K-array Kommander-KA User Manual page 8

Kommander-KA
User Guide
Unpacking
Each K-array amplifier is built to the highest standard and
thoroughly inspected before leaving the factory.
Upon arrival, carefully inspect the shipping carton, then examine
and test your new amplifier. If you find any damage, immediately
notify the shipping company. Check that the following parts are
supplied with the product.
A. 1x Amplifier unit: model and version shall be one from the following list:
• Kommander-KA14 I
• Kommander-KA18 / Kommander-KA18+
• Kommander-KA28 / Kommander-KA28+
• Kommander-KA34
• Kommander-KA68 / Kommander-KA68+
• Kommander-KA208 / Kommander-KA208+
• Kommander-KA104
• Kommander-KA104LIVE / Kommander-KA104LIVE+
• Kommander-KA208LIVE / Kommander-KA208LIVE+
B. 2x Rack mounting brackets with screws
C. PC 4/ 4-ST-7,62 speaker output flying connectors *
D. 4-Pin Female SpeakON Cable-Mount Connector**
E. 1x Power cord
F. 1x Quick guide
A
Notes
* 2 pieces in 4-channel units, 4 pieces in 8-channel units.
* 2 pieces in 4-channel units, 4 pieces in 8-channel units for Kommander-KA208LIVE
*** The AC mains cord plug may differ from the picture according to local regulation.
8
B
*
C
***
E
**
D
F
4-channel units: KA14 I, KA34, KA104
8-channel units: KA18, KA28, KA68, KA208
