MB2236 MFP
Service Manual
September 2024

www.lexmark.com

Advertisement

loading
Need help?

Need help?

Do you have a question about the MB2236 and is the answer not in the manual?

Questions and answers

Related Manuals for Lexmark MB2236

Summary of Contents for Lexmark MB2236

  • Page 1   MB2236 MFP   Service Manual    www.lexmark.com September 2024  ...

  • Page 2: Product Information

    Product information Product name: Lexmark MB2236adw MFP Machine type: 3400 Model(s): 481, 485...

  • Page 3: Edition Notice

    Evaluation and verification of operation in conjunction with other products, programs, or services, except those expressly designated by the manufacturer, are the user’s responsibility. Lexmark and the Lexmark logo are trademarks of Lexmark International, Inc., registered in the United States and/or other countries. PCL® is a registered trademark of the Hewlett-Packard Company. PCL is Hewlett-Packard ...

  • Page 4: Table Of Contents

    Service Manual Contents Product information ..................2 Edition notice....................3 Notices, conventions, and safety information Laser notice......................12 Avis relatif à l'utilisation du laser................12 Aviso de láser ......................12 Laser-Hinweis......................13 Conventions ......................13 Safety information ....................14 Consignes de sécurité....................15 Información de seguridad..................
  • Page 5 232 paper jams......................151 232 paper jam messages ....................151 Sensor (input sensor S3): Duplex failure service check ..........151 User attendance messages ................156 Non-Lexmark supply ....................156 8–12 user attendance messages ................157 8–12 user attendance messages ..................157 Manual feeder service check...................157 Auto reboot service check ....................159 31–33 user attendance messages ................
  • Page 6 Service Manual 34–41 user attendance messages ................168 34–41 user attendance messages ..................168 Scanner collation area service check ................168 Insufficient memory service check...................170 42 user attendance messages ................172 42 user attendance messages ..................172 Toner cartridge service check..................174 55 user attendance messages ................175 55 user attendance messages ..................175 Unsupported USB device service check .................175 71 user attendance messages ................
  • Page 7 Service menus Understanding the printer control panel ............267 Lexmark MB2236adw MFP ..................267 Lexmark MB2236adwe, Lexmark MB2236i MFPs ..........269 Understanding the status of the power button and indicator light ......269 Diagnostics menu....................270 Entering the Diagnostics menu ................270 Reports........................
  • Page 8 Service Manual Input tray quick print ....................273 Output bin quick feed ....................273 Printer Setup ......................273 Printed page count (mono) ....................273 Permanent page count ....................274 Processor ID ........................274 Serial number ........................274 Model name ........................274 Engine setting [x] ......................274 EP setup ..........................275 Printer diagnostics &...
  • Page 9 Service Manual Updating the printer firmware .................. 297 Using a flash drive ......................297 Using a network computer....................298 Using a USB cable connection ..................298 Backing up eSF solutions and settings ..............299 Ribbon cable connectors..................299 Zero Insertion Force (ZIF) connectors................299 Horizontal top contact connector ..................300 ............................301 Horizontal bottom contact connector ................302...
  • Page 10 Service Manual Sensor (paper present) removal................366 Sensor (staging and input) removal ................ 367 Input sensor flags removal ..................369 Pick rollers removal ....................371 ADF and scanner ....................373 Scanner stand removal ................... 373 ADF pick assembly removal..................374 ADF scanner (old) and flatbed scanner (old) removal ..........
  • Page 11 Service Manual POR sequence ....................425 Print cycle operation..................425 Print engine layout....................425 Print cycle........................ 426 Flowchart .........................426 Charge ..........................427 Expose..........................428 Develop ...........................429 Transfer ...........................430 Clean ..........................430 Fuse..........................431 Printer operation....................432 Printer sections......................432 Printer paper path....................433 Simplex print job ......................433 Duplex print job........................434 Printer paper path sensors ..................

  • Page 12: Notices, Conventions, And Safety Information

    Notices, conventions, and safety information   Notices, conventions, and safety information Laser notice The printer is certified in the U.S. to conform to the requirements of DHHS 21 CFR, Chapter I, Subchapter J for Class I (1) laser products, and elsewhere is certified as a Class I laser product conforming to the requirements of IEC 60825-1: 2014.

  • Page 13: Laser-Hinweis

    Notices, conventions, and safety information Los productos láser de Clase I no se consideran peligrosos. El sistema láser y la  impresora se han diseñado para que el ser humano no acceda nunca a las radiaciones láser por encima del nivel de Clase I durante su uso normal, ni en tareas de mantenimiento o intervenciones de servicio técnico prescritas. El conjunto de cabezal de impresión de la impresora no se puede reparar y contiene un láser con las siguientes especificaciones: Class: IIIb (3b) AlGaAs...

  • Page 14: Safety Information

    Notices, conventions, and safety information CAUTION—HOT SURFACE Indicates a risk of burn if touched. CAUTION—PINCH HAZARD Indicates a risk of being caught between moving parts. CAUTION—MOVING PARTS Indicates a risk of laceration or abrasion injuries from rotating parts. Safety information • The safety of this product is based on testing and approvals of the original design and specific components.

  • Page 15: Consignes De Sécurité

    CAUTION—POTENTIAL INJURY Only a Lexmark Inline Surge Protector that is properly connected between the printer and the power cord provided with the printer may be used with this product. The use of non-Lexmark surge protection devices may result in a risk of fire, property damage, or poor printer performance.
  • Page 16 CAUTION—POTENTIAL INJURY Utilisez uniquement un parasurtenseur correctement raccordé à l'imprimante et au câble d'alimentation fourni avec la machine. L'utilisation de parasurtenseurs non fabriqués par Lexmark comporte un risque d'incendie et de dégâts matériels, et peut amoindrir les performances de l'imprimante. CAUTION—POTENTIAL INJURY N'utilisez pas ce produit avec un parasurtenseur en ligne.

  • Page 17: Información De Seguridad

    Notices, conventions, and safety information CAUTION—POTENTIAL INJURY Si votre imprimante pèse plus de 20 kg (44 lb), l'intervention d'au moins  deux personnes est nécessaire pour la soulever sans risque. Información de seguridad • La seguridad de este producto se basa en las pruebas y comprobaciones del diseño original y los componentes específicos. El fabricante no se hace responsable de la seguridad en caso de uso de piezas de repuesto no autorizadas.

  • Page 18: Sicherheitshinweise

    Lexmark debidamente conectado entre la impresora y el cable de alimentación que con ella se suministra. El uso de protectores de sobretensión de marcas distintas a Lexmark puede dar lugar a que el rendimiento de la impresora sea bajo, a daños materiales o a posibles incendios.
  • Page 19 Brandgefahr, Beschädigung von Eigentum oder einer eingeschränkten Druckerleistung führen kann. CAUTION—POTENTIAL INJURY Mit diesem Produkt darf nur ein Lexmark Inline Surge Protector verwendet werden, der vorschriftsgemäß zwischen dem Drucker und dem mitgelieferten Netzkabel angeschlossen ist. Die Verwendung von nicht von Lexmark stammenden Überspannungsschutzgeräten kann zu Brandgefahr,...
  • Page 20 Notices, conventions, and safety information CAUTION—POTENTIAL INJURY Verwenden Sie dieses Produkt nicht mit einem Inline- Überspannungsschutz. Die Verwendung von Überspannungsschutzgeräten kann zu Brandgefahr, Beschädigung von Eigentum oder einer eingeschränkten Druckerleistung führen. CAUTION—POTENTIAL INJURY Wenn der Drucker mehr als 20 kg wiegt, sind zum sicheren Anheben  mindestens zwei Personen notwendig.

  • Page 21: Change History

    Change history   Change history Change history September 4, 2024 • Updated the Controller board connectors topic in the Component locations chapter. See Controller board connectors on page 398. • Updated the wiring diagram. See wiring diagram. August 9, 2024 •...
  • Page 22 Change history Covers (MB2236adw) on page 409. Covers (MB2236adwe, MB2236i) on page 411. November 29, 2022 • Added the topic group Securing the printer in the Diagnostics and troubleshooting chapter. It includes the topic Resetting the printer without admin credentials. See Resetting the printer without admin credentials on page October 6, 2022...
  • Page 23 Change history • Added an installation note in the ADF scanner and flatbed scanner removal topic in the Parts removal chapter. See ADF scanner (old) and flatbed scanner (old) removal on page 376. March 25, 2022 • Updated the 42 user attendance messages topic in the Diagnostics and troubleshooting chapter.
  • Page 24 Change history • Added the MB2236i top cover removal and ADF scanner and flatbed scanner removal topics in the Parts removal chapter. • Added Top cover (MB2236i) (41X2979) in the Parts catalog chapter. • Updated Entering the configurations menu topic in the Service menus chapter: •...
  • Page 25 Change history • Updated the Printhead removal topic in the Parts removal chapter. April 1, 2020 • Updated the description of PN 41X2467 in the Parts catalog chapter. July 15, 2019 • Added information for the MB2236adwe printer model. • Updated the following topics in the Service menus chapter: ◦...

  • Page 26: General Information

    General information   General information Printer model configurations The Lexmark™ MB2236adw, MB2236adwe and MB2236i are small, monochrome, network‑capable multifunction laser printers. Model Configurations Machine type/model MB2236adw Network-ready 3400‑481 monochrome laser printer with 2‑line LCD display,  wireless capability, analog fax, internal duplex printing, and simplex scanning for...

  • Page 27: Supported Paper Sizes, Types, And Weights

    General information Supported paper sizes, types, and weights Supported paper sizes Note: • Paper less than 210 mm (8.3 in.) wide always prints at reduced speed. • Use the manual feeder when printing on paper less than 105 mm (4.1 in.) wide. • The minimum paper dimension supported for two‑sided printing is 210 x 279.4 mm  (8.3 x 11 in.). • The maximum paper length supported by the scanner glass is 297 mm (11.7 in.). • For two-sided printing on letter‑, legal‑, or folio‑size paper, make sure that the paper  size setting in the duplex unit is set to Letter. Paper size 250‑sheet  Manual Two‑sided  Scanner Automatic tray feeder printing...
  • Page 28 General information Paper size 250‑sheet  Manual Two‑sided  Scanner Automatic tray feeder printing glass document feeder ✓ ✓ ✓ ✓ A5 (short edge feed) 148 x 210 mm  (5.83 x 8.27 in.) ✓ ✓ ✓ ✓ A5 (long edge feed) 210 x 148 mm  (8.27 x 5.83 in.) ✓ ✓ ✓ ✓ 105 x 148 mm  (4.13 x 5.83 in.) ✓...
  • Page 29 General information Paper size 250‑sheet  Manual Two‑sided  Scanner Automatic tray feeder printing glass document feeder ✓ ✓ ✓ ✓ Folio 215.9 x 330.2 mm  (8.5 x 13 in.) ✓ ✓ ✓ Universal 98 x 148 mm  (3.9 x 5.8 in.)  216 x 356 mm  (8.5 x 14 in.) ✓ ✓ ✓ ✓ Universal 105 x 148 mm  (4.1 x 5.8 in.)  216 x 356 mm  (8.5 x 14 in.) ✓ ✓...

  • Page 30: Supported Paper Types

    General information Paper size 250‑sheet  Manual Two‑sided  Scanner Automatic tray feeder printing glass document feeder ✓ ✓ Universal Envelope 98.4 x 162 mm  (3.87 x 6.38 in.)  176 x 250 mm  (6.93 x 9.84 in.) * This paper source supports paper size only up to 216 x 297 mm (8.5 x 11.7 in.). Supported paper types Note: Labels, envelopes, and card stock always print at reduced speed.

  • Page 31: Supported Fax

    ✓ ✓ MB2236i Needs a subscription. For more information, go to https://www.etherfax.net/lexmark contact the place where you purchased the printer. Needs an installed license bundle. For more information, contact the place where you purchased the printer. Tools required for service •...

  • Page 32: Diagnostics And Troubleshooting

    Diagnostics and troubleshooting   Diagnostics and troubleshooting Troubleshooting precautions CAUTION—SHOCK HAZARD When you see this symbol on the product, there is a danger from hazardous voltage in the area of the product where you are working. Unplug the product before you begin, or use caution if the product must receive power in order to perform the task.

  • Page 33: Précautions De Dépannage

    Diagnostics and troubleshooting CAUTION—MOVING PARTS To avoid the risk of laceration or abrasion injuries, keep hands away from moving parts in areas marked with this label. Injuries from moving parts may occur around gears and other rotating parts. Précautions de dépannage CAUTION—SHOCK HAZARD Ce symbole indique un danger lié...

  • Page 34: Precauciones Durante La Solución De Problemas

    Diagnostics and troubleshooting CAUTION—PINCH HAZARD Pour éviter tout risque de blessure par pincement, agissez avec précaution au niveau des zones signalées par cette étiquette. Les blessures par pincement peuvent se produire autour des pièces mobiles telles que les engrenages, portes, tiroirs et capots. CAUTION—MOVING PARTS Pour éviter tout risque de coupures ou de frottements, éloignez les mains des pièces en mouvement dans les zones signalées par cette étiquette.

  • Page 35: Vorsichtsmaßnahmen Bei Der Fehlerbehebung

    Diagnostics and troubleshooting CAUTION—HOT SURFACE El interior de la impresora podría estar caliente. Para evitar el riesgo de heridas producidas por el contacto con un componente caliente, deje que la superficie se enfríe antes de tocarlo. CAUTION—PINCH HAZARD Para evitar el riesgo de lesión por atrapamiento, preste atención en las áreas marcadas con esta etiqueta.

  • Page 36: Troubleshooting Overview

    Diagnostics and troubleshooting CAUTION—SHOCK HAZARD Um das Risiko eines elektrischen Schlags und Schäden am Drucker zu vermeiden, ziehen Sie das Netzkabel aus der Steckdose und trennen Sie alle Verbindungen zu jeglichen externen Geräten, bevor Sie Kabel, Elektronikplatinen oder Baugruppen einstecken oder abziehen. CAUTION—HOT SURFACE Das Innere des Druckers kann sehr heiß...

  • Page 37: Securing The Printer

    Diagnostics and troubleshooting Securing the printer Resetting the printer without admin credentials Note: • Resetting the printer or replacing the controller board deletes all security settings. • Before changing the security settings, ask permission from your administrator. Perform an Out of Service Erase to reset the printer to factory defaults without using admin credentials.

  • Page 38: Erasing Printer Memory

    Request the customer to sign the Customer Retention form. Note: You can get printed copies of the form from your Lexmark partner manager. Take a photo of the signed form, and then upload it to the Service Request debrief tool.

  • Page 39: Gray Or Solid Background Check

    Diagnostics and troubleshooting • On the Menu Settings page, check if the print resolution is set to 600 dpi and the toner darkness is set to Normal. • Check the toner cartridges for damage, and replace if necessary. • Make sure that the correct print driver is used to prevent print problems. If the wrong print driver is installed, then incorrect characters could print and the copy may not fit the page correctly.
  • Page 40 Diagnostics and troubleshooting Does the problem remain? ◦ Yes: Go to the next step. ◦ The problem is solved. Perform the following tests: Make sure that the toner cartridge is properly installed and free of damage. Make sure that the smart chip contacts are free of corrosion and contamination. Make sure that the developer roller surface is free of damage.
  • Page 41 Diagnostics and troubleshooting Check the HVPS toner contact spring for proper installation and damage. Check the toner smart chip contact for proper installation and damage. Check the toner contact spring for corrosion and contamination. Are the HVPS toner contact spring and toner smart chip contact properly installed and free of damage and contamination? ◦...
  • Page 42 Diagnostics and troubleshooting ◦ Yes: Go to the next step. ◦ The problem is solved. Replace the transfer roller. See Transfer roller removal on page 344. Does the problem remain? ◦ Yes: Go to the next step. ◦ The problem is solved. Adjust the toner darkness.
  • Page 43 Diagnostics and troubleshooting Is the LVPS properly installed and free of damage? ◦ Yes: Go to step 20. ◦ Go to the next step. Perform the following tests: Make sure that the LVPS is compatible with the fuser and the printer. Make sure that the fuser connector has voltage.

