Pantum CM1100 Series Service Manual

Pantum CM1100 Series Service Manual

Multi-function color laser printer
Hide thumbs Also See for CM1100 Series:
Table of Contents

Advertisement

Quick Links

Download this manual
Service Manual
Service Manual for Pantum CM1100 Series
Multi-Function Color Laser Printer
It is recommended to read this manual carefully before repairing
Version: V1.0

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the CM1100 Series and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Pantum CM1100 Series

Summary of Contents for Pantum CM1100 Series

  • Page 1 Service Manual Service Manual for Pantum CM1100 Series Multi-Function Color Laser Printer It is recommended to read this manual carefully before repairing Version: V1.0...
  • Page 2 Service Manual for Pantum Multi-Function Color Laser Printer Suitable printer: CM11** (“*”stands for any number and letter)

  • Page 3: Version Change History

    Version change history Version Time Modified contents V1.0 July 29, 2021 New Service Manual Page:...
  • Page 4 The copyright of this user guide is possessed by Zhuhai Pantum Electronics Co., Ltd.. Without the prior written consent of Zhuhai Pantum Electronics Co., Ltd., it is forbidden to copy, translate, modify and transmit this user guide by any means or in any form.
  • Page 5 Recycling system of Pantum’s electronic products In order to protect the environment, Zhuhai Pantum Electronics Co., Ltd. has established a recycling system for discarded products. You can choose to hand over the discarded printers and consumables to the local Pantum maintenance center for unified recycling, and then the discarded...
  • Page 6 Safety Warnings Prior to the use of this printer, please pay attention to the following safety warnings: Warnings There are high voltage electrodes inside the printer. Prior to the cleaning of the printer, make sure that the power is cut off! Do not insert or uproot the power plugs with wet hands to avoid electric shock.
  • Page 7 Safety Information Appointment Note: information that may help you or things that may cause damage to the printer hardware or software. Caution: potential hazards that may cause physical injury. Different types of warning banners include: Caution - potential injuries: risk of physical injury. Caution - shock hazards: risk of electric shock.
  • Page 8 wear or press the power cord. Please do not place the power cord between objects, such as furniture and walls. There may be fire or shock hazard once these things happen. Please check the power cord regularly to identify signs of this problem in time.
  • Page 9 do not touch the location with the high temperature warning label immediately to avoid burns. Caution-pinching hazards: for the purpose of avoiding pinching hazards, please proceed with caution in the area marked with this label. Pinching may occur near moving parts such as gears, closing covers, trays, and covering plate.
  • Page 10 Important notes Precautions before use: 1. Read and understand all instructions; 2. Understand the common sense on how to use electrical appliances; 3. Follow the signs on the machine or the warnings and instructions in the manual supplied with the printer; 4.
  • Page 11 24. This product is sold as a whole, and consumers can purchase the required accessories at Pantum after-sales service center. If the sales product is inconsistent with the packaging list, please go to the designated after-sales service center for processing;...
  • Page 12 Radio Equipment directive 2014/53/EU only for models ending with suffix "W". The manufacturer of this product is: Zhuhai Pantum Electronics Co.,Ltd., No.3883, Zhuhai Avenue, Zhuhai, Guangdong, China 519060. A declaration of conformity to the requirements of the Directives is available upon request from the Authorized Representative.
  • Page 13 Names and contents of toxic and harmful substances or elements in products Toxic and harmful substances or elements Part names Cr (VI) PBDE ○ ○ ○ ○ ○ × Circuit board ○ ○ ○ ○ ○ × Power supply ○ ○...

  • Page 14: Table Of Contents

    Contents 1. Product series introduction ..................... 17 2. Whole machine structure and principle ................18 2.1 Component structure chart ....................18 2.2 2.2 Mechanical device ...................... 18 2.3 Paper Walk Path........................ 20 ADF Paper Walk Path ....................20 2.3.1 Printer Paper Walk Path ....................20 2.3.2 2.4 Image-forming principle ....................
  • Page 15 Removing the paper jammed ..................59 5.5.2 5.6 Paper jam troubleshooting ....................65 5.7 Image quality problems ....................67 6. Disassembly and Assembly ....................72 6.1 Disassembly Steps ......................72 6.2 Disassembly tools ......................73 6.3 Disassembly steps ......................74 Disassembly of left cover ....................
  • Page 16 Disassembly of manual feed sensor ................100 6.3.37 Disassembly of front cover sensor switch ..............100 6.3.38 7. Precautions for replacement of spare parts: ..............101 7.1 Manually performing the calibration function after replacing any accessories ....101 Calibration method (FB model) ................101 7.1.1 7.1.2 Calibration method (ADF model) .................

