66: Warranty

    3. Periodic inspections, adjustments, maintenance work and changes are not covered by the warranty. 4. Scanmaskin is not liable for any damages to grinding discs or other similar equipment. 5. The warranty only applies to material and design deficiencies and does not apply in the following cases: a.
  • Page 67: Ec Declaration

    SCANMASKIN 18 ENGLISH EC Declaration Declaration of conformity Manufacturer Scanmaskin Sweden AB Address Heljesvägen 10 437 36 Lindome Sweden Product Grinding machine Name Scanmaskin 18 Serial number _____________________ Standards used including number Machine directives 2006/42/EC 2004/108/EG 2006/95/EG Harmonized standards EN ISO 13850...
  • Page 68: Kontakt

    Contact information Sweden (Head Office) Heljesvägen 10 Box 187 SE-437 22 Lindome Phone: +46 (0) 31 99 49 70 E-mail: info@scanmaskin.se Website: www.scanmaskin.se Finland Raudoittajantie 3 A FIN-06450 Porvoo / Borgå Phone: +358 10 292 4700 E-mail: info@scanmaskin.fi Website: www.scanmaskin.fi 22737 72nd Ave S, Suite C-104...
  • Page 69 SCANMASKIN 18 ENGLISH www.scanmaskin.com...
  • Page 70 SCANMASKIN SWEDEN AB Huvudkontor / Head office Box 187 SE-437 22 Lindome, Sweden Besöksadress / Visiting Address Heljesvägen 10, Lindome, Sweden Phone: +46 (0)31 - 99 49 70 Email: info@scanmaskin.com www.scanmaskin.com...