  • Page 44: Solid Color Or Black Image Check

    Diagnostics and troubleshooting Solid color or black image check Perform the following tests: Make sure that the toner cartridge is supported. Make sure that the toner cartridge and imaging unit are not empty. Check if the toner cartridge is new. Is the toner cartridge new? ◦...
  • Page 45 Diagnostics and troubleshooting Make sure that the imaging unit is properly installed and free of damage. Make sure that the smart chip contacts are free of corrosion and contamination. Make sure that the photoconductor roller surface is free of damage. Make sure that the imaging unit HVPS contacts are free of corrosion and contamination.
  • Page 46 Diagnostics and troubleshooting The problem is solved. Perform the following tests: Check the HVPS toner contact spring for proper installation and damage. Check the toner smart chip contact for proper installation and damage. Check the toner contact spring for corrosion and contamination. Are the HVPS toner contact spring and toner smart chip contact properly installed and free of damage and contamination? ◦...

  • Page 47: Blank Or White Pages Check

    Diagnostics and troubleshooting Blank or white pages check Perform the following tests: Make sure that the toner cartridge is supported. Make sure that the toner cartridge and imaging unit are not empty. Check if the toner cartridge is new. Is the toner cartridge new? ◦...
  • Page 48 Diagnostics and troubleshooting Make sure that the imaging unit is properly installed and free of damage. Make sure that the smart chip contacts are free of corrosion and contamination. Make sure that the photoconductor roller surface is free of damage. Make sure that the imaging unit HVPS contacts are free of corrosion and contamination.
  • Page 49 Diagnostics and troubleshooting Go to the next step. ◦ The problem is solved. Replace the transfer roller. See Transfer roller removal on page 344. Does the problem remain? ◦ Yes: Go to the next step. ◦ The problem is solved. Perform the following tests: Make sure that the toner cartridge is properly installed and free of damage.
  • Page 50 Diagnostics and troubleshooting ◦ Yes: Contact the next level of support. ◦ The problem is solved. Perform the following tests: Clean the printhead lens. Reseat the two printhead cables at both ends. Perform a print test. Does the problem remain? ◦...
  • Page 51 Diagnostics and troubleshooting Perform the following tests: Check the HVPS characterization. Reseat the HVPS cables. Check the HVPS cables for proper installation and damage. Check the HVPS spring contact for proper connection to the board. Is the HVPS properly installed and free of damage? ◦...

  • Page 52: Dark Print Check

    Diagnostics and troubleshooting Dark print check Perform the following tests: Make sure that the toner cartridge is supported. Make sure that the toner cartridge and imaging unit are not empty. Check if the toner cartridge is new. Is the toner cartridge new? ◦...
  • Page 53 Diagnostics and troubleshooting Make sure that the paper type is supported. Make sure that the paper type and size settings match the paper type and size set on the tray. Make sure that the paper has no damage or defects. Make sure that the paper guides are properly set.
  • Page 54 Diagnostics and troubleshooting ◦ Yes: Go to the next step. ◦ The problem is solved. Replace the imaging unit. Does the problem remain? ◦ Yes: Go to the next step. ◦ The problem is solved. Perform the following tests: Check the HVPS toner contact spring for proper installation and damage. Check the toner smart chip contact for proper installation and damage.
  • Page 55 Diagnostics and troubleshooting Enter the Diagnostics menu, and then select Advanced Print Quality Samples. Does the problem remain? ◦ Yes: Go to the next step. ◦ The problem is solved. Perform the following tests: Reseat the transfer roller. Enter the Diagnostics menu, and then select Advanced Print Quality Samples. Does the problem remain? ◦...

  • Page 56: Light Print Check

    Diagnostics and troubleshooting ◦ Yes: Contact the next level of support. ◦ Go to the next step. Replace the HVPS. See HVPS removal on page 327. Note: Make sure to perform the HVPS characterization when replacing the HVPS. Does the problem remain? ◦...
  • Page 57 Diagnostics and troubleshooting Perform the following tests: Clear the paper path of debris and contamination. Remove, and then insert the imaging unit and toner cartridge. Note: Shake the toner cartridge and imaging unit before inserting them. Perform a POR. Enter the Diagnostics menu, and then select Advanced Print Quality Samples. Does the problem remain? ◦...
  • Page 58 Diagnostics and troubleshooting The problem is solved. Replace the toner cartridge. Does the problem remain? ◦ Yes: Go to the next step. ◦ The problem is solved. Perform the following tests: Make sure that the imaging unit is properly installed and free of damage. Make sure that the smart chip contacts are free of corrosion and contamination.
  • Page 59 Diagnostics and troubleshooting ◦ Yes: Contact the next level of support. ◦ The problem is solved. Perform the following tests: Check the imaging unit contact spring for damage and contamination. Make sure that the imaging unit contact spring is in proper contact with the HVPS. Is the imaging unit contact spring properly installed and free of damage and contamination? ◦...
  • Page 60 Diagnostics and troubleshooting ◦ Yes: Go to the next step. ◦ The problem is solved. Perform the following tests: Make sure that the printhead cables are properly connected. Check the printhead for proper installation and damage. Is the printhead properly installed and free of damage? ◦...

  • Page 61: Paper Curl Check

    Diagnostics and troubleshooting Go to the next step. Replace the HVPS. See HVPS removal on page 327. Note: Make sure to perform the HVPS characterization when replacing the HVPS. Does the problem remain? ◦ Yes: Contact the next level of support. ◦...
  • Page 62 Diagnostics and troubleshooting Make sure that the paper has no damage or defects. Make sure that the paper guides are properly set. Make sure that the paper size setting in the duplex unit is properly set. Does the problem remain? ◦...

  • Page 63: Folded Or Wrinkled Paper Check

    Diagnostics and troubleshooting Check the LVPS for proper installation and damage. Is the LVPS properly installed and free of damage? ◦ Yes: Contact the next level of support. ◦ Go to the next step. Perform the following tests: Make sure that the LVPS is compatible with the fuser and the printer. Make sure that the fuser connector has voltage.
  • Page 64 Diagnostics and troubleshooting Enter the Diagnostics menu, and then select Advanced Print Quality Samples. Does the problem remain? ◦ Yes: Go to the next step. ◦ The problem is solved. Perform the following tests: Make sure that the paper type is supported. Make sure that the paper type and size settings match the paper type and size set on the tray.
  • Page 65 Diagnostics and troubleshooting Does the problem remain? ◦ Yes: Go to the next step. ◦ The problem is solved. Perform the following tests: Reseat all the cables connected to the LVPS. Check the cables for proper connection and damage. Check the fuse for continuity. Check the electronic components on the LVPS for damage.

  • Page 66: Repeating Defects Check

    Diagnostics and troubleshooting Repeating defects check Perform the following tests: Make sure that the toner cartridge is supported. Make sure that the toner cartridge and imaging unit are not empty. Check if the toner cartridge is new. Is the toner cartridge new? ◦...
  • Page 67 Diagnostics and troubleshooting Is the distance equal to 75.4 mm or 34.7 mm? ◦ Yes: Go to the next step. ◦ Go to step 6. Replace the imaging unit. Does the problem remain? ◦ Yes: Go to the next step. ◦...
  • Page 68 Diagnostics and troubleshooting The problem is solved. Perform the following tests: Make sure that the toner cartridge is properly installed and free of damage. Make sure that the smart chip contacts are free of corrosion and contamination. Make sure that the developer roller surface is free of damage. Make sure that the toner HVPS contacts are free of corrosion and contamination.
  • Page 69 Diagnostics and troubleshooting Perform the following tests: Reseat the transfer roller. Enter the Diagnostics menu, and then select Advanced Print Quality Samples. Does the problem remain? ◦ Yes: Go to the next step. ◦ The problem is solved. Replace the transfer roller. See Transfer roller removal on page 344.
  • Page 70 Diagnostics and troubleshooting Select Motor (transport). Open the rear door, and then check if the fuser exit rollers turn. Open the fuser access door, and then check if the hot rollers turn. Are the rollers properly working? ◦ Yes: Go to step 22. ◦...

  • Page 71: Skewed Print Check

    Diagnostics and troubleshooting Skewed print check Perform the following tests: Clear the paper path of debris and contamination. Remove, and then insert the imaging unit and toner cartridge. Note: Shake the toner cartridge and imaging unit before inserting them. Perform a POR. Enter the Diagnostics menu, and then select Advanced Print Quality Samples.
  • Page 72 Diagnostics and troubleshooting Is the tray insert properly installed and free of damage? ◦ Yes: Go to step 5. ◦ Go to the next step. Replace the tray insert. Does the problem remain? ◦ Yes: Go to the next step. ◦...

  • Page 73: Streaked Vertical Lines Appear On Prints Check

    Diagnostics and troubleshooting Perform the following tests: Clean the printhead lens. Reseat the two printhead cables at both ends. Perform a print test. Does the problem remain? ◦ Yes: Go to the next step. ◦ The problem is solved. Perform the following tests: Make sure that the printhead cables are properly connected.
  • Page 74 Diagnostics and troubleshooting ◦ Yes: Go to the next step. ◦ Go to step 3. Make sure to remove the packing material on the toner cartridge and imaging unit. Does the problem remain? ◦ Yes: Go to the next step. ◦...
  • Page 75 Diagnostics and troubleshooting Does the problem remain? ◦ Yes: Go to the next step. ◦ The problem is solved. Perform the following tests: Make sure that the imaging unit is properly installed and free of damage. Make sure that the smart chip contacts are free of corrosion and contamination. Make sure that the photoconductor roller surface is free of damage.
  • Page 76 Diagnostics and troubleshooting Check the HVPS toner contact spring for proper installation and damage. Check the toner smart chip contact for proper installation and damage. Check the toner contact spring for corrosion and contamination. Are the HVPS toner contact spring and toner smart chip contact properly installed and free of damage and contamination? ◦...
  • Page 77 Diagnostics and troubleshooting ◦ Yes: Go to the next step. ◦ The problem is solved. Replace the transfer roller. See Transfer roller removal on page 344. Does the problem remain? ◦ Yes: Go to the next step. ◦ The problem is solved. Perform the following tests: Reseat the HVPS cables.

  • Page 78: Horizontal White Lines Check

    Diagnostics and troubleshooting Contact the next level of support. ◦ The problem is solved. Horizontal white lines check Perform the following tests: Make sure that the toner cartridge is supported. Make sure that the toner cartridge and imaging unit are not empty. Check if the toner cartridge is new.
  • Page 79 Diagnostics and troubleshooting Go to the next step. ◦ The problem is solved. Perform the following tests: Make sure that the imaging unit is properly installed and free of damage. Make sure that the smart chip contacts are free of corrosion and contamination. Make sure that the photoconductor roller surface is free of damage.
  • Page 80 Diagnostics and troubleshooting Are the HVPS toner contact spring and toner smart chip contact properly installed and free of damage and contamination? ◦ Yes: Go to step 10. ◦ Go to the next step. Perform the following tests: Make sure that the HVPS toner contact spring is in proper contact with the toner cartridge.
  • Page 81 Diagnostics and troubleshooting ◦ The problem is solved. Replace the transfer roller. See Transfer roller removal on page 344. Does the problem remain? ◦ Yes: Go to the next step. ◦ The problem is solved. Perform the following tests: Clean the printhead lens. Reseat the two printhead cables at both ends.

  • Page 82: Vertical White Lines Check

    Diagnostics and troubleshooting ◦ Yes: Contact the next level of support. ◦ The problem is solved. Perform the following tests: Check the HVPS characterization. Reseat the HVPS cables. Check the HVPS cables for proper installation and damage. Check the HVPS spring contact for proper connection to the board. Is the HVPS properly installed and free of damage? ◦...
  • Page 83 Diagnostics and troubleshooting ◦ Yes: Go to the next step. ◦ Go to step 3. Make sure to remove the packing material on the toner cartridge and imaging unit. Does the problem remain? ◦ Yes: Go to the next step. ◦...
  • Page 84 Diagnostics and troubleshooting Does the problem remain? ◦ Yes: Go to the next step. ◦ The problem is solved. Perform the following tests: Make sure that the imaging unit is properly installed and free of damage. Make sure that the smart chip contacts are free of corrosion and contamination. Make sure that the photoconductor roller surface is free of damage.
  • Page 85 Diagnostics and troubleshooting Check the HVPS toner contact spring for proper installation and damage. Check the toner smart chip contact for proper installation and damage. Check the toner contact spring for corrosion and contamination. Are the HVPS toner contact spring and toner smart chip contact properly installed and free of damage and contamination? ◦...
  • Page 86 Diagnostics and troubleshooting ◦ Yes: Go to the next step. ◦ The problem is solved. Replace the transfer roller. See Transfer roller removal on page 344. Does the problem remain? ◦ Yes: Go to the next step. ◦ The problem is solved. Perform the following tests: Reseat the HVPS cables.

  • Page 87: Vertical Colored Lines Or Banding Check

    Diagnostics and troubleshooting Contact the next level of support. ◦ The problem is solved. Vertical colored lines or banding check Perform the following tests: Make sure that the toner cartridge is supported. Make sure that the toner cartridge and imaging unit are not empty. Check if the toner cartridge is new.
  • Page 88 Diagnostics and troubleshooting Go to the next step. ◦ The problem is solved. Perform the following tests: Clean the printhead lens. Reseat the two printhead cables at both ends. Perform a print test. Does the problem remain? ◦ Yes: Go to the next step. ◦...
  • Page 89 Diagnostics and troubleshooting Go to the next step. ◦ The problem is solved. Perform the following tests: Make sure that the toner cartridge is properly installed and free of damage. Make sure that the smart chip contacts are free of corrosion and contamination. Make sure that the developer roller surface is free of damage.
  • Page 90 Diagnostics and troubleshooting Is the imaging unit contact spring properly installed and free of damage and contamination? ◦ Yes: Contact the next level of support. ◦ The problem is solved. Perform the following tests: Make sure that the transfer roller is properly installed and free of damage and contamination.

  • Page 91: Vertical Dark Streaks With Print Missing Check

    Diagnostics and troubleshooting ◦ Yes: Contact the next level of support. ◦ The problem is solved. Perform the following tests: Check the HVPS characterization. Reseat the HVPS cables. Check the HVPS cables for proper installation and damage. Check the HVPS spring contact for proper connection to the board. Is the HVPS properly installed and free of damage? ◦...
  • Page 92 Diagnostics and troubleshooting ◦ Yes: Go to the next step. ◦ Go to step 3. Make sure to remove the packing material on the toner cartridge and imaging unit. Does the problem remain? ◦ Yes: Go to the next step. ◦...
  • Page 93 Diagnostics and troubleshooting Does the problem remain? ◦ Yes: Go to the next step. ◦ The problem is solved. Perform the following tests: Make sure that the imaging unit is properly installed and free of damage. Make sure that the smart chip contacts are free of corrosion and contamination. Make sure that the photoconductor roller surface is free of damage.
  • Page 94 Diagnostics and troubleshooting Check the HVPS toner contact spring for proper installation and damage. Check the toner smart chip contact for proper installation and damage. Check the toner contact spring for corrosion and contamination. Are the HVPS toner contact spring and toner smart chip contact properly installed and free of damage and contamination? ◦...
  • Page 95 Diagnostics and troubleshooting ◦ Yes: Go to the next step. ◦ The problem is solved. Replace the transfer roller. See Transfer roller removal on page 344. Does the problem remain? ◦ Yes: Go to the next step. ◦ The problem is solved. Perform the following tests: Reseat the HVPS cables.