  • Page 17: Product Series Introduction

    Product series introduction CM1100DN CM1100DW CM1100ADN CM1100ADW Product series parameters Series Series Series Series ● ● ● ● Interface ● ● type ● ● Wi-Fi ● ● ● Printer ● Language ● Control ● ● ● panel ● ● ● Printing ●...

  • Page 18: Whole Machine Structure And Principle

    Whole machine structure and principle 2.1 Component structure chart ADF assembly Scanner assembly Top cover assembly Discarded toner cartridge Controller assembly board Laser Fuser Fan assembly Right cover Double-sided rear cover assembly High voltage board assembly Power supply Transfer belt Toner cartridge assembly Toner cartridge...

  • Page 19: Mechanical Device

    2.2 Mechanical device Names Pickup roller Tip correction roller Second transfer roller Double-sided correction roller Fuser heat roller Fuser pressure roller Delivery roller First transfer roller Photoconductor drum Charging roller Developer roller Toner adder roller ADF paper discharge roller ADF paper feed roller Page:...

  • Page 20: Paper Walk Path

    2.3 Paper Walk Path 2.3.1 ADF Paper Walk Path 2.3.2 Printer Paper Walk Path As shown in the above figure, the red line is the machine’s single-sided paper feed route (Line A is the manual paper tray feed route, and Line B is the automatic paper tray feed route), and the blue line C is the machine double-sided paper feed route.

  • Page 21: Image-Forming Principle

    Detect paper jam location 1. Check whether the rear cover is closed, an error will be reported if it is not closed 2. Detect the bending of the paper as it enters the fuser. If it Fuser (probe) sensor bends excessive, the motor (fuser) will improve the speed to avoid paper jams;...

  • Page 22: Exposure

    charging roller applies a uniform negative charge on the entire surface of the photoconductor drum to prepare to be irradiated by the laser beam. Service Tips In case that the surface of the charging roller is damaged (for example, there are notches or pits), it will cause uneven charge on the photoconductor drum, and periodic image defects may appear on the printed page.

  • Page 23: Develop

    latent images or electrostatic images. The laser beam discharges only to the surface, causing the beam to hit the photoconductor drum. This discharge creates a potential difference between the exposed area and the rest of the photoconductor drum surface. Service Tips Do not touch the surface of the photoconductor drum directly by hand.

  • Page 24: First Transfer

    When the laser exposes the photoconductor drum, the HVPS will transfer the electric charge to the developer roller, which is evenly adhered with toner. Due to the electrical charge difference between the developer roller and the photoconductor drum, the toner is attracted to the laser-exposed area on the photoconductor drum surface.

  • Page 25: Second Transfer

    When each photoconductor is developed, HVPS transmits voltage to the first transfer roller inside the transfer belt. For each color, the image on the surface of the photoconductor drum is transferred to the surface of the transfer belt through the charge difference between the surface of the photoconductor drum and the first transfer roller, which occurs during the direct surface contact between the photoconductor drum and the transfer belt.

  • Page 26: Fuser

    timing until the paper just moves to the position between the transfer belt and the second transfer roller. HVPS transmits the voltage to the second transfer roller to generate positive charge. When the image on the transfer belt reaches the second transfer roller, the negatively charged toner will stick to the paper and then the whole image is transferred from the transfer belt to the paper.
  • Page 27 With the help of transfer roller, the paper with image enters the fuser area. The fuser applies heat and pressure to the paper to melt the toner particles and stick them to the paper permanently. The fuser drives the paper to the exit roller, which then drives the paper to the paper channel. Service Tips In case that the fuser roller is damaged, toner may fall off the paper and the paper may be jammed.

  • Page 28: Cleaning/Wiping

    2.4.7 Cleaning/Wiping The printer will perform these two cleaning processes during the imaging process. During these two processes, the residual toner will be removed from the corresponding modules. a. Cleaning of transfer belt Transfer Screw belt Cleaning blade After the image is transferred to the paper by transfer belt, the cleaning blade transfers the residual toner to the waste toner bottle by the rotating screw.

