Fametech AP-3515 Quick Installation Manual

 Specifications
Model Name
Processor
Memory
Storage
LCD Panel
Touch Panel
Speaker
I/O Expansion
USB
LAN
COM
LPT
VGA
Cash Drawer 1 x RJ11 port supports 2 cash drawer with 12V or 24V by jumper
DC Power Out
DC Power In
Integrated Peripheral
Thermal Printer (PRP-250X)
Power Management
Power Adapter
Mechanical & Environmental
Dust and Water
Tilt Adjustment
Dimension
Weight
Certification
Operation System POS Ready 7/Windows Embedded 8.1 Industry/Windows 10 IoT/Linux (Ubuntu)
Operation Condition 0°C to +40°C / 20 to 80% without condensation (Equipped with HDD)
Storage Condition
Optional Accesories
8" (800x 600), 9.7" (1024X768) , 10.4"(1280x800) ,and 15" (1024x768) LCD Display
2nd Display
Customer Display
MSR
Combo Card Reader
i-Button
AP-3515
Intel® Bay Trail-D J1900 2.0G up to 2.4G, 2M Cache
1 x DDR3L SODIMM, up to 8GB
1 x 2.5" SATA BAY (Option : m-SATA)
15-inch TFT LCD with LED Backlight
1024 (W) RGB x 768 (H)
True-Flat Projected Capacitive Multi Touch
True-Flat 5-wire Resistive Touch
1 x 2W High Quality Speaker
6 x USB type A
- 1 x USB 2.0 and 1 x USB 3.0 (Bottom)
- 2 x USB 2.0 (Stand Side)
- 2 x USB 2.0 (Panel Side)
1 x RJ45 10/100/1000Mbps Giga Ethernet
4 x COM (DB9), w/ RI/+5V/12V
1 x DB25 Parallel Port (Option)
1 x DB-15 VGA Port
1 x +12V Power Output
1 x Standard Mini-DIN 4PIN type
Thermal Printer with cutter, 203 dpi and 250 mm/s
12V@6A 60W Adapter (System)
24V@2.5A 60W Adapter (Printer)
IP65 on Front Panel
15° ~ 85 °
355 (W) x 416 (H) x 296 (D) mm
8.3 kg
CE/FCC/LVD
-20°C to +55°C / 20 to 85% without condensation
Optional PCAP Touchscreen
VFD and LCD Customer Display
Comply with ISO 7811 and Three Track support
MSR - Comply with ISO 7811/JSII and Three Track
RFID - Comply Mifare, ISO14443AB-4 and Felica
Dallas i-button Reader
15 Inches All-In-One POS System
Quick Installation Guide
IMPORTANT SAFETY INFORMATION
Read following instructions carefully.

Use only parts, especially power adapter, recommended by the manufacturer;

unapproved parts may be hazardous.
Make sure that the voltage applied to the power outlet is within the specified

range (100VAC ~240VAC).
Improper power source voltage range will cause damage.
Power off the system and remove the power adapter while cleaning the system.

Before powering on the system, make sure all the peripherals are

firmly installed.
AP-3515