  • Page 96: White Streaks And Voided Areas Check

    Diagnostics and troubleshooting Contact the next level of support. ◦ The problem is solved. White streaks and voided areas check Perform the following tests: Make sure that the toner cartridge is supported. Make sure that the toner cartridge and imaging unit are not empty. Check if the toner cartridge is new.
  • Page 97 Diagnostics and troubleshooting Go to the next step. ◦ The problem is solved. Perform the following tests: Make sure that the imaging unit is properly installed and free of damage. Make sure that the smart chip contacts are free of corrosion and contamination. Make sure that the photoconductor roller surface is free of damage.
  • Page 98 Diagnostics and troubleshooting Are the HVPS toner contact spring and toner smart chip contact properly installed and free of damage and contamination? ◦ Yes: Go to step 10. ◦ Go to the next step. Perform the following tests: Make sure that the HVPS toner contact spring is in proper contact with the toner cartridge.
  • Page 99 Diagnostics and troubleshooting ◦ The problem is solved. Replace the transfer roller. See Transfer roller removal on page 344. Does the problem remain? ◦ Yes: Go to the next step. ◦ The problem is solved. Perform the following tests: Clean the printhead lens. Reseat the two printhead cables at both ends.

  • Page 100: Clipped Pages Or Images Check

    Diagnostics and troubleshooting ◦ Yes: Contact the next level of support. ◦ The problem is solved. Perform the following tests: Check the HVPS characterization. Reseat the HVPS cables. Check the HVPS cables for proper installation and damage. Check the HVPS spring contact for proper connection to the board. Is the HVPS properly installed and free of damage? ◦...
  • Page 101 Diagnostics and troubleshooting ◦ Yes: Go to the next step. ◦ Go to step 3. Make sure to remove the packing material on the toner cartridge and imaging unit. Does the problem remain? ◦ Yes: Go to the next step. ◦...
  • Page 102 Diagnostics and troubleshooting Perform the following tests: Make sure that the toner cartridge is properly installed and free of damage. Make sure that the smart chip contacts are free of corrosion and contamination. Make sure that the developer roller surface is free of damage. Make sure that the toner HVPS contacts are free of corrosion and contamination.
  • Page 103 Diagnostics and troubleshooting ◦ Yes: Contact the next level of support. ◦ The problem is solved. Perform the following tests: Make sure that the transfer roller is properly installed and free of damage and contamination. Make sure that the HVPS contact spring is properly connected to the transfer roller. Make sure that the transfer roller spring is properly installed.
  • Page 104 Diagnostics and troubleshooting ◦ Yes: Go to step 17. ◦ Go to the next step. Replace the printhead. See .Printhead removal on page 363 Does the problem remain? ◦ Yes: Go to the next step. ◦ The problem is solved. Perform the following tests: Reseat the HVPS cables.

  • Page 105: Compressed Images Appear On Prints Check

    Diagnostics and troubleshooting Go to the next step. ◦ The problem is solved. Perform the following tests: Reseat all the cables connected to the LVPS. Check the cables for proper connection and damage. Check the fuse for continuity. Check the electronic components on the LVPS for damage. Check the LVPS for proper installation and damage.
  • Page 106 Diagnostics and troubleshooting Perform the following tests: Clear the paper path of debris and contamination. Remove, and then insert the imaging unit and toner cartridge. Note: Shake the toner cartridge and imaging unit before inserting them. Perform a POR. Enter the Diagnostics menu, and then select Advanced Print Quality Samples. Does the problem remain? ◦...
  • Page 107 Diagnostics and troubleshooting Open the front door. Remove the imaging unit. Remove the toner cartridge from the imaging unit. Slightly close the front door, and then check if the lever actuates the imaging unit drive gear. Did the imaging unit drive gear actuate? ◦...
  • Page 108 Diagnostics and troubleshooting Go to the next step. ◦ The problem is solved. Replace the transfer roller. See Transfer roller removal on page 344. Does the problem remain? ◦ Yes: Go to the next step. ◦ The problem is solved. Make sure that the roller is free of dirt and contamination.

  • Page 109: Incorrect Margins On Prints Check

    Diagnostics and troubleshooting Perform the following tests: Enter the Diagnostics menu, and then navigate to: Input tray quick print > Tray 1 > Single Enter the Diagnostics menu, and then navigate to: Input tray quick print > Duplex > Single Does the problem remain? ◦...
  • Page 110 Diagnostics and troubleshooting Remove, and then insert the imaging unit and toner cartridge. Note: Shake the toner cartridge and imaging unit before inserting them. Perform a POR. Enter the Diagnostics menu, and then select Advanced Print Quality Samples. Does the problem remain? ◦...
  • Page 111 Diagnostics and troubleshooting Printer diagnostics & adjustments > Registration adjust Select Quick test or Duplex quick test. Adjust the following margins: ▪ Top Margin ▪ Bottom Margin ▪ Left Margin ▪ Right Margin Does the problem remain? ◦ Yes: Go to the next step. ◦...

  • Page 112: Toner Rubs Off Check

    Diagnostics and troubleshooting ◦ Yes: Contact the next level of support. ◦ Go to the next step. Replace the controller board. See .Controller board removal on page 322 Does the problem remain? ◦ Yes: Contact the next level of support. ◦...
  • Page 113 Diagnostics and troubleshooting Note: Shake the toner cartridge and imaging unit before inserting them. Perform a POR. Enter the Diagnostics menu, and then select Advanced Print Quality Samples. Does the problem remain? ◦ Yes: Go to the next step. ◦ The problem is solved.

  • Page 114: Toner Specks Appear On Prints Check

    Diagnostics and troubleshooting Perform the following tests: Reseat all the cables connected to the LVPS. Check the cables for proper connection and damage. Check the fuse for continuity. Check the electronic components on the LVPS for damage. Check the LVPS for proper installation and damage. Is the LVPS properly installed and free of damage? ◦...
  • Page 115 Diagnostics and troubleshooting Is the toner cartridge new? ◦ Yes: Go to the next step. ◦ Go to step 3. Make sure to remove the packing material on the toner cartridge and imaging unit. Does the problem remain? ◦ Yes: Go to the next step.
  • Page 116 Diagnostics and troubleshooting ◦ The problem is solved. Perform the following tests: Make sure that the toner cartridge is properly installed and free of damage. Make sure that the smart chip contacts are free of corrosion and contamination. Make sure that the developer roller surface is free of damage. Make sure that the toner HVPS contacts are free of corrosion and contamination.
  • Page 117 Diagnostics and troubleshooting Is the imaging unit contact spring properly installed and free of damage and contamination? ◦ Yes: Contact the next level of support. ◦ The problem is solved. Perform the following tests: Make sure that the transfer roller is properly installed and free of damage and contamination.

  • Page 118: Paper Jams

    Diagnostics and troubleshooting Check the printhead for proper installation and damage. Is the printhead properly installed and free of damage? ◦ Yes: Contact the next level of support. ◦ Go to the next step. Replace the printhead. See .Printhead removal on page 363 Does the problem remain? ◦...

  • Page 119: 200 Paper Jams

    Diagnostics and troubleshooting • Make sure that the paper guides are positioned correctly and are not pressing tightly against the paper or envelopes. • Push the tray firmly into the printer after loading paper. Use recommended paper • Use only recommended paper or specialty media. •...

  • Page 120: Sensor (Input Sensor S3) Static Jam Service Check

    Diagnostics and troubleshooting Error code Description Action 200.05 Paper fed from the manual feeder never cleared the sensor (input sensor S3). 200.06 Paper fed from the manual feeder was not picked. Paper did not reach the sensor (input sensor S3). 200.07 Paper reached the sensor (input sensor S3) earlier...
  • Page 121 Diagnostics and troubleshooting ◦ Yes: Go to the next step. ◦ The problem is solved. Perform the following tests: Remove the imaging unit and toner cartridge, and then make sure that the paper path is free of jams and obstructions. Clear all rollers of dirt and contamination.
  • Page 122 Diagnostics and troubleshooting Go to the next step. Replace the sensor. Does the problem remain? ◦ Yes: Go to the next step. ◦ The problem is solved. Perform the following tests: Enter the Diagnostics menu, and then navigate to: Printer diagnostics & adjustment > Sensor tests Find the following sensors: ▪...

  • Page 123: Sensor (Input Sensor S3) Service Check

    Diagnostics and troubleshooting Go to the next step. Replace the damaged cable. Does the problem remain? ◦ Yes: Go to the next step. ◦ The problem is solved. Perform the following tests: Reseat all the cables on the controller board. Check if the controller board LED lights up.
  • Page 124 Diagnostics and troubleshooting Clear all rollers of dirt and contamination. Does the problem remain? ◦ Yes: Go to the next step. ◦ The problem is solved. Perform the following tests: Perform a POR. Enter the Diagnostics menu, and then navigate to: Input tray quick print >...
  • Page 125 Diagnostics and troubleshooting The problem is solved. Perform the following tests: Enter the Diagnostics menu, and then navigate to: Printer diagnostics & adjustment > Sensor tests Find the following sensors: ▪ Sensor (media present in tray1 S1) ▪ Sensor (input sensor S3) ▪...
  • Page 126 Diagnostics and troubleshooting ◦ Yes: Contact the next level of support. ◦ The problem is solved. Check the cables for proper connection and damage. Are the cables properly connected and free of damage? ◦ Yes: Go to step 14. ◦ Go to the next step.

  • Page 127: 202 Paper Jams

    Diagnostics and troubleshooting Does the problem remain? ◦ Yes: Go to the next step. ◦ The problem is solved. Replace the main drive. See Main drive removal on page 331. Does the problem remain? ◦ Yes: Go to the next step. ◦...

  • Page 128: Sensor (Fuser Exit Sensor S4) Service Check

    Diagnostics and troubleshooting Error code Description Action 202.13 Paper fed from tray 1 never Sensor (fuser exit arrived at the sensor (fuser sensor S4) service check exit sensor S4). on page 128. 202.15 Paper fed from tray 1 never Sensor (fuser exit arrived at the sensor (fuser sensor S4) never cleared exit sensor S4).
  • Page 129 Diagnostics and troubleshooting Input tray quick print > Tray 1 > Single Does the problem remain? ◦ Yes: Go to the next step. ◦ The problem is solved. Perform the following tests: Enter the Diagnostics menu, and then navigate to: Printer diagnostics &...
  • Page 130 Diagnostics and troubleshooting ◦ Yes: Go to step 10. ◦ Go to the next step. Perform the following tests: Check the sensor flags for proper installation and damage. Check the sensor flags for proper alignment with the sensors. Check the sensor flag springs for proper installation and damage. Are the sensor flags properly installed and free of damage? ◦...
  • Page 131 Diagnostics and troubleshooting ◦ Go to step 14. Perform the following tests: Check the fuser cables for proper connection and damage. Check the fuser access door for damage. Check if the fuser gears are in proper contact with the drive gears. Make sure that the fuser is compatible with the LVPS.
  • Page 132 Diagnostics and troubleshooting Reseat the deskew solenoid cable at both ends. Does the problem remain? ◦ Yes: Contact the next level of support. ◦ The problem is solved. Perform the following tests: Enter the Diagnostics menu, and then navigate to: Printer diagnostics &...

  • Page 133: Sensor (Fuser Exit Sensor S4) Never Cleared Service Check

    Diagnostics and troubleshooting ◦ The problem is solved. Perform the following tests: Reseat all the cables on the controller board. Check if the controller board LED lights up. Check the controller board for proper installation and damage. Is the controller board properly installed and free of damage? ◦...
  • Page 134 Diagnostics and troubleshooting The problem is solved. Perform the following tests: Perform a POR. Enter the Diagnostics menu, and then navigate to: Input tray quick print > Tray 1 > Single Does the problem remain? ◦ Yes: Go to the next step. ◦...
  • Page 135 Diagnostics and troubleshooting ▪ Sensor (input sensor S3) ▪ Sensor (fuser exit sensor S4) Does the sensor status change while toggling the sensor? ◦ Yes: Go to step 10. ◦ Go to the next step. Perform the following tests: Check the sensor flags for proper installation and damage. Check the sensor flags for proper alignment with the sensors.
  • Page 136 Diagnostics and troubleshooting Are the rollers properly working? ◦ Yes: Go to the next step. ◦ Go to step 14. Perform the following tests: Check the fuser cables for proper connection and damage. Check the fuser access door for damage. Check if the fuser gears are in proper contact with the drive gears.
  • Page 137 Diagnostics and troubleshooting ◦ Yes: Go to step 20. ◦ Go to the next step. Perform the following tests: Make sure that the redrive gears are in proper contact with the printer drive gears. Check the redrive gears for proper installation and damage. Check the roller for wear, contamination, and damage.

  • Page 138: Sensor (Fuser Exit Sensor S4) Static Jam Service Check

    Diagnostics and troubleshooting Make sure that the main drive is properly installed and free of damage. Make sure that the main drive gears are properly installed. Make sure that the drive gears are in proper contact with the gear they are driving. Does the problem remain? ◦...
  • Page 139 Diagnostics and troubleshooting ◦ Yes: Go to the next step. ◦ The problem is solved. Perform the following tests: Remove the imaging unit and toner cartridge, and then make sure that the paper path is free of jams and obstructions. Clear all rollers of dirt and contamination.
  • Page 140 Diagnostics and troubleshooting Replace the sensor. See Sensor (fuser exit) removal on page 365. Does the problem remain? ◦ Yes: Go to the next step. ◦ The problem is solved. Perform the following tests: Enter the Diagnostics menu, and then navigate to: Printer diagnostics &...

  • Page 141: 206 Paper Jams

    Diagnostics and troubleshooting Replace the damaged cable. Does the problem remain? ◦ Yes: Go to the next step. ◦ The problem is solved. Perform the following tests: Reseat all the cables on the controller board. Check if the controller board LED lights up. Check the controller board for proper installation and damage.
  • Page 142 Diagnostics and troubleshooting Make sure that the duplex unit is properly inserted. Make sure that the paper size setting in the duplex unit matches the printer setting. Make sure that the front and rear doors are fully closed. Make sure that the output bin is free from obstructions. Does the problem remain? ◦...
  • Page 143 Diagnostics and troubleshooting Check the sensor cable for proper connection and damage. Is the sensor properly installed and free of damage? ◦ Yes: Go to step 7. ◦ Go to the next step. Replace the sensor. Does the problem remain? ◦...
  • Page 144 Diagnostics and troubleshooting Check the cables for proper connection and damage. Are the cables properly connected and free of damage? ◦ Yes: Go to step 12. ◦ Go to the next step. Replace the damaged cable. Does the problem remain? ◦...
  • Page 145 Diagnostics and troubleshooting Enter the Diagnostics menu, and then navigate to: Input tray quick print > Duplex > Single Does the problem remain? ◦ Yes: Go to the next step. ◦ The problem is solved. Perform the following tests: Make sure that the main drive is properly installed and free of damage. Make sure that the main drive gears are properly installed.

