Overview
4. Overview
This IN776MHI⁎⁎⁎O000 gateway supports four combinations.
Gateway's client interface
Mitsubishi Heavy Industries VRF
systems
IMPORTANT
This document assumes that the user is familiar with these technologies.
Figure 1. Integration of Mitsubishi Heavy Industries units into Modbus systems
Figure 2. Integration of Mitsubishi Heavy Industries units into KNX TP systems
USER MANUAL Version 1.2.12
↔
Gateway's server interface
Modbus TCP and RTU
KNX TP
to
BACnet/IP or MS/TP
Home Automation
700series Air Gateway - IN776MHI⁎⁎⁎O000
Page 5 of 37
