INMBSDAI001I000 Modbus RTU Gateway

3. Overview

®
The Intesis INMBSDAI001I000 gateway provides full integration of Daikin air conditioners into Modbus RTU
(EIA-485) networks.
Figure 1. Integration of Daikin AC units into a Modbus RTU installation using the Intesis INMBSDAI001I000
IMPORTANT
This document assumes that the user is familiar with these technologies.

3.1. Inside the Package

Items included:
• Intesis INMBSDAI001I000 gateway
• Cable to connect the gateway and the indoor unit
• Installation Sheet

3.2. Main Features

• Modbus RTU (EIA-485) server device.
• Total control and monitoring of the AC unit from Modbus RTU, including AC unit's internal variables, running
hours counter (for filter maintenance control) and error indication.
• Quick and easy installation and configuration (plug and set the DIP switches).
• External power not required.
• Simultaneous control of the AC unit by Modbus RTU and the IR remote controller.
• Reduced dimensions.
• Wall or DIN rail mounting, or even inside the indoor unit in some models of AC.
• Window contact function allows energy savings.
Page 4 of 23
gateway.