  • Page 146: Sensor (Staging Sensor S2): Paper Failed To Arrive Service Check

    Diagnostics and troubleshooting Sensor (staging sensor S2): Paper failed to arrive service check Perform the following tests: Make sure that the tray insert is properly inserted. Make sure that the paper type and size settings match the paper type and size set on the tray.
  • Page 147 Diagnostics and troubleshooting ◦ Yes: Go to step 7. ◦ Go to the next step. Perform the following tests: Check the sensor for proper installation and damage. Check the alignment with the sensor flag. Check the sensor cable for proper connection and damage. Is the sensor properly installed and free of damage? ◦...
  • Page 148 Diagnostics and troubleshooting Replace the damaged sensor flag. Does the problem remain? ◦ Yes: Go to the next step. ◦ The problem is solved. Check the cables for proper connection and damage. Are the cables properly connected and free of damage? ◦...
  • Page 149 Diagnostics and troubleshooting Go to the next step. ◦ The problem is solved. Perform the following tests: Reseat the pick solenoid cable. Enter the Diagnostics menu, and then navigate to: Printer diagnostics & adjustments > Motor tests Select Feed solenoid. Check if the pick solenoid actuates.
  • Page 150 Diagnostics and troubleshooting Input tray quick print > Duplex > Single Does the problem remain? ◦ Yes: Go to the next step. ◦ The problem is solved. Perform the following tests: Make sure that the main drive is properly installed and free of damage. Make sure that the main drive gears are properly installed.

  • Page 151: 232 Paper Jams

    Diagnostics and troubleshooting 232 paper jams 232 paper jam messages Error code Description Action 232.13 Paper fed from tray 1 never Sensor (input sensor arrived at the sensor (input S3): Duplex failure service sensor S3) during a duplex check on page 151.
  • Page 152 Diagnostics and troubleshooting Input tray quick print > Tray 1 > Single Does the problem remain? ◦ Yes: Go to the next step. ◦ The problem is solved. Perform the following tests: Reseat the sensor cable. Enter the Diagnostics menu, and then navigate to: Printer diagnostics &...
  • Page 153 Diagnostics and troubleshooting Does the sensor status change while toggling the sensor? ◦ Yes: Go to step 10. ◦ Go to the next step. Perform the following tests: Check the sensor flags for proper installation and damage. Check the sensor flags for proper alignment with the sensors. Check the sensor flag springs for proper installation and damage.
  • Page 154 Diagnostics and troubleshooting Enter the Diagnostics menu, and then navigate to: Input tray quick print > Tray 1 > Duplex Does the problem remain? ◦ Yes: Go to the next step. ◦ The problem is solved. Perform the following tests: Reseat the duplex unit.
  • Page 155 Diagnostics and troubleshooting ◦ Yes: Go to the next step. ◦ Go to step 19. Perform the following tests: Enter the Diagnostics menu, and then navigate to: Input tray quick print > Tray 1 > Single Enter the Diagnostics menu, and then navigate to: Input tray quick print >...

  • Page 156: User Attendance Messages

    Use of third-party supplies or parts may affect the performance, reliability, or life of the printer and its imaging components. All life indicators are designed to function with Lexmark supplies and parts and may deliver unpredictable results if third-party supplies or parts are used. Imaging component usage beyond the intended life may damage the Lexmark printer or associated components.

  • Page 157: 8-12 User Attendance Messages

    Change the paper in the Manual feeder service manual feeder. check on page 157. Manual feeder service check Make sure that the imaging unit and toner cartridge are genuine Lexmark supplies. Does the problem remain? ◦ Yes: Go to the next step. ◦...
  • Page 158 Diagnostics and troubleshooting ◦ The problem is solved. Replace the toner cartridge. Does the problem remain? ◦ Yes: Go to the next step. ◦ The problem is solved. Perform the following tests: Shake the imaging unit. Clean the imaging unit smart chip contacts, and then check the contacts for damage. Clean the imaging unit spring contacts, and then check the contacts for damage.

  • Page 159: Auto Reboot Service Check

    Diagnostics and troubleshooting Check the cables for proper connection and damage. Are the cables properly connected and free of damage? ◦ Yes: Go to step 10. ◦ Go to the next step. Replace the damaged cable. Does the problem remain? ◦...
  • Page 160 Diagnostics and troubleshooting Perform the following tests: Upgrade the firmware. Note: Contact your next level of support for the correct firmware level to use. Perform a POR. Perform a print test. Does the problem remain? ◦ Yes: Go to the next step. ◦...

  • Page 161: 31-33 User Attendance Messages

    Program (NLRP) codes. toner cartridge service check on page 161. Photoconductor and toner cartridge service check Make sure that the imaging unit and toner cartridge are genuine Lexmark supplies. Does the problem remain? ◦ Yes: Go to the next step.
  • Page 162 Diagnostics and troubleshooting The problem is solved. Replace the toner cartridge. Does the problem remain? ◦ Yes: Go to the next step. ◦ The problem is solved. Perform the following tests: Shake the imaging unit. Clean the imaging unit smart chip contacts, and then check the contacts for damage. Clean the imaging unit spring contacts, and then check the contacts for damage.

  • Page 163: Black Imaging Unit, Photoconductor Smart Chip, Or Sensor Problem Service Check

    Diagnostics and troubleshooting Are the cables properly connected and free of damage? ◦ Yes: Go to step 10. ◦ Go to the next step. Replace the damaged cable. Does the problem remain? ◦ Yes: Go to the next step. ◦ The problem is solved.
  • Page 164 Diagnostics and troubleshooting Shake the toner cartridge. Clean the toner cartridge smart chip contacts, and then check the contacts for damage. Clean the toner cartridge spring contacts, and then check the contacts for damage. Perform a print test. Does the problem remain? ◦...
  • Page 165 Diagnostics and troubleshooting Check the front door hinge for damage. Check if the front door properly closes. Is the front door properly installed and free of damage? ◦ Yes: Go to step 9. ◦ Go to the next step. Replace the front door. See .Rear door removal on page 345 Does the problem remain? ◦...

  • Page 166: Unsupported Imaging Unit Or Toner Cartridge Service Check

    Does the problem remain? ◦ Yes: Contact the next level of support. ◦ The problem is solved. Unsupported imaging unit or toner cartridge service check Make sure that the imaging unit and toner cartridge are genuine Lexmark supplies. Does the problem remain? ◦ Yes: Go to the next step. ◦ The problem is solved.
  • Page 167 Diagnostics and troubleshooting Clean the imaging unit smart chip contacts, and then check the contacts for damage. Clean the imaging unit spring contacts, and then check the contacts for damage. Perform a print test. Does the problem remain? ◦ Yes: Go to the next step.

  • Page 168: 34-41 User Attendance Messages

    Diagnostics and troubleshooting Go to the next step. Replace the controller board. See .Controller board removal on page 322 Does the problem remain? ◦ Yes: Contact the next level of support. ◦ The problem is solved. 34–41 user attendance messages 34–41 user attendance messages Error code Description Action Paper size mismatch (too...
  • Page 169 Diagnostics and troubleshooting Go to the next step. ◦ The problem is solved. Resend a print job or a scan job. Does the problem remain? ◦ Yes: Go to the next step. ◦ The problem is solved. Perform the following tests: Perform a print test.

  • Page 170: Insufficient Memory Service Check

    Diagnostics and troubleshooting Perform a POR. Perform a print test. Does the problem remain? ◦ Yes: Go to the next step. ◦ The problem is solved. Perform the following tests: Reseat all the cables on the controller board. Check if the controller board LED lights up. Check the controller board for proper installation and damage.
  • Page 171 Diagnostics and troubleshooting The problem is solved. Resend a print job or a scan job. Does the problem remain? ◦ Yes: Go to the next step. ◦ The problem is solved. Perform the following tests: Reduce the number of pages to print. Reduce the file size of the print job.

  • Page 172: 42 User Attendance Messages

    Diagnostics and troubleshooting ◦ No: The problem is solved. 42 user attendance messages 42 user attendance messages Note: The .xy in the error code after 42 indicates the printer and cartridge regions. Where x is the printer region and y is the cartridge region. The numeric value is from 0 to 6.
  • Page 173 Diagnostics and troubleshooting Error code Description Action 42.13 42.14 42.15 42.19 42.20 42.21 42.23 42.24 42.25 42.29 42.30 42.31 Toner cartridge region does Toner cartridge service not match the printer region. check on page 174. 42.32 42.34 42.35 42.39 42.40 42.41 42.42 42.43...

  • Page 174: Toner Cartridge Service Check

    174. 42.91 42.92 42.93 42.94 42.95 Toner cartridge service check Make sure that the imaging unit and toner cartridge are genuine Lexmark supplies. Does the problem remain? ◦ Yes: Go to the next step. ◦ The problem is solved. Perform the following tests: Shake the toner cartridge.

  • Page 175: 55 User Attendance Messages

    Diagnostics and troubleshooting Go to the next step. ◦ The problem is solved. Make sure that the toner cartridge is changed from shipped with equipment (SWE) toner to a compatible toner. Does the problem remain? ◦ Yes: Go to the next step. ◦...
  • Page 176 Diagnostics and troubleshooting Check if the flash drive is detected on the computer. Is the flash drive set to the correct file system, and is it detected? ◦ Yes: Go to step 4. ◦ Go to the next step. Format the flash drive to the correct file system. Does the problem remain? ◦...

  • Page 177: 71 User Attendance Messages

    Diagnostics and troubleshooting Go to the next step. ◦ The problem is solved. Perform the following tests: Reseat all the cables on the controller board. Check if the controller board LED lights up. Check the controller board for proper installation and damage. Is the controller board properly installed and free of damage? ◦...

  • Page 178: Analog Phone Line Service Check

    Diagnostics and troubleshooting ◦ Yes: Go to the next step. ◦ The problem is solved. Perform the following tests: From the control panel, go to Settings > Fax > Fax defaults > General fax settings > Fax name. Enter the fax name. Does the problem remain? ◦...

  • Page 179: Network Service Check

    Diagnostics and troubleshooting ◦ Yes: Contact the next level of support. ◦ Go to the next step. Replace the damaged cable. Does the problem remain? ◦ Yes: Contact the next level of support. ◦ The problem is solved. Network service check Perform the following tests: Turn off the printer.

  • Page 180: 84 User Attendance Messages

    Diagnostics and troubleshooting 84 user attendance messages 84 user attendance messages Error code Description Action 84.01 The imaging unit is nearly Toner cartridge or low. imaging unit low service 84.02 check on page 181. 84.11 The imaging unit is low. 84.12 84.13 84.19...

  • Page 181: Toner Cartridge Or Imaging Unit Low Service Check

    Diagnostics and troubleshooting Toner cartridge or imaging unit low service check Make sure that the imaging unit and toner cartridge are genuine Lexmark supplies. Does the problem remain? ◦ Yes: Go to the next step. ◦ The problem is solved. Perform the following tests: From the control panel, navigate to Settings > Reports > Device > Device statistics.
  • Page 182 Diagnostics and troubleshooting Go to the next step. ◦ The problem is solved. Perform the following tests: Shake the imaging unit. Clean the imaging unit smart chip contacts, and then check the contacts for damage. Clean the imaging unit spring contacts, and then check the contacts for damage. Perform a print test.

  • Page 183: 88 User Attendance Messages

    Diagnostics and troubleshooting Is the controller board properly installed and free of damage? ◦ Yes: Contact the next level of support. ◦ Go to the next step. Replace the controller board. See .Controller board removal on page 322 Does the problem remain? ◦...

  • Page 184: Non-Supply User Attendance Messages

    Diagnostics and troubleshooting Non-supply user attendance messages Non-supply user attendance messages Error code Description Action Short paper. Short paper service check on page 185. Deficient memory. Insufficient memory service check on page 170. Insufficient collation area. Insufficient memory. Memory full. Complex page.

  • Page 185: Short Paper Service Check

    Diagnostics and troubleshooting Check if the controller board LED lights up. Check the controller board for proper installation and damage. Is the controller board properly installed and free of damage? ◦ Yes: Contact the next level of support. ◦ Go to the next step. Replace the controller board.
  • Page 186 Diagnostics and troubleshooting Input tray quick print > Tray 1 > Single Does the problem remain? ◦ Yes: Go to the next step. ◦ The problem is solved. Perform the following tests: Make sure that the separator roller is free of dust and contamination. Make sure that the lift plate is properly working.
  • Page 187 Diagnostics and troubleshooting ◦ Yes: Go to step 9. ◦ Go to the next step. Replace the duplex unit. Does the problem remain? ◦ Yes: Go to the next step. ◦ The problem is solved. Perform the following tests: Reseat the sensor cable. Enter the Diagnostics menu, and then navigate to: Printer diagnostics &...
  • Page 188 Diagnostics and troubleshooting ▪ Sensor (input sensor S3) ▪ Sensor (fuser exit sensor S4) Does the sensor status change while toggling the sensor? ◦ Yes: Go to step 15. ◦ Go to the next step. Perform the following tests: Check the sensor flags for proper installation and damage. Check the sensor flags for proper alignment with the sensors.

  • Page 189: Insufficient Memory Service Check

    Diagnostics and troubleshooting Insufficient memory service check Perform the following tests: Perform a POR. Send a print job with no image. Does the problem remain? ◦ Yes: Go to the next step. ◦ The problem is solved. Perform the following tests: Enter the Diagnostics menu, and then select Advanced print quality samples.

  • Page 190: Printer Hardware Errors

    Diagnostics and troubleshooting Go to the next step. ◦ The problem is solved. Make sure that the printer is using the latest firmware version, and update if necessary. Does the problem remain? ◦ Yes: Contact the next level of support. ◦...

  • Page 191: 121 Errors

    Diagnostics and troubleshooting Error code Description Action 111.36 Printhead error (mirror Printhead error 2 motor lock never stabilized) service check on page 206. was detected. 111.37 Paper reached the sensor (input sensor S3) but the mirror motor was not locked. 111.38 Paper reached the sensor (input sensor S3) but the...
  • Page 192 Diagnostics and troubleshooting Error code Description Action 121.12 The fuser never reached final EWC/line detection temperature (belt: 90°C, lamp: 149°C). 121.13 The fuser heated too fast to the final EWC/line detection temperature (belt: 90°C, lamp: 149°C). 121.20 The fuser high power trace heating rate from 165°C to 180°C exceeded the error threshold.

  • Page 193: Fuser Service Check

    Diagnostics and troubleshooting Error code Description Action 121.71 Open fuser main heater thermistor. Fuser service check Make sure that the voltage rating of the printer matches the power supply voltage of the electrical outlet that the printer is plugged into. Does the problem remain? ◦...
  • Page 194 Diagnostics and troubleshooting ◦ Yes: Go to the next step. ◦ The problem is solved. Perform the following tests: Enter Diagnostics menu, and then navigate to: Printer diagnostics & adjustments > Motor tests Select Motor (transport drive). Open the rear door, and then check if the fuser exit rollers turn. Open the fuser access door, and then check if the hot rollers turn.
  • Page 195 Diagnostics and troubleshooting ◦ The problem is solved. Perform the following tests: Reseat the fan cable. Make sure that the cable is properly connected. Make sure that the fan and gears are properly installed. Make sure that the fan is free of grease contamination. Does the problem remain? ◦...
  • Page 196 Diagnostics and troubleshooting Go to the next step. ◦ The problem is solved. Replace the LVPS. See LVPS removal on page 326. Does the problem remain? ◦ Yes: Go to the next step. ◦ The problem is solved. Perform the following tests: Enter the Diagnostics menu, and then navigate to: Printer diagnostics &...

  • Page 197: 126 Errors

    Diagnostics and troubleshooting ◦ Yes: Go to the next step. ◦ The problem is solved. Perform the following tests: Reseat all the cables on the controller board. Check if the controller board LED lights up. Check the controller board for proper installation and damage. Is the controller board properly installed and free of damage? ◦...

  • Page 198: Lvps Service Check

    Diagnostics and troubleshooting LVPS service check Perform the following tests: Remove the imaging unit and toner cartridge, and then make sure that the paper path is free of jams and obstructions. Clear all rollers of dirt and contamination. Does the problem remain? ◦...