  • Page 29: Maintenance

    Maintenance • The appearances of the printers with different models and functions are different, and the Note: schematic diagram is for reference only. 3.1 Cleaning of printer ：Some parts of the printer are still in high temperature within a short time after use. To prevent burns, please don’t directly touch places labeled with high temperature warning in contact with internal components after opening the printer’s front or rear.
  • Page 30 1.Turn off the printer, and then unplug the power cord from the electrical outlet. 2. Remove the paper from the standard exit and feed tray. 3. Remove any dust, lint, and pieces of paper around the printer using a soft brush or vacuum. 4.

  • Page 31: Replacing Parts And Consumables

    3.2 Replacing parts and consumables 3.2.1 Replacing the toner cartridge Note: • If the paper tray is opened, remove it before replacing the toner cartridge. 1. Open the front door and push it down firmly. 2. Pull out the printer toner cartridge tray. Page:...
  • Page 32 3. Remove the used toner cartridge. 4. Unpack the new printer toner cartridge. Note: • Do not expose the bottom of the printer toner cartridge to direct light. Prolonged exposure to light may cause print quality problems. • Do not touch the bottom of the printer toner cartridge. Otherwise, the quality of future printing jobs will be affected.
  • Page 33 5. Push the new printer toner cartridge. 6. Push the printer toner cartridge, and then close the closing cover. Page:...

  • Page 34: Replacing The Waste Toner Bottle

    3.2.2 Replacing the waste toner bottle 1. Remove the old waste toner bottle. Note: • Place the waste toner bottle upright to avoid toner leakage. 2. Unpack the new waste toner bottle. 3. Push the new waste toner bottle. Page:...

  • Page 35: Replacing The Paper Tray

    3.2.3 Replacing the paper tray 1. Remove the old paper tray. 2. Unpack the new paper tray. 3. Push the new paper tray. Page:...

  • Page 36: Moving The Printer

    3.2.4 Moving the printer 3.2.4.1 Moving the printer to another location : for the purpose of avoiding shock hazards, please do not place or use this product near water sources or in damp places. : the printer with a weight of more than 18 kg can only be safely lifted by two or more trained persons.

  • Page 37: Printer Panel Structure And Function Descriptions

    Printer panel structure and function descriptions 4.1 FB control panel structure and function descriptions 4.1.1 Control panel structure 4.1.2 The button functions are defined as follows: Name Functions Turn the power on or off and press this button under Ready state to enter energy-saving mode.
  • Page 38 Back Return to the previous menu. Copy Button Press this button to enter into copy mode. Scan Button Press this button to enter into scan mode. ID copy Press it to enter the ID copy mode. Short press Wi-Fi button to turn on direct Wi-Fi connection of the printer and automatically print out "Mobile Device Wi-Fi Connection Wizard"...

  • Page 39: Touch Screen Panel Structure And Function Descriptions

    4.2 Touch screen panel structure and function descriptions 4.2.1 Control panel structure Layout of touch screen buttons of printer control panel is shown as below: 4.2.2 The button functions are defined as follows: Name Functions Turn the power on or off and press this button under Ready state to enter Power switch energy-saving mode.

  • Page 40: Error Display And Troubleshooting

    Error display and troubleshooting 5.1 Inspection prior to repair 5.1.1 Precautions for inspection prior to repair Caution - shock hazards: this symbol on the product means that there is dangerous voltage in the working area. Unplug the power plug of the product before working. Be careful if the product must be powered on to perform the task.

