Kommander-KA
User Guide
4-channel KA104LIVE+
1 2
3
10
1. Status LED
2. Reset button
3. 4x XLR-F balanced line channel inputs 1-4
4. 1x USB ports
5. 2x SpeakON NL4 Speaker outputs ch 1-4
6. 1x CA-COM connection ch 1-4
7. 2x RJ45 Ethernet (Ethercon) port for primary & secondary network
8. 4x XLR-M balanced line channel outputs
9. PowerCon TRUE inlet (AC mains in)
10. PowerCon TRUE link (AC mains in)
14
5
4
OUTPUTS
6
9

Front Panel

9
CAUTION: To
reduce the risk DO NOT
EXPOSE TO
of electric RAIN OR
MOISTURE
shock, the
grounding of the
center pin of the
AC input must
be maintained.
ATTENTION: Pour éviter les risques de choc
électrique, la mise à la terre du contact central A. Input signal monitor LED
de la fiche secteur doit être maintenue.
B. Output signal monitor LED
10

AC mains supply

The AC Main connection is made via the provided power cord:
1. insert the powerCon TRUE flying connector into the inlet
and then rotate it clockwise;
2. connect the power plug of the
power cord to a mains socket
outlet.
Once properly plugged, the amplifier
powers up: the front and back LEDs
light on.
In order to set the amplifier unit in standby mode, press and
hold the button on the front panel for 2 seconds. To wake up the
amplifier from standby mode, press
and hold the button for 2 seconds.
The powerCon TRUE link (AC mains
out) connector allows to distribute
the AC main power to other units according to their power
consumption. Please don't exceed the limits stated on the next
tables.
A B C D
C. Status LED
D. Standby button
click!