  • Page 199: 140 Errors

    Diagnostics and troubleshooting Does the problem remain? ◦ Yes: Go to the next step. ◦ The problem is solved. Perform the following tests: Reseat all the cables on the controller board. Check if the controller board LED lights up. Check the controller board for proper installation and damage. Is the controller board properly installed and free of damage? ◦...
  • Page 200 Diagnostics and troubleshooting Does the problem remain? ◦ Yes: Go to the next step. ◦ The problem is solved. Perform the following tests: Remove the imaging unit and toner cartridge, and then make sure that the paper path is free of jams and obstructions. Clear all rollers of dirt and contamination.

  • Page 201: 6Yy Errors

    Diagnostics and troubleshooting ◦ Contact the next level of support. Check the cables for proper connection and damage. Are the cables properly connected and free of damage? ◦ Yes: Go to step 8. ◦ Go to the next step. Replace the damaged cable. Does the problem remain? ◦...
  • Page 202 Diagnostics and troubleshooting Error code Description Action 600.04 Duplex paper was never Printer declared jam picked. service check on page 203. 600.05 Invalid printhead NVRAM Printhead error 1 type. service check on page 205. 600.06 No response from the paper Printer declared jam port driver.

  • Page 203: Printer Declared Jam Service Check

    Diagnostics and troubleshooting Error code Description Action 611.37 Paper reached the sensor (input sensor S3) but the mirror motor was not locked. 611.38 Paper reached the sensor (input sensor S3) but the printhead startup was not complete. 621.01 The fuser heater was not Restart the print job.
  • Page 204 Diagnostics and troubleshooting Check the smart chip for proper installation and damage. Is the smart chip properly installed and free of damage? ◦ Yes: Go to step 6. ◦ Go to the next step. Replace the imaging unit Does the problem remain? ◦...

  • Page 205: Printhead Error 1 Service Check

    Diagnostics and troubleshooting Printhead error 1 service check Perform the following tests: Turn off the printer. Unplug the power cord. Wait for 20 seconds, and then plug the power cord. Turn on the printer. Does the problem remain? ◦ Yes: Go to the next step.

  • Page 206: Printhead Error 2 Service Check

    Diagnostics and troubleshooting Does the problem remain? ◦ Yes: Go to the next step. ◦ The problem is solved. Perform the following tests: Reseat all the cables on the controller board. Check if the controller board LED lights up. Check the controller board for proper installation and damage. Is the controller board properly installed and free of damage? ◦...
  • Page 207 Diagnostics and troubleshooting ◦ Yes: Go to step 5. ◦ Go to the next step. Perform the following tests: Check the sensor for proper installation and damage. Check the alignment with the sensor flag. Check the sensor cable for proper connection and damage. Is the sensor properly installed and free of damage? ◦...
  • Page 208 Diagnostics and troubleshooting Replace the damaged sensor flag. Does the problem remain? ◦ Yes: Go to the next step. ◦ The problem is solved. Perform the following tests: Reseat the two printhead cables at both ends. Check the printhead cables for proper connection. Check the printhead for proper installation and damage.

  • Page 209: Procedure Before Starting The 9Yy Service Checks

    Diagnostics and troubleshooting Perform the following tests: Reseat all the cables on the controller board. Check if the controller board LED lights up. Check the controller board for proper installation and damage. Is the controller board properly installed and free of damage? ◦...

  • Page 210: Collecting The Firmware Logs (Fwdebug And Logs.tar.gz) From The Se Menu

    Diagnostics and troubleshooting Note: ◦ printer_IP_address is the TCP/IP address of the printer. ◦ se is required to access the printer diagnostic information. Click History Information, copy all information, and then save it as a text file. E-mail the text file to your next level of support. B.

  • Page 211: Collecting Information From The User

    Diagnostics and troubleshooting Note: Make sure that your printer is connected to a network or to a print server. Open a web browser, type http://printer_IP_address, and then press Enter. Click Settings, and then select one of the settings pages from the links shown on the page. Copy all the information, and then save it as a text file.
  • Page 212 Diagnostics and troubleshooting Error code Description Action Engine card—Delay line  calibration failure. Non-Generic FRU installed. Mismatch between system NVRAM part and mirror NVRAM part. Note: .xx points to the setting that does not match. A recoverable NVRAM cyclic redundancy check error occurred. Note: •...
  • Page 213 Diagnostics and troubleshooting Error code Description Action RIP card failure—ASIC  failure. Controller board NAND failure. Invalid firmware—Service  system board. RAM memory error—RAM  soldered on the card is bad. RAM memory error—RAM  in slot 1 is bad. RAM memory error—RAM  in slot 2 is bad. RAM memory error—RAM  in slot 3 is bad. Download emulation cyclic redundancy check error—...

  • Page 214: 900 Error Service Check

    Diagnostics and troubleshooting Error code Description Action Invalid command received. Invalid command parameter received. RFID media option hardware error. An equipment check condition has occurred in the printer, but the printer is unable to identify the exact component failure. A controller board equipment check is detected.
  • Page 215 Diagnostics and troubleshooting At the rear of the printer, disconnect the network cable, USB cable, and fax line. Turn on the printer. Does the problem remain? ◦ Yes: Go to step 12. ◦ Go to the next step. Perform the following tests: From the control panel, navigate to the Reports menu.
  • Page 216 Diagnostics and troubleshooting ◦ Yes: Go to the next step. ◦ Contact the next level of support. Using the Device Settings report that is printed in step 5, check if the firmware level is older than the latest available version. Is the firmware version older, and does the customer agree to update the firmware? ◦...
  • Page 217 Diagnostics and troubleshooting ◦ Yes: Go to the next step. ◦ The problem is solved. Perform the following tests: Turn off the printer. Uninstall the hard disk. Perform a POR. Does the problem remain? ◦ Yes: Go to step 17. ◦...

  • Page 218: Engine Error Service Check

    Diagnostics and troubleshooting ▪ Memory options ▪ Fax card ▪ Modem ▪ Wireless and network option cards Note: Make sure to perform a POR after installing each component. Does the problem remain? ◦ Yes: Go to the next step. ◦ The problem is solved.

  • Page 219: Network Software Error Service Check

    Diagnostics and troubleshooting The problem is solved. Make sure that the printer is using the latest firmware version, and update if necessary. Does the problem remain? ◦ Yes: Go to the next step. ◦ The problem is solved. Check the cables for proper connection and damage. Are the cables properly connected and free of damage? ◦...
  • Page 220 Diagnostics and troubleshooting Wait for 20 seconds, and then plug the power cord. Turn on the printer. Does the problem remain? ◦ Yes: Go to the next step. ◦ The problem is solved. Perform the following tests: Check the network cable for proper connection and damage. Make sure that the network cable contacts are free from dirt or corrosion.

  • Page 221: Adf/Scanner Hardware Errors

    Diagnostics and troubleshooting Go to the next step. ◦ The problem is solved. Check the cables for proper connection and damage. Are the cables properly connected and free of damage? ◦ Yes: Go to step 9. ◦ Go to the next step. Replace the damaged cable.

  • Page 222: Sensor (Scan) Service Check

    Diagnostics and troubleshooting Error code Description Action 840.02 The scanner is disabled for other reasons. For example, invalid license and too many hardware errors. 842.00 Non‑responsive scanner  communication failure. 842.01 Hardware protocol scanner communication failure. 842.02 Logical protocol scanner communication failure. 843.00 Flatbed home position •...
  • Page 223 Diagnostics and troubleshooting ◦ Yes: Go to the next step. ◦ The problem is solved. Perform the following tests: Check the ADF pick and feed rollers for wear, damage, and contamination. Check the ADF pick separator pad for wear, damage, contamination, and spring load. Check if the ADF cover properly closes.
  • Page 224 Diagnostics and troubleshooting Go to the next step. ◦ The problem is solved. Perform the following tests: Make sure that the ADF cover properly closes. Check the ADF scan sensor flag for proper installation and damage. Is the sensor flag properly installed and free of damage? ◦...

  • Page 225: Sensor (Adf Top Door Interlock) Service Check

    Diagnostics and troubleshooting ◦ Go to the next step. Perform the following tests: Reseat the ADF cable. Check the ADF cable for proper connection and damage. Check the ADF assembly for proper installation and damage. Check the ADF cover sensor for damage. Is the ADF assembly properly installed and free of damage? ◦...
  • Page 226 Diagnostics and troubleshooting Make sure that the scanner paper setting matches the paper loaded. Does the problem remain? ◦ Yes: Go to the next step. ◦ The problem is solved. Perform the following tests: Enter the Diagnostics menu, and then navigate to: Scanner diagnostics >...
  • Page 227 Diagnostics and troubleshooting Go to the next step. ◦ The problem is solved. Perform the following tests: Clean the ADF pick rollers and separator pad. Enter the Diagnostics menu, and then navigate to: Scanner diagnostics > Feed test Does the problem remain? ◦...

  • Page 228: Adf Feed Error Service Check

    Diagnostics and troubleshooting Check the ADF cover sensor for damage. Is the ADF assembly properly installed and free of damage? ◦ Yes: Go to step 13. ◦ Go to the next step. Replace the ADF assembly. See ADF scanner (old) and flatbed scanner (old) removal on page 376 ADF scanner (new) and flatbed scanner (new) removal on page 386.
  • Page 229 Diagnostics and troubleshooting The problem is solved. Perform the following tests: Enter the Diagnostics menu, and then navigate to: Scanner diagnostics > Sensor tests Find the sensor (ADF media present). Does the sensor status change while toggling the sensor? ◦ Yes: Go to step 5.
  • Page 230 Diagnostics and troubleshooting Perform the following tests: Clean the ADF pick rollers and separator pad. Enter the Diagnostics menu, and then navigate to: Scanner diagnostics > Feed test Does the problem remain? ◦ Yes: Go to the next step. ◦ The problem is solved.

  • Page 231: Scanner Disabled And Scanner Communication Error Service Check

    Diagnostics and troubleshooting ◦ Yes: Go to step 13. ◦ Go to the next step. Replace the ADF assembly. See ADF scanner (old) and flatbed scanner (old) removal on page 376 ADF scanner (new) and flatbed scanner (new) removal on page 386.
  • Page 232 Diagnostics and troubleshooting Perform the following tests: Reseat all the scanner cables on the controller board. Perform a POR. Does the problem remain? ◦ Yes: Go to the next step. ◦ The problem is solved. Perform the following tests: Enter the Diagnostics menu, and then navigate to: Scanner diagnostics >...

  • Page 233: Flatbed Home Position Service Check

    Diagnostics and troubleshooting ◦ Yes: Go to step 9. ◦ Go to the next step. Perform the following tests: Make sure that the flatbed scanner cables are properly connected and free of damage. Check the flatbed scanner for proper installation and damage. Is the flatbed scanner properly installed and free of damage? ◦...
  • Page 234 Diagnostics and troubleshooting Go to the next step. ◦ The problem is solved. Perform the following tests: Reseat all the scanner cables on the controller board. Perform a POR. Does the problem remain? ◦ Yes: Go to the next step. ◦...

  • Page 235: Other Symptoms

    Diagnostics and troubleshooting ◦ Yes: Contact the next level of support. ◦ Go to the next step. Replace the controller board. See Controller board removal on page 322. Does the problem remain? ◦ Yes: Contact the next level of support. ◦...
  • Page 236 Diagnostics and troubleshooting ◦ Go to the next step. Replace the front door. See .Rear door removal on page 345 Does the problem remain? ◦ Yes: Go to the next step. ◦ The problem is solved. Perform the following tests: Check the HVPS characterization.

  • Page 237: Load Tray 1 With A4 Plain Paper Service Check

    Diagnostics and troubleshooting Contact the next level of support. ◦ The problem is solved. Load tray 1 with A4 plain paper service check Perform the following tests: Make sure that the tray insert is properly inserted. Make sure that the paper is properly loaded in the tray. Make sure that the paper type and size settings match the paper type and size set on the tray.
  • Page 238 Diagnostics and troubleshooting ◦ The problem is solved. Perform the following tests: Enter the Diagnostics menu, and then navigate to: Printer diagnostics & adjustment > Sensor tests Find the following sensors: ▪ Sensor (media present in tray1 S1) ▪ Sensor (input sensor S3) ▪...

  • Page 239: Paper Did Not Arrive In The Bin Service Check

    Diagnostics and troubleshooting Does the problem remain? ◦ Yes: Go to the next step. ◦ The problem is solved. Check the cables for proper connection and damage. Are the cables properly connected and free of damage? ◦ Yes: Go to step 12. ◦...
  • Page 240 Diagnostics and troubleshooting Make sure that the paper size setting in the duplex unit matches the printer setting. Make sure that the front and rear doors are fully closed. Make sure that the output bin is free from obstructions. Does the problem remain? ◦...
  • Page 241 Diagnostics and troubleshooting Printer diagnostics & adjustment > Motor tests Select Motor (transport). Check if the exit roller turns. Did the exit roller turn? ◦ Yes: Go to step 9. ◦ Go to the next step. Perform the following tests: Make sure that the redrive gears are in proper contact with the printer drive gears.

  • Page 242: Tray Insert Obstructed Service Check

    Diagnostics and troubleshooting ◦ Contact the next level of support. Perform the following tests: Enter the Diagnostics menu, and then navigate to: Input tray quick print > Tray 1 > Single Enter the Diagnostics menu, and then navigate to: Input tray quick print > Duplex > Single Does the problem remain? ◦...

  • Page 243: Unable To Remove Toner Cartridge Service Check

    Diagnostics and troubleshooting ◦ The problem is solved. Perform the following tests: Make sure that the separator roller is free of dust and contamination. Make sure that the lift plate is properly working. Make sure that the paper guides are properly working. Check the tray insert for proper installation and damage.
  • Page 244 Diagnostics and troubleshooting Go to the next step. ◦ Contact the next level of support. Perform the following tests: Enter the Diagnostics menu, and then navigate to: Printer diagnostics & adjustments > Motor tests Select Motor (transport drive). Did the motor run? ◦...

  • Page 245: No Display Service Check

    Diagnostics and troubleshooting No display service check Perform the following tests: Reseat all the cables on the controller board. Check if the controller board LED lights up. Does the controller board LED light up? ◦ Yes: Go to the next step. ◦...

  • Page 246: No Power Service Check

    Diagnostics and troubleshooting No power service check Perform the following tests: Reseat all the cables on the controller board. Check if the controller board LED lights up when the power is on. Does the controller board LED light up? ◦ Yes: Go to step 5.

  • Page 247: Adf/Scanner Symptoms

    Diagnostics and troubleshooting Go to the next step. Replace the damaged cable. Does the problem remain? ◦ Yes: Go to the next step. ◦ The problem is solved. Perform the following tests: Reseat all the cables on the controller board. Check if the controller board LED lights up.
  • Page 248 Diagnostics and troubleshooting Is the ADF pick assembly properly installed and free of damage? ◦ Yes: Go to step 4. ◦ Go to the next step. Replace the ADF pick assembly. See ADF pick assembly removal on page 374. Does the problem remain? ◦...

  • Page 249: Fax Symptoms

    Diagnostics and troubleshooting Check the controller board for proper installation and damage. Is the controller board properly installed and free of damage? ◦ Yes: Contact the next level of support. ◦ Go to the next step. Replace the controller board. See Controller board removal on page 322.

  • Page 250: Fax Symptoms

    Diagnostics and troubleshooting ◦ Yes: The problem is solved. ◦ Go to https://www.etherfax.net/lexmark. Fax symptoms Symptom Action Fax not detected. Fax not detected service check on page 250. Cannot set up etherFAX. Cannot set up etherFAX on page 251 Cannot send or receive faxes using Cannot send or receive faxes using etherFAX.

