Overview

4. Overview
This IN770AIR00xO000 gateway supports four applications.
Gateway's client interface
Panasonic domestic and commercial
HVAC systems
IMPORTANT
This document assumes that the user is familiar with these technologies.
Figure 1. Integration of Panasonic AC systems into Modbus installations
Figure 2. Integration of Panasonic AC systems into KNX installations
USER MANUAL Version 1.0.7
Panasonic domestic and commercial with KNX, Serial and IP support
↔ Gateway's server interface
Modbus TCP and RTU
KNX TP
to
BACnet/IP or MS/TP
Home Automation