  • Page 41: Preliminary Printer Troubleshooting

    Avoid placing the printer in a place where its vents will not be blocked. 5.1.3 Preliminary printer troubleshooting Check whether its appearance is damaged (printer defects may be related to its appearance damage) Confirm the startup and shutdown (check whether the printer can warm up normally or what faults are reported) Check whether there is a large amount of toner or dust in the printer, and please clean.
  • Page 42 5) Ensure that the paper guide is placed correctly and the paper or envelope shall not be pressed tightly 6) After loading the paper, push the tray into the printer 2. Using paper recommended 1) Use new, undamaged paper and paper recommended or special media 2) Do not load wrinkled, shrunk, damp, bent or curled paper 3) Before loading paper, it shall be tightened, unfolded and the edges of the paper shall be aligned 4) Do not use paper that has been hand-cut or trimmed...
  • Page 43 5.1.3.2 How to restore the factory settings 1) FB model “Restore factory settings” is used to recover the default settings of printer. The printer will restart itself automatically after recovering factory settings. 1. Press "Menu" to enter the menu setting interface. 2.
  • Page 44 5.1.3.3 Printing information report 5.1.3.3.1 FB panel model You can print information report by operating control panel. These pages can help you to learn about product information, and diagnose and solve product failures. 1. Press "Menu" to enter the menu setting interface. 2.
  • Page 45 5.1.3.3.2 ADF panel model You can print information report by operating control panel. These pages can help you to learn about product information, and diagnose and solve product failures. 1. Click " " button in control panel to enter "Menu Setting" interface. 2.
  • Page 46 5.1.3.3.3 Information page descriptions Firmware version Machine serial number Number of pages printed by the machine Consumables information Page:...
  • Page 47 5.1.3.3.4 Network configuration information page descriptions information Page:...
  • Page 48 5.1.3.4 Color calibration setting method (FB model) When the environment where your printer is used changes greatly, the printer may automatically perform color calibration for better printing results. In case of ghosting or large color difference, you can manually calibrate colors as follows: 1.
  • Page 49 5.1.3.5 Color calibration setting method (ADF model) When the environment where your printer is used changes greatly, the printer may automatically perform color calibration for better printing results. In case of ghosting or large color difference, you can manually calibrate colors as follows: 1.

  • Page 50: Error Messages

    5.2 Error messages Error prompts Error reasons Solutions The printer is not 1. The USB cable or power 1. Please connect the USB cable connected cord is not connected and power cord correctly; 2. The driver installed 2. Install the correct driver; incorrectly 3.
  • Page 51 damaged 4. Re-connect/replace the toner 4. The toner cartridge chip cartridge chip cable cable is pulled out or 5. Replace the spring of the contact broken point of the high voltage board 5. The spring of the contact chip point of the high voltage board chip has deformation C/M/Y/K toner...
  • Page 52 cartridge; damaged The paper source does not match 1. The paper used 1. Set the paper by the panel or the Automatic input tray inconsistent with the paper driver to be consistent with the set by the panel or the paper settings do not paper used driver...

  • Page 53: Common Malfunctions

    5.3 Common malfunctions Defects Causes of defects Solutions 1. The power supply board 1. Re-connect/replace power Power when cable is pulled out/damaged supply board cable booting 2. Power supply board defects 2. Replace the power supply board 3. Controller board defects 3.
  • Page 54 2. Fuser defects Please close 1. The ADF switch cable is 1.Re-connect ADF switch cable. ADF cover pulled out. 2.Replace ADF switch. 2. ADF switch damaged. 3.Re-connect ADF sensor FFC. 3. ADF sensor FFC is pulled 4.Replace ADF sensor FFC. 5.Replace controller board.

  • Page 55: Fault Codes

    5.4 Fault codes Warnings! This product has a self-diagnostic function. In the event that a fault is detected, an error code warning message will be displayed on the screen or computer. Error code Cause Inspection and measures Internal error of printer The heat roller works at full 01.001 power for a too long time...
  • Page 56 02.007 toner cartridge control motor) DC motor is at a slow rotating Internal error of printer speed (color toner cartridge 02.008 control motor) DC motor is at a fast rotating Internal error of printer speed (color toner cartridge 02.008 control motor) Internal error of printer DC motor is jammed (color toner 02.008...
  • Page 57 Internal error 15 of AFE calibration scanner failed (GAIN) Internal error 16 of Shading failed scanner Page:...

  • Page 58: Removing The Paper Jammed

    5.5 Removing the paper jammed 5.5.1 Identifying the location of the paper jammed Paper jam location Standard exit Manual feed tray Automatic Feeder Tray Automatic document feeder Rear cover Page:...