  • Page 251: Cannot Set Up Etherfax

    Diagnostics and troubleshooting Does the problem remain? ◦ Yes: Go to the next step. ◦ The problem is solved. Perform the following tests: Reseat all the cables on the controller board. Check if the controller board LED lights up. Check the controller board for proper installation and damage. Is the controller board properly installed and free of damage? ◦...

  • Page 252: Fax Transmission Service Check

    Can you set up etherFAX? ◦ Yes: The problem is solved. ◦ Go to https://www.etherfax.net/lexmark. Fax transmission service check Note: These instructions apply only to printers that support analog fax. For more information, see Supported fax on page Reseat the telephone cable on the LINE port of the printer and on the wall jack.
  • Page 253 Diagnostics and troubleshooting Does the problem remain? ◦ Yes: Go to the next step. ◦ The problem is solved. Perform the following tests: From the home screen, navigate to Settings > Fax > Analog Fax Setup > Fax Receive Settings > Admin Controls > Enable Fax Receive. Select On.
  • Page 254 Diagnostics and troubleshooting Contact the next level of support. Check if the printer receives a fax from one specific remote device. Does the printer receive a fax from one specific remote device? ◦ Yes: Go to step 13. ◦ Go to the next step. Check if a different device can send a fax. Can the device send a fax? ◦ Yes: Contact the next level of support.

  • Page 255: Fax Reception Service Check

    Diagnostics and troubleshooting Adjust the setting in steps of 2 dB. Note: The recommended adjustment range is between -33 dB and -48 dB. Does the problem remain? ◦ Yes: Go to the next step. ◦ The problem is solved. Perform the following tests: Enter the Service Engineer menu, and then navigate to: Fax SE >...
  • Page 256 Diagnostics and troubleshooting ◦ Yes: Go to step 4. ◦ Go to the next step. Connect the telephone cable to a working wall jack. Does the problem remain? ◦ Yes: Go to the next step. ◦ The problem is solved. Check if the telephone line is analog.
  • Page 257 Diagnostics and troubleshooting Go to the next step. ◦ The problem is solved. Perform the following tests: From the home screen, navigate to Settings > Fax > Analog Fax Setup > Fax Send Settings > Behind a PABX. Select No. Check if access to an outside line needs a dial prefix.
  • Page 258 Diagnostics and troubleshooting The problem is solved. Check the TIA/EIA-IS-968 Standard "Technical Requirements for Connection of Terminal Equipment to the Telephone Network" for your geography. Is it permitted for analog modulated transmitted data to transmit above -9 dBm? ◦ Yes: Go to the next step.

  • Page 259: Lost Connection To Https Fax Server When Using Etherfax Service Check

    Diagnostics and troubleshooting Does the problem remain? ◦ Yes: Contact the next level of support. ◦ The problem is solved. Lost connection to HTTPS fax server when using etherFAX service check Perform the following tests: Enter the Service Engineer (SE) menu, and then navigate to: Fax SE Menu >...

  • Page 260: Fax Error Log Codes

    Diagnostics and troubleshooting ◦ The problem is solved. Make sure that the printer serial number is properly added in your etherFAX portal account. Does the problem remain? ◦ Yes: Contact the next level of support. ◦ The problem is solved. Fax error log codes Error code Description...
  • Page 261 Diagnostics and troubleshooting Error code Description Action An error occurred when • Check the line quality. receiving a frame. • Adjust the Receive Threshold. An error occurred when • Check the line quality. sending a frame. • Adjust the Transmit Level.
  • Page 262 Diagnostics and troubleshooting Error code Description Action T5 Timeout occurred when • Check line quality. transmitting image data to • Adjust the Transmit remote fax device. Level setting • Decrease the Max Speed setting under Fax Send settings. Too many errors when •...
  • Page 263 Diagnostics and troubleshooting Error code Description Action Tried too many times at • Adjust the Transmit selected speed using V34 Level setting. modulation scheme. • Decrease the modulation scheme. Fax transmission was Troubleshoot MFP if error interrupted due to power persists.
  • Page 264 Diagnostics and troubleshooting Error code Description Action Failure to transmit training • Decrease the Max successfully in V17, V27 Speed setting under terminal modulation Fax Send settings. schemes. • Adjust the Transmit Level setting. • Check line quality. Failure to transmit training •...
  • Page 265 Diagnostics and troubleshooting Error code Description Action Failed to connect using • Check line quality. V.34 modulation scheme. • Decrease the modulation scheme. • Adjust the Transmit Level or Receive Threshold settings. No fax tones detected from • Verify destination remote end.
  • Page 266 Diagnostics and troubleshooting Error code Description Action Received request for No action needed. unsupported image resolution from remote fax device. Received request for No action needed. unsupported compression type from remote fax device. Received request for No action needed. unsupported image length from remote fax device.

  • Page 267: Service Menus

    Service menus   Service menus Understanding the printer control panel Lexmark MB2236adw MFP Control panel part Function Display • View printer messages and supply status. • Set up and operate the printer. Left arrow button • Scroll through menus or move...
  • Page 268 Service menus Control panel part Function Select button • Select a menu option. • Save the changes in a setting. Right arrow button • Scroll through menus or move between screens and menu options. • Increase the numeric value of a setting.

  • Page 269: Lexmark Mb2236Adwe, Lexmark Mb2236I Mfps

    Service menus Lexmark MB2236adwe, Lexmark MB2236i MFPs Control panel part Function Home button Go to the home screen. Back button Return to the previous screen. Start button Start a job, depending on which mode is selected. Indicator light Check the status of the printer.

  • Page 270: Diagnostics Menu

    Green The printer is on or ready. Blinking green The printer is processing data. Blinking red The printer requires user intervention. Lexmark MB2236adwe, Lexmark MB2236i MFPs Panel with touch‑screen display Indicator light Printer status The printer is off or in Sleep mode. Blue The printer is on or ready.

  • Page 271: Reports

    Service menus A menu appears on the display. Select Diagnostics_Mode, and then select Boot. • To access the Diagnostics menu from the home screen, press these buttons in the following sequence: Back, Back, Start, Start Reports Device Settings This report lists all the current printer settings. Enter the Diagnostics menu, and then navigate to: Reports >...

  • Page 272: Format Fax Storage

    Service menus Format Fax Storage This setting deletes stored fax jobs. Enter the Diagnostics menu, and then navigate to: Format Fax Storage > Format Fax Storage For non‑touch‑screen printer models, press  to navigate through the settings. Event Log Display Log This setting displays the panel text that appears when the event occurs. Enter the Diagnostics menu, and then navigate to: Event Log >...

  • Page 273: Mark Log

    Service menus Mark Log This setting allows you to create a service, maintenance, or custom log entry. Each log entry is added in the printer event log. Enter the Diagnostics menu, and then navigate to: Event Log > Mark Log For non‑touch‑screen printer models, press ...

  • Page 274: Permanent Page Count

    Service menus Permanent page count This setting displays the total number of pages printed. After all the print tests are completed, this value resets to zero. Enter the Diagnostics menu, and then navigate to: Printer Setup > Permanent page count View the permanent page count.

  • Page 275: Ep Setup

    Service menus For non‑touch‑screen printer models, press  to navigate through the settings. Enter the Diagnostics menu, and then navigate to: Printer Setup > Engine setting [x] Select a setting, and then enter a value. EP setup Warning—Potential Damage Do not change this setting without specific instructions from the next level of support.

  • Page 276: Motor Tests

    Service menus Sensor (media present in tray1 S1) Sensor (staging sensor S2) Sensor (input sensor S3) Sensor (fuser exit sensor S4) Motor tests Enter the Diagnostics menu, and then navigate to: Printer diagnostics & adjustments > Motor tests For non‑touch‑screen printer models, press  to navigate through the settings. Select a motor.

  • Page 277: Universal Override

    Service menus Enter the Diagnostics menu, and then navigate to: Printer diagnostics & adjustments > Registration adjust Select a setting to adjust. Universal Override This setting allows the user to feed custom media sizes to a Custom Media Tray. For non‑touch‑screen printer models, press  to navigate through the settings.

  • Page 278: Sensor Tests

    Service menus Note: • If the motor is activated, then it is properly working. • Some motors require automatic deactivation in order to avoid secondary issues such as possible damage and contamination. • Some tests require a special action to activate a motor such as removing a major component.

  • Page 279: Feed Test

    Service menus Sensor (ADF 1st scan) Sensor (ADF top door interlock) Feed Test This test allows for a continuous feed from the ADF or flatbed. Enter the Diagnostics menu, and then navigate to: Scanner Diagnostics > Feed Test For non‑touch‑screen printer models, press  to navigate through the settings. Select a paper size.

  • Page 280: Config Menu

    Service menus Config menu Entering the Config menu The Config menu consists of menus, settings, and operations that are used to configure the printer. • To access the Config menu in MB2236adw printers, press and hold Right arrow and OK on the control panel, and then turn on the printer.
  • Page 281 Service menus Menu item Description Tray Configuration Set the paper source that the user fills when a prompt to load paper appears. Paper Prompts Auto* Manual Paper Tray Configuration Set the paper source that the user fills when a prompt to load envelope appears. Envelope Prompts Auto* Manual Envelope...
  • Page 282 Service menus Menu item Description Printer Emulations Disable access to the printer message during emulation. Emulator Security Disable Printer Message Access (On*) Fax Configuration Specify the printer power setting when it is in fax mode. Fax Low Power Support Disable Sleep Permit Sleep Auto* Print Configuration...
  • Page 283 Service menus Menu item Description Device Operations Show existing error messages on the display after the printer remains inactive on Automatically Display Error Screens the home screen for a length of time equal to the Screen Timeout setting. Note: This menu item appears only in some printer models.

  • Page 284: Service Engineer Menu

    Service menus Menu item Description Scanner Configuration Set the RowsPerStrip tag value of a TIFF‑formatted scan output. Exact Tiff Rows Per Strip Note: An asterisk (*) next to a value indicates the factory default setting. Service Engineer menu Entering the Service Engineer (SE) menu This contains several functions that a service engineer may need in order to diagnose and fix problems on the printer.

  • Page 285: Fax Se Menu

    Service menus Top‑level menu Intermediate menu History • Print History • Mark History • Set Card Speed • • Keep Alive NPAP Print Alerts TCP/IP • netstat • • Allow SNMP Set • • Meditech Mode • RAW LPR Mode Wireless Enable Wi‑Fi Direct Sigma Control Agent Ping Test •...

  • Page 286: Scan Se

    Service menus Top‑level menu Intermediate menu Agency Test Menu • Go Off Hook • Ring Detect • Generate Tones • Modulations Fax Settings • Fax Modulations • FOIP Settings • Miscellaneous Settings • Reset Fax Settings Modem Settings • Caller ID Pattern Note: Changing the value of this setting also changes the value of the Caller ID setting...

  • Page 287: Entering Invalid Engine Mode

    Service menus To access the Silabs configuration: Open a web browser and then type https://<IP address>/se . Navigate to: Fax > Settings > Silabs Configuration Entering Invalid engine mode This mode allows the printer to load the correct firmware code. To access the Invalid engine mode in MB2236adw printers, perform the following: Turn off the printer.

  • Page 288: Entering Recovery Mode

    Service menus Entering Recovery mode This mode allows the printer to boot from a secondary set of instructions and flash firmware code. While in this mode, you can only flash firmware code through a USB cable  directly connected to a PC. Depending on your printer model, do any of the following: For LED display Turn off the printer. Open the front door.

  • Page 289: For 2.8-, 4.3-, 7-, And 10-Inch Displays Without Number Pads

    Service menus For 2.8‑, 4.3‑, 7‑, and 10‑inch displays without number  pads Turn off the printer. Open tray 1. Note: Make sure that paper is loaded in the tray. Turn on the printer. When an ellipses appears on the upper‑left corner of the display, close tray 1. Note: If tray 1 is not closed, then the printer boots normally.

  • Page 290: Parts Removal

    Parts removal   Parts removal Important removal information Removal precautions CAUTION—SHOCK HAZARD The low-voltage power supply (LVPS) and the high-voltage power supply (HVPS) may have residual voltage present. To avoid the risk of electrical shock, do not touch their circuit components or the solder side of the board. Only handle them by their outer edges or metal housing.

  • Page 291: Précautions De Retrait

    Parts removal Précautions de retrait CAUTION—SHOCK HAZARD Une tension résiduelle peut être présente dans le bloc d'alimentation basse tension (LVPS) et le bloc d'alimentation haute tension (HVPS). Pour éviter tout risque d'électrocution, ne touchez pas les composants du circuit ou le côté...

  • Page 292: Vorsichtsmaßnahmen Bei Der Demontage

    Parts removal CAUTION—SHOCK HAZARD Este producto utiliza un interruptor de corriente electrónico. No desconecta físicamente la entrada de voltaje de CA. Para evitar el riesgo de descarga eléctrica, desenchufe siempre el cable de alimentación de la impresora cuando sea necesario retirar la entrada de voltaje de CA. CAUTION—SHOCK HAZARD Para evitar el riesgo de descargas eléctricas y daños en la impresora, retire el cable de alimentación de la toma eléctrica y desconecte todas las...

  • Page 293: Handling Esd-Sensitive Parts

    Parts removal CAUTION—SHOCK HAZARD Um das Risiko eines elektrischen Schlags und Schäden am Drucker zu vermeiden, ziehen Sie das Netzkabel aus der Steckdose und trennen Sie alle Verbindungen zu jeglichen externen Geräten, bevor Sie Kabel, Elektronikplatinen oder Baugruppen einstecken oder abziehen. CAUTION—HOT SURFACE Das Innere des Druckers kann sehr heiß...

  • Page 294: Critical Information For Controller Board Or Control Panel Replacement (For Mb2236Adwe Only)

    Parts removal Critical information for controller board or control panel replacement (for MB2236adwe only) CAUTION—POTENTIAL INJURY The lithium battery in this product is not intended to be replaced. There is a danger of explosion if a lithium battery is incorrectly replaced. Do not recharge, disassemble, or incinerate a lithium battery.

  • Page 295: Restoring The Printer Configuration

    Parts removal Warning—Potential Damage To avoid damaging the part or experience NVRAM mismatch issues, replace only one of the following components at a time: • Control panel • Controller board To replace a component and to test whether the problem is resolved: Replace the affected component.
  • Page 296 • The software bundle contains the latest version of the firmware, applications, and software licenses from the Lexmark CFM and Package Builder. The printer firmware may be at a different level from what is used before replacement of the part.

  • Page 297: Restoring Solutions, Licenses, And Configuration Settings

    Parts removal If the printer had eSF apps previously installed, then confirm from the customer if all the eSF apps have been installed after performing the installation instructions in the Readme file. Note: • If you are unable to access the administrative menus to verify that the printer is restored, then ask the customer for access rights.

  • Page 298: Using A Network Computer

    Note: Make sure that the cable is connected to the rear USB port. Using USB Flash Utility Go to support.lexmark.com, and then download USB Flash Utility. Extract, and then run the utility. Click Browse Files, and then browse to the firmware file directory.

  • Page 299: Backing Up Esf Solutions And Settings

    Select the source printer. Click Start. Using USButil Go to support.lexmark.com, and then download USButil. Extract, and then drag and drop the firmware file onto the USButil icon. A command prompt window appears briefly. Note: Make sure to disconnect other USB devices when using USButil.

  • Page 300: Horizontal Top Contact Connector

    Parts removal • Avoid pressing against the cables when opening the locking actuator. These are the types of the ZIF connectors that are used in this printer: • Horizontal top contact connector • Horizontal bottom contact connector • Vertical mount contact connector •...
  • Page 301 Parts removal Inserting the cable Make sure that the actuator is unlocked before installing the cable. The tabs are vertical when the actuator is locked. Insert the cable on top of the actuator with the contacts facing up. Note: Make sure that the cable is installed squarely into the connector to avoid intermittent failures.

  • Page 302: Horizontal Bottom Contact Connector

    Parts removal Horizontal bottom contact connector This connector uses a flip locking actuator to lock the ribbon cable into the ZIF connector. Warning—Potential Damage When opening or closing this type of actuator, gently lift the center of the actuator using your finger. Do not use a fingernail or screwdriver to open the actuator to avoid damaging the ribbon cable.
  • Page 303 Parts removal Remove the cable. Inserting the cable Make sure that the actuator is in the open position.
  • Page 304 Parts removal 2. Insert the cable below the actuator with the contacts facing downward and away from the locking actuator. Note: Make sure that the cable is installed squarely into the connector to avoid intermittent failures.
  • Page 305 Parts removal 3. Rotate the locking actuator to the locked position.

  • Page 306: Vertical Mount Contact Connector

    Parts removal Vertical mount contact connector This connector uses a back flip locking actuator to lock the ribbon cable into the ZIF connector. Warning—Potential Damage When opening or closing this type of actuator, gently lift the center of the actuator using your finger. Do not use a fingernail or screwdriver to open the actuator to avoid damaging the ribbon cable.
  • Page 307 Parts removal Remove the cable. Inserting the cable Make sure that the locking actuator is in the open position.
  • Page 308 Parts removal 2. Insert the cable on top of the actuator with the contacts facing away from the locking actuator. Note: Make sure that the cable is installed squarely into the connector to avoid intermittent failures.
  • Page 309 Parts removal Rotate the locking actuator to the locked position. Note: ◦ Do not move the cable while locking the actuator. ◦ If the cable moves, open the actuator, reposition the cable, and then close the actuator.

  • Page 310: Horizontal Sliding Contact Connector

    Parts removal Horizontal sliding contact connector This connector uses a slide locking actuator to lock the ribbon cable into the ZIF connector. Warning—Potential Damage When opening or closing this type of actuator, gently push or pull the two tabs located on each end of the actuator. Do not close the actuator from the center of the actuator.
  • Page 311 Parts removal Remove the cable. Inserting the cable Make sure that the locking actuator is in the open position. If you are opening the connector, then pull back the end tabs using equal force to avoid breaking the connector.
  • Page 312 Parts removal 2. Insert the cable on top of the actuator with the contacts facing away from the locking actuator.
  • Page 313 Parts removal Slide the locking actuator toward the connector to lock the cable. Note: ◦ Do not move the cable while locking the actuator. ◦ If the cable moves, open the actuator, reposition the cable, and then close the actuator.

  • Page 314: Low Insertion Force (Lif) Connector

    Parts removal Low insertion force (LIF) connector Warning—Potential Damage When installing a cable into an LIF connector, avoid bending the edges of the cables and damaging the contacts on the cables. Inserting the cable Make sure that the contacts of the controller board and connectors are on the same side.
  • Page 315 Parts removal 2. Insert the cable. Note: Make sure that the cable is installed straight into the connector to avoid intermittent failures.

  • Page 316: Printhead Assembly Adjustment

    Parts removal Printhead assembly adjustment A printhead must be correctly positioned after it has been removed. Use a sharp pencil or a small, flat-blade screwdriver to mark the location of the old printhead on the printer frame. Align the new printhead relative to the location of the old printhead. Note: Skew is caused by a sheet being fed through the printer while misaligned.
  • Page 317 Parts removal Perform a POR. Enter the Diagnostics menu, and then print a Quick test page: Diagnostics Menu > Print Tests > Tray 1 > Single Fold the printed test page on the left side so that a few millimeters of grid lines wrap around the outside of the fold.

  • Page 318: Performing The Hvps Characterization

    Parts removal Print another Quick test page, and check if adjustments are still needed. After obtaining a properly adjusted image on the paper, tighten all the screws. Note: If necessary, print a Quick test page again and perform the Registration adjust procedure to correct the skew and misalignments.

  • Page 319: Removal Procedures

    Parts removal Perform a POR. Enter the Diagnostics menu, and then navigate to: Reports > Device > Device settings Check if the new HVPS adjust values were saved. Removal procedures Keep the following tips in mind as you replace parts: •...
  • Page 320 Parts removal Remove the bottom rear door. See Bottom rear door removal on page 347. Remove the left cover.
  • Page 321 Parts removal...

  • Page 322: Controller Board Removal

    Parts removal Controller board removal Note: For a video demonstration, see Controller board removal. Warning—Potential Damage When replacing or removing the controller board with PN 41X2461, do not replace or remove the toner cartridge to avoid losing printer settings and information.
  • Page 323 Parts removal Warning—Potential Damage When replacing or removing the controller board with PN 41X2515, do not replace or remove the control panel. See Critical information for controller board or control panel replacement (for MB2236adwe only) on page 294. Remove the tray insert. Remove the duplex unit.
  • Page 324 Parts removal 8. Remove the Wi‑Fi antenna.
  • Page 325 Parts removal Installation Note After replacing the controller board, perform the following: Make sure that the toner cartridge is installed. Enter the Diagnostics menu. See Entering the Diagnostics menu on page 270. Wait for 30 seconds. Navigate to Printer Setup > Serial number.

  • Page 326: Lvps Removal

    Parts removal Check if the correct printer serial number is displayed on the screen. Note: If the serial number is not updated to the correct one after 10 minutes, update the printer firmware to the latest version, and then check the serial number again.

  • Page 327: Hvps Removal

    Parts removal HVPS removal Note: Make sure to perform the HVPS characterization when replacing the HVPS. Performing the HVPS characterization on page 318. Remove the tray insert. Remove the duplex unit. Remove the rear door. See Bottom rear door removal on page 347.
  • Page 328 Parts removal 7. Remove the HVPS. Installation Note Make sure that the spring contacts on the printer (A) are properly aligned with the contacts on the HVPS (B).

  • Page 329: Right Side Removals

    Parts removal Right side removals Right cover removal Remove the tray insert. Remove the duplex unit. Remove the right cover.
  • Page 330 Parts removal...

  • Page 331: Main Drive Removal

    Parts removal Main drive removal Note: For a video demonstration, see Main drive removal. Remove the tray insert. Remove the duplex unit. Remove the rear door. See Bottom rear door removal on page 347. Remove the bottom rear door. See Bottom rear door removal on page 347.
  • Page 332 Parts removal 7. Remove the three gears (A).

  • Page 333: Pick Solenoid Removal

    Parts removal Installation Note Pay attention on how the gears are installed on the main drive and on the printer. Some gears may have a coupler within them. For more information, see the Main drive removal video. Pick solenoid removal Remove the tray insert.

  • Page 334: Fan Assembly Removal

    Parts removal Fan assembly removal Remove the tray insert. Remove the duplex unit. Remove the rear door. See Bottom rear door removal on page 347. Remove the bottom rear door. See Bottom rear door removal on page 347. Remove the left cover. See Left cover removal on page 319.
  • Page 335 Parts removal 9. Remove the fan, and then remove the gear.
  • Page 336 Parts removal Installation Note Before installing the gear, make sure that it is properly greased.

  • Page 337: Front Removals

    Parts removal Front removals 2‑line control panel removal Remove the tray insert. Remove the duplex unit. Remove the rear door. See Bottom rear door removal on page 347. Remove the bottom rear door. See Bottom rear door removal on page 347. Remove the left cover. See Left cover removal on page 319.
  • Page 338 Parts removal 8. Remove the control panel.
  • Page 339 Parts removal...

  • Page 340: 2.8-In. Control Panel Removal

    Parts removal 2.8‑in. control panel removal Warning—Potential Damage Do not replace or remove the controller board when replacing or removing the control panel. See Critical information for controller board or control panel replacement (for MB2236adwe only) on page 294. Remove the tray insert. Remove the duplex unit. Remove the rear door.
  • Page 341 Parts removal 8. Remove the control panel.
  • Page 342 Parts removal...

  • Page 343: Front Door Removal

    Parts removal Front door removal Detach the door strap. Remove the front door.

  • Page 344: Transfer Roller Removal

    Parts removal Transfer roller removal Remove the toner cartridge. Remove the transfer roller.

  • Page 345: Rear Removals

    Parts removal Installation Note ◦ Do not touch the foam on the roller. ◦ The shaft is greased. To avoid contaminating the roller, do not touch the shaft. ◦ Make sure that the spring is properly installed on the right side of the roller. Rear removals Rear door removal Remove the duplex unit.

  • Page 346: Duplex Unit Removal

    Parts removal Duplex unit removal Remove the duplex unit.

  • Page 347: Bottom Rear Door Removal

    Parts removal Bottom rear door removal Remove the duplex unit. Remove the rear door. See Rear door removal on page 345. Remove the bottom rear door. Redrive removal Remove the tray insert. Remove the duplex unit. Remove the left cover. See Left cover removal on page 319.

  • Page 348: Fuser Removal

    Parts removal Fuser removal Note: For a video demonstration, see Fuser removal. Remove the tray insert. Remove the duplex unit. Remove the front door. See Rear door removal on page 345. Remove the rear door. See Rear door removal on page 345.
  • Page 349 Parts removal...

  • Page 350: Fuser Exit Flag Removal

    Parts removal Fuser exit flag removal Remove the rear door. See .Bottom rear door removal on page 347 Open the fuser door. Remove the fuser exit flag.

  • Page 351: Top Removals

    Parts removal Top removals Top cover removal MB2236adw top cover removal Remove the tray insert. Remove the duplex unit. Remove the front door. See Front door removal on page 343. Remove the rear door. See Bottom rear door removal on page 347.
  • Page 352 Parts removal Installation Note Make sure to reinstall the toroids on the ADF and flatbed scanner cables, after removing the ADF and flatbed scanner. Remove the control panel. See 2‑line control panel removal on page 337. Disconnect the cable from the right side of the printer.
  • Page 353 Parts removal Note: Make sure to release the right side cable from the frame. Remove the top cover.
  • Page 354 Parts removal...
  • Page 355 Parts removal MB2236adwe top cover removal Remove the tray insert. Remove the duplex unit. Remove the front door. See Front door removal on page 343. Remove the rear door. See Bottom rear door removal on page 347. Remove the bottom rear door. See Bottom rear door removal on page 347.
  • Page 356 Parts removal Note: Make sure to release the right side cable from the frame. Remove the screws, and then remove the fax card holder (A).
  • Page 357 Parts removal Remove the screws, and then remove the USB cable (B) from the guides. Remove the top cover.
  • Page 358 Parts removal Installation Note Remove the USB port cover.
  • Page 359 Parts removal MB2236i top cover removal Remove the tray insert. Remove the duplex unit. Remove the front door. See Front door removal on page 343. Remove the rear door. See Bottom rear door removal on page 347. Remove the bottom rear door. See Bottom rear door removal on page 347.
  • Page 360 Parts removal Remove the control panel. See 2.8‑in. control panel removal on page 340. Disconnect the cable from the left and right sides of the printer.
  • Page 361 Parts removal Note: Make sure to release the right side cable from the frame. Remove the top cover.
  • Page 362 Parts removal...

  • Page 363: Printhead Removal

    Parts removal Printhead removal Note: If the printhead is like the one shown, then replace the printhead with PN 41X2843, and then make sure to replace the printhead cables and install the EMC bracket. Remove the tray insert. Remove the duplex unit. Remove the left cover.
  • Page 364 Parts removal 9. Remove the printhead. Installation Note Make sure that the EMC clip is properly installed.

  • Page 365: Bottom Removals

    Parts removal Bottom removals Sensor (fuser exit) removal Remove the tray insert. Remove the duplex unit. Remove the rear door. See . Bottom rear door removal on page 347 Remove the bottom rear door. See . Bottom rear door removal on page 347 Place the printer on its front, and then remove the sensor.

  • Page 366: Sensor (Paper Present) Removal

    Parts removal Sensor (paper present) removal Remove the tray insert. Remove the duplex unit. Place the printer on its rear, and then remove the sensor.

  • Page 367: Sensor (Staging And Input) Removal

    Parts removal Sensor (staging and input) removal Remove the tray insert. Remove the duplex unit. Place the printer on its rear, and then remove the sensor cover.
  • Page 368 Parts removal 4. Remove the sensor.

  • Page 369: Input Sensor Flags Removal

    Parts removal Input sensor flags removal Remove the tray insert. Remove the duplex unit. Remove the sensor (staging and input). See Sensor (staging and input) removal on page 367. Remove the two sensor flags.
  • Page 370 Parts removal Installation Note Pay attention to the position of the spring on each flag.

  • Page 371: Pick Rollers Removal

    Parts removal Pick rollers removal Note: For a video demonstration, see Pick roller removal. Remove the tray insert. Place the printer on its rear. Remove the right pick roller retainers.
  • Page 372 Parts removal...

  • Page 373: Adf And Scanner

    Parts removal Note: Perform the same procedure to remove the left pick roller retainer. Remove the two pick rollers. ADF and scanner Scanner stand removal Raise the ADF and scanner assembly. Remove the scanner stand.

  • Page 374: Adf Pick Assembly Removal

    Parts removal ADF pick assembly removal Open the ADF cover. Remove the separator pad.
  • Page 375 Parts removal Note: ◦ Pay attention to the position of the spring under the pad. ◦ Do not lose the spring. Remove the ADF pick assembly.

  • Page 376: Adf Scanner (Old) And Flatbed Scanner (Old) Removal

    Parts removal ADF scanner (old) and flatbed scanner (old) removal Installation Note Before replacing the ADF scanner and flatbed scanner, do the following: Look for the printer serial number, and then check the printer version.
  • Page 377 Parts removal Printer serial number Printer version The 8 digit of the serial number is 1. The 8 digit of the serial number is 2. Check the category of the installed ADF hinge (A). Part Category...
  • Page 378 Parts removal Part Category Note: If a printer has the new ADF hinge installed, then either has or both of the following have been installed: ◦ ADF scanner assembly (new) ◦ Flatbed scanner (new) To select the correct parts for your printer, refer to the following: Note: ◦...

  • Page 379: Removal Procedure

    Parts removal Parts Part number Compatibility ADF scanner assembly P/N 41X4494 Either part is compatible (new) with the following: ◦ New version Flatbed scanner (new) P/N 41X4495 printers. ◦ Old version printers. ◦ Printers with the new ADF hinge installed. Removal procedure Note: For a how‑to video on removing the part, see ADF/scanner assembly...
  • Page 380 Parts removal...
  • Page 381 Parts removal Disconnect the flatbed scanner FFC cable. Remove the two toroids from the ADF and flatbed scanner cables. Disconnect the four cables, and then remove the screw securing the two ground cables.
  • Page 382 Parts removal 10. Remove the ADF and flatbed scanner cables from the printer, and then remove the ADF and flatbed scanner assembly.
  • Page 383 Parts removal 11. Remove the screw. Detach the ADF scanner from the flatbed scanner.
  • Page 384 Parts removal Note: Do not lose the two brackets.
  • Page 385 Parts removal 12. Lift the ADF scanner at a 45‑degree angle and then pull it from the flatbed scanner.

  • Page 386: Adf Scanner (New) And Flatbed Scanner (New) Removal

    Parts removal ADF scanner (new) and flatbed scanner (new) removal Installation Note Before replacing the ADF scanner and flatbed scanner, do the following: Look for the printer serial number, and then check the printer version. Printer serial number Printer version The 8 digit of the serial number is 1.
  • Page 387 Parts removal Part Category Note: If a printer has the new ADF hinge installed, then either has or both of the following have been installed: ◦ ADF scanner assembly (new) ◦ Flatbed scanner (new) To select the correct parts for your printer, refer to the following:...