  • Page 59: Removing The Paper Jammed

    5.5.2 Removing the paper jammed 1. Paper jammed in automatic input tray 1) Pull out the tray 3) Remove the paper jammed. Note: • Make sure that all paper fragments are removed. 3) Insert the tray 4) Open the rear cover :The inside of the printer might be hot.
  • Page 60 5) Remove the paper jammed • Make sure that all paper fragments are removed. Note: 6) Close the rear cover 2. Paper jammed in manual input tray 1) Open the front cover, and then push it down hard. 2) Remove the jammed paper. •...
  • Page 61 3. Close the front cover. • If the problem still cannot be solved, please contact the customer services center. Note: 3. Paper jammed in rear cover 1) Open the rear door : the inside of the printer may be very hot. To avoid the risk of being burned by hot components, please wait for the surface to cool down before touching the components.
  • Page 62 Paper jammed in fuser zone Paper jammed below the fuser Page:...
  • Page 63 Duplex unit 3) Close the cover. 4. Paper jam in the automatic document feeder (ADF) 1) Open the ADF's top cover. 2) Remove the paper jammed from the ADF. Page:...
  • Page 64 3) After removing the paper jamed, close the top cover and then the printer will be back to the ready state. 4) If it is difficult to remove the paper jammed, please try to open the scanner cover and remove it from the pressing block. Page:...

  • Page 65: Paper Jam Troubleshooting

    5.6 Paper jam troubleshooting Error reasons Solutions Paper jammed 1. Re-load the paper automatic input tray 2. Replace the automatic input tray 3. Clean/replace the rubber roller Automatic input tray 4. Replace the controller board fails to feed the paper No paper in automatic input tray Paper...
  • Page 66 Place the ADF paper properly No paper in ADF Replace ADF the adf paper sensor. Replace the ADF paper sensor handle. Paper jammed in ADF Check ADF paper path, and remove jammed paper by hand. Replace the ADF paper sensor. Page:...

  • Page 67: Image Quality Problems

    5.7 Image quality problems Symptom Possible cause Suggested remedy   The printout is blank Laser FFC defects Re-connect or replace the laser FFC   Laser defects Replace the laser   High voltage board defects Replace the high voltage board ...
  • Page 68 toner nozzle are leaking or damaged   Colored lines appear Toner cartridge assembly defects Replace the toner cartridge assembly   vertically There are contaminants or spilled Clean the transfer belt assembly toner on the transfer belt assembly (transfer belt, transfer roller, and ...
  • Page 69   Gray colored Toner cartridge assembly defects Replace the toner cartridge assembly   background appears Laser defects Replace the laser   in the printout There are contaminants or spilled Clean the transfer belt assembly toner on the transfer belt assembly (transfer belt, transfer roller, and ...
  • Page 70   The printout is not Toner cartridge assembly defects Replace the toner cartridge assembly   uniform Laser defects Replace the laser   There are contaminants or spilled Clean the transfer assembly (transfer toner on the transfer module belt, transfer roller, coupling gear) ...
  • Page 71   Polychrome Laser defects Adjust the color calibration settings inaccurate (see Section 8.1.7 for concrete operation methods)  Replace the laser There are vertical The glass platen is dirty. Clean the glass platen    The scanning head is dirty ...

  • Page 72: Disassembly And Assembly

    Disassembly and Assembly Preparations before disassembling: 1. The printer needs to be disconnected from all external power supplies prior to disassembly. 2. The cable tie needs to be removed prior to disassembly. The cable tie must be exchanged during reassembly to avoid wire pinching, paper path blocking, or restricted mechanical movement. 3.

  • Page 73: Disassembly Tools

    6.2 Disassembly tools Cross screwdriver Six-angle screwdriver (6 angles T10 blades) Spring hook Tweezers Page:...

  • Page 74: Disassembly Steps

    6.3 Disassembly steps 6.3.1 Disassembly of left cover 1. Pull out the automatic input tray, and use a six-angle screwdriver (T10) to remove the two fixing screws on the left cover (as shown below) 2. Open the front and rear covers of the printer 3.

  • Page 75: Disassembly Of Right Cover

    4. Unclench the two buckles connecting the left cover and the upper cover (from left to right) with tweezers 5. Loosen the buckle B at the bottom of the left cover and remove the left cover ○ 6.3.2 Disassembly of right cover 1.
  • Page 76 2. Move the side of the printer out of the desktop, and open the back-end buckle of the right cover of the printer with your left hand while opening the buckle A at the bottom of the printer with your right hand ○...