  • Page 388: Removal Procedure

    Parts removal Note: ◦ If any of the old parts is out of stock, then you must replace both of them with the new parts. ◦ The old flatbed scanner is only compatible with the old ADF scanner assembly. The same is true for the new flatbed scanner and new ADF scanner assembly. Parts Part number Compatibility...
  • Page 389 Parts removal...
  • Page 390 Parts removal Disconnect the flatbed scanner FFC cable. Remove the two toroids from the ADF and flatbed scanner cables. Disconnect the four cables, and then remove the screw securing the two ground cables.
  • Page 391 Parts removal 10. Remove the ADF and flatbed scanner cables from the printer, and then remove the ADF and flatbed scanner assembly.
  • Page 392 Parts removal 11. Remove the screw. Detach the ADF scanner from the flatbed scanner.
  • Page 393 Parts removal Note: Do not lose the two brackets.
  • Page 394 Parts removal 12. Lift the ADF scanner at a 45‑degree angle and then pull it from the flatbed scanner.
  • Page 395 Parts removal 13. Remove the ADF scanner from the flatbed scanner.
  • Page 396 Parts removal...

  • Page 397: Component Locations

    Component locations   Component locations Printer configuration Automatic document feeder (ADF) ADF tray ADF bin Standard bin Power button Manual feeder 250‑sheet tray Control panel Note: The appearance may vary depending on your printer model.

  • Page 398: Controller Board Connectors

    Component locations Controller board connectors Note: Fax connector is applicable only to specific models. Connector Connects to Pin number Signal JCN37 Sensor 1.2 V (flatbed) GROUND FB home Sns JCN34 Motor (ADF) ADF BOUT1 ADF BOUT2 ADF AOUT1 ADF AOUT2 Not used JCN36 Motor...
  • Page 399 Component locations Connector Connects to Pin number Signal JCIS P9 JCIS P10 JCIS P11 GROUND JCN6 3.3 V FUSED RIP GROUND 5 V FUSED FAX POR FAX IRQ 3.3 V FUSED RIP GROUND BSPI CLK FAX GROUND BSPI TXD FAX GROUND BSPI RXD GROUND...
  • Page 400 Component locations Connector Connects to Pin number Signal ROW6 ROW5 ROW4 ROW3 ROW2 ROW1 ROW0 LCD ON LCD SDA LCD SCK LCD RSTN OP PAN DETECT LCD CD LCD CS LCD BK GROUND 3.3 V JCN31 3.3 V Imaging 13.3 unit contact SCHIP...
  • Page 401 Component locations Connector Connects to Pin number Signal HVPS ID C 3.3 V_ENG 3.3 V_SCHIP CART SDA C CART SCL C FDOOR OPEN C FAN EN C 3.3 V ENG SNS PICK EN C BUMP ROLL EN C INPUT SNSN C BUMP SNSN C CONNECTION) UNUSED SNSN C...
  • Page 402 Component locations Connector Connects to Pin number Signal VDO K1  -C VDO ADJ1N C VDO K1 +C VDO LENAN C GROUND VDO LPOW C VDO K0 -C VDO PWR C 3.3 V VDO K0 +C JCN24 LVPS 25 V CONT 25 V CONT 25 V CONT GROUND GROUND...
  • Page 403 Component locations Connector Connects to Pin number Signal JCN10 Sensor (tray TRAY EMPTY LED empty) C  1.1 V TRAY EMPTY C GROUND No connection JCN1 Sensor (fuser 3.3 V exit) EXIT SNS C GROUND JCN2 Sensor A FUSER THERM (fuser) C 1.8 V GROUND...

  • Page 404: Maintenance

    Maintenance   Maintenance Cleaning printer parts Cleaning the printer CAUTION—SHOCK HAZARD To avoid the risk of electrical shock when cleaning the exterior of the printer, unplug the power cord from the electrical outlet and disconnect all cables from the printer before proceeding. Note: •...

  • Page 405: Cleaning The Scanner

    Maintenance Cleaning the scanner Open the scanner cover. Using a damp, soft, lint-free cloth, wipe the following areas: ◦ ADF glass ◦ ADF glass pad...
  • Page 406 Maintenance ◦ Scanner glass ◦ Scanner glass pad...
  • Page 407 Maintenance 3. Close the scanner cover.

  • Page 408: Parts Catalog

    Parts catalog   Parts catalog Legend The following column headings are used in the parts catalog: • Asm‑index—Identifies the item in the illustration. • Part number—Identifies the unique number that correlates with the part. • Units/mach—Refers to the number of units actually used in the base machine or product. • Units/FRU—Refers to the number of units in a particular FRU. • Description—Describes the part. The following abbreviations are used in the parts catalog: • NS (not shown) in the Asm‑index column indicates that the part is procurable but is not  pictured in the illustration. •...

  • Page 409: Covers (Mb2236Adw)

    Parts catalog Covers (MB2236adw) Asm- Units/ Units/ Description Removal procedure index mach 41X2449 Right cover Right cover removal on page 41X2450 Front door Front door removal on page 41X2451 Left cover Left cover removal on page 41X2448 Bottom rear door Bottom rear door removal on page 347 41X2447...
  • Page 410 Parts catalog Asm- Units/ Units/ Description Removal procedure index mach 41X2479 2‑line control panel 2‑line control panel removal on page 337...

  • Page 411: Covers (Mb2236Adwe, Mb2236I)

    Parts catalog Covers (MB2236adwe, MB2236i) Asm- Units/ Units/ Description Removal procedure index mach 41X2449 Right cover Right cover removal on page 41X2450 Front door Front door removal on page 41X2451 Left cover Left cover removal on page 41X2448 Bottom rear door Bottom rear door removal on page 347 41X2447...
  • Page 412 Parts catalog Asm- Units/ Units/ Description Removal procedure index mach 41X2446 Top cover (MB2236adwe) Top cover removal on page 41X2979 Top cover (MB2336i) Top cover removal on page 41X2516 2.8‑in. control panel 2.8‑in. control panel removal on page 340...

  • Page 413: Paper Path

    Parts catalog Paper path Asm- Units/ Units/ Description Removal procedure index mach 41X2453 Redrive Redrive removal on page 347 41X2454 Duplex unit Duplex unit removal on page 41X2455 Pick roller Pick rollers removal on page 41X2452 Tray insert...

  • Page 414: Drive

    Parts catalog Drive Asm- Units/ Units/ Description Removal procedure index mach 41X2470 Fan assembly 41X2471 Main drive Main drive removal on page 41X2472 Pick solenoid Pick solenoid removal on page 333...

  • Page 415: Sensors

    Parts catalog Sensors Asm- Units/ Units/ Description Removal procedure index mach 41X2468 Sensor (fuser exit) Sensor (fuser exit) removal on page 365 41X2467 Sensor (staging and input) Sensor (staging and input) removal on page 367 41X2466 Sensor (paper present) Sensor (paper present) removal on page 366 41X2469 Sensor flags...

  • Page 416: Electronics

    Parts catalog Electronics Asm- Units/ Units/ Description Removal procedure index mach 41X2843 Printhead Printhead removal on page 41X2457 Transfer roller Transfer roller removal on page 344 41X2459 LVPS, 110 V LVPS removal on page 326 41X2460 LVPS, 220 V LVPS removal on page 326 41X2458 HVPS HVPS removal on page 327...
  • Page 417 Parts catalog Asm- Units/ Units/ Description Removal procedure index mach 41X2973 Controller board Controller board removal on (MB2236adw) page 322 Note: Make sure to upgrade the firmware to version FW 074.038 or later. 41X2515 Controller board Controller board removal on (MB2236adwe) page 322 41X2974...

  • Page 418: Scanner

    Parts catalog Scanner Asm- Units/ Units/ Description Removal procedure index mach 41X2476 ADF scanner assembly (old) ADF scanner (old) and flatbed scanner (old) removal on page 376 Note: Before replacing the part, refer to the compatibility information in the removals.
  • Page 419 Parts catalog Asm- Units/ Units/ Description Removal procedure index mach 41X4494 ADF scanner assembly (new) ADF scanner (new) and flatbed scanner (new) removal on page 386 Note: Before replacing the part, refer to the compatibility information in the removals. 41X2480 ADF pick assembly ADF pick assembly removal on page 374...

  • Page 420: Miscellaneous

    Parts catalog Miscellaneous Asm- Units/ Units/ Description Removal procedure index mach 40X0278 Power cord, straight—Austria  and Russia 40X0282 Power cord, straight—PRC 40X0286 Power cord, straight—Ireland,  Bahrain, Cyprus, Kuwait, Lebanon, Malta, Oman, Qatar, United Arab Emirates, and United Kingdom (England, Scotland, Wales, and Northern Ireland) 40X0297 Power cord, straight (6 feet)— US, Canada, and Latin America (Colombia, Costa Rica, Dominican Republic,...

  • Page 421: Printer Specifications

    Printer specifications   Printer specifications Power consumption Product power consumption The following table documents the power consumption characteristics of the product. Note: Some modes may not apply to your product. Mode Description Power consumption (Watts) MB2236adw MB2236adwe Printing The product is generating hard‑copy output ...

  • Page 422: Sleep Mode

    The power consumption levels listed in the previous table represent time-averaged measurements. Instantaneous power draws may be substantially higher than the average. Values are subject to change. See www.lexmark.com for current values. Sleep Mode This product is designed with an energy-saving mode called Sleep Mode. The Sleep Mode saves energy by lowering power consumption during extended periods of inactivity.

  • Page 423: Selecting A Location For The Printer

    Printer specifications Selecting a location for the printer • Leave enough room to open trays, covers, and doors and to install hardware options. • Set up the printer near an electrical outlet. • Make sure that airflow in the room meets the latest revision of the ASHRAE 62 standard or  the CEN Technical Committee 156 standard. •...

  • Page 424: Noise Emission Levels

    1-meter average sound pressure, dBA Printing One-sided: 52; Two-sided: 50 Scanning Copying Ready Values are subject to change. See www.lexmark.com for current values. Temperature information Ambient operating temperature 10 to 32.2°C (50 to 90°F) Shipping temperature -40 to 43.3°C (-40 to 110°F) Storage temperature and relative humidity -40 to 43.3°C (-40 to 110°F)

  • Page 425: Theory Of Operation

    Theory of operation   Theory of operation POR sequence As the printer turns on, the engine code goes through a series of tests to verify hardware integrity. If a hardware failure is detected, then it is reported to the printer. If the POR sequence cannot be completed successfully, then the printer may post an error message.

  • Page 426: Print Cycle

    Theory of operation Fuser Print cycle Flowchart...

  • Page 427: Charge

    Theory of operation Charge Charge roller Photoconductor drum The charge roller applies a uniform negative electrical charge to the surface of the photoconductor drum. The photoconductive properties of the surface material allow it to hold the charge as long as it is not exposed to light.

  • Page 428: Expose

    Theory of operation Expose Printhead Photoconductor drum The printhead emits the light that contacts the surface of the photoconductor drum. The light turns on or off coinciding with the digital latent image. The light causes areas of the photoconductor drum surface to lose charge, resulting in a relative opposite polarity.

  • Page 429: Develop

    Theory of operation Develop Toner cartridge Developer roller Photoconductor drum The developer unit applies the toner from the toner cartridge to the photoconductor drum. The difference in charge causes the toner particles to attract to the photoconductor drum areas which are exposed to light.

  • Page 430: Transfer

    Theory of operation Transfer Charge roller Transfer roller Paper The transfer roller applies a positive charge to the paper, which is pressed between the transfer roller and the photoconductor drum. Due to relative opposite polarities between the paper from the transfer roller, and the photoconductor drum from the charge roller, the charge attracts the toner to the paper.

  • Page 431: Fuse

    Theory of operation Fuse Fuser Paper Even if the toner image is already on the paper, the toner particles are not yet permanently bonded to the surface. For the final part of printing, the paper is transported to the fuser where heat and pressure are applied to it.

  • Page 432: Printer Operation

    Theory of operation Printer operation Printer sections Output bin Printhead Toner cartridge Imaging unit Manual feeder Tray Lift plate Transfer roller Fuser Paper paths...

  • Page 433: Printer Paper Path

    Theory of operation Printer paper path Simplex print job Paper exit roller Fuser exit roller Fuser Photoconductor drum Deskew roller Transport roller Feed roller Pick roller Transfer roller The pick and feed rollers pick the paper, and then feeds it to the transport roller. The transport roller moves the paper to the deskew roller where the paper skew is corrected.

  • Page 434: Duplex Print Job

    Theory of operation The deskew roller feeds the paper to the transfer roller for image transfer. At the transfer roller, the photoconductor drum transfers the developed image to the paper to create the printed image. As the paper passes the fuser, heat and pressure are applied to bond permanently the toner to the paper.

  • Page 435: Printer Paper Path Sensors

    Theory of operation Printer paper path sensors Sensor Function Sensor (fuser exit) Detects the paper exiting the fuser Sensor (staging) Detects the paper travelling between the pick rollers and the deskew roller Sensor (paper present) Detects paper presence in the tray Sensor (input) Detects the paper travelling between the...

  • Page 436: Main Drive

    Theory of operation Main drive Transfer roller Photoconductor Fuser Paper exit  Motor (main drive) Deskew solenoid Pick solenoid  Transport roller Deskew roller...

  • Page 437: Adf And Scanner Operation

    Theory of operation The motor (main drive) powers the drive mechanism of the printer. The gearbox provides mechanical power to the printer which transfers power through several gears to the following parts: • Manual feeder • Paper pick using the pick solenoid •...

  • Page 438: Adf Paper Path

    Theory of operation The flatbed scanner has a scanner lamp that illuminates the surface of the document. The reflections produced are processed to create the scan image. For flatbed scan jobs, the flatbed scanner moves across the scanner glass area to scan the front side of the document.

  • Page 439: Adf Paper Path Sensors

    Theory of operation The scan rollers continue to move the paper to the scan area until the trailing edge of the paper reaches the sensor (ADF scan). When the trailing edge of the paper reaches the sensor (ADF scan), the sensor goes to the off position. Scanning continues for a predetermined length of time.

  • Page 440: Index

    Index Index scanner calibration reset feed test avoiding paper jams accessing advanced print quality samples develop ADF theory paper path sensors paper path error codes 200 paper jam messages 202 paper jam messages configurations 206 paper jam messages printer models 232 paper jam messages change history electrostatic‑sensitive parts...
  • Page 441 Non‑Lexmark supply horizontal sliding contact connector print quality initial check invalid engine mode paper jams accessing avoiding invalid code, fixing printer status...
  • Page 442 Index output bin quick feed resetting the supply usage counters printer diagnostics and adjustments resetting the printer HVPS adjust without admin credentials registration adjust restoring performing the HVPS characterization license file printer parts configuration file cleaning removal procedures parts catalog legend tips POR sequence restoring configuration...
  • Page 443 Index pick rollers finding main drive service engineer (SE) menu pick solenoid accessing LVPS network SE fuser exit flag general SE fuser removal EWS SE menu sensor (fuser exit) scan SE ADF scanner (old) and flatbed scanner (old) fax SE menu symptoms ADF scanner (new) and flatbed scanner (new) printer...
  • Page 444 USB cable connection duplex paper path using the control panel paper path sensors Lexmark MB2236adw MFP main drive panel with 2‑line LCD theory, ADF paper path sensors Lexmark MB2236adwe MFP theory, flatbed scanner Lexmark MB2236i MFP theory, ADF paper path panel with touch‑screen display...
  • Page 445 Service Manual  ...

This manual is also suitable for:

Mb2236iMb2236adwMb2236adwe