  • Page 77: Adf/Scanner Assembly

    6.3.3 ADF/scanner assembly 1.Remove the left cover and right cover, use a six-angle screwdriver (T10) to remove one fixing screw, and then take out the protecting cover. 2.Disconnect the five cables of the left data board connected to the scanner assembly, use a six-angle screwdriver (T10) to remove one grounding screw outside the controller board.

  • Page 78: Adf Motor

    Use a cross screwdriver to remove one screw of the cover, use tweezer to pry out the edge of cover, and then remove the cover. (hold the scanner assembly by hand to avoid damage). 5. Hold the scanner/ADF assembly by hand, remove the scanner harness, and vertically pull out the scanning assembly.

  • Page 79: Scanner Cover Assembly

    6.3.5 Scanner cover assembly 1. Remove the ADF/scanner assembly, two bottom screws of the scanner assembly, and then take out the iron baffles. Remove ADF by pulling it up. 3.Pry out the bucklers (just into the corresponding holes of the jaws, and keep the tweezers in the first position while conduct prying in other positions) with two slotted screwdrivers or tweezers, and remove the scanner cover assembly ⑦...

  • Page 80: Cis

    6.3.6 1. Remove the scanner cover assembly. Then pull out the CIS friction pads (one respectively on the left and right) 2. Pull out the CIS harness. Make CIS upright and take it out through the right side (do not directly touch the CIS luminous tube while replacing CIS, in order to avoid abnormality of the scanned image).
  • Page 81 2. Remove the screws and the conductive sheet of the steel shaft. Then pry out the left end of the steel shaft. Remove the two screws and take out the motor assembly. Then remove two motor screws and scanner motor. Page:...

  • Page 82: Disassembly Of Toner Cartridge Assembly

    6.3.8 Disassembly of toner cartridge assembly 1. Open the front cover, push aside 4 pairs of toner assembly buckles, and then take out the toner cartridge (tips: do not touch the OPC surface of the toner cartridge with your hands, OPC shall be protected from light for a long term to avoid affecting the print quality) 2.

  • Page 83: Disassembly Of Front Cover

    2. Move to the left to remove the rear cover (along the direction of arrow) 6.3.10 Disassembly of front cover 1. Use the tip of a straight screwdriver to push out the hinge pins on the left and right sides of the front cover to the right (place the tweezers in the position shown below to prevent the hinge pins pushed out from falling and losing) 2.

  • Page 84: Disassembly Of Transfer Belt Assembly

    6.3.11 Disassembly of transfer belt assembly 1. Push aside the connecting wire protecting cover on the right side of the power supply board by hand, use a six-angle screwdriver (T10) to loosen the screws on high voltage board and take out the wiring harness, and disconnect the wiring harness connecting the power controller board 2.

  • Page 85: Disassembly Of Toner Spot Sensor

    Left buckle Drive gear of transfer belt B. Pull out the transfer belt from the back of the printer and take it out (do not touch or scratch the surface of the transfer belt and the transfer roller while removing them to avoid print quality problems) 6.3.12 Disassembly of toner spot sensor...

  • Page 86: Disassembly Of Controller Board Cover

    6.3.13 Disassembly of controller board cover Remove the left cover, use a six-angle screwdriver (T10) to remove one fixing screw, and then take out the protecting cover 6.3.14 Disassembly of controller board Remove the left cover and the controller board protection cover. Disconnect all connecting lines of the controller board, use a six-angle screwdriver (T10) to remove 5 fixing screws, and then take out the controller board.

  • Page 87: Disassembly Of Controller Board Holder

    6.3.15 Disassembly of controller board holder Remove the left cover, take out the controller board, use a six-angle screwdriver (T10) to remove 4 fixing screws on the controller board holder and take it out 6.3.16 Disassembly of motor (CMY) 1. Remove the left cover, force apart the buckles on the motor cover in the frame to the direction that the arrow indicates and take out the black protecting cover, disconnect the motor connecting lines, and use a six-angle screwdriver (T10) to remove 3 fixing screws and take out the motor.

  • Page 88: Disassembly Of Motor (Fuser)

    6.3.18 Disassembly of motor (fuser) Remove the controller board, use a six-angle screwdriver (T10) to remove 4 fixing screws on the controller board holder and take it out. Disconnect the motor connecting lines, and use a six-angle screwdriver (T10) to remove 2 fixing screws and take out the motor. 6.3.19 Disassembly of graded clutch 1.

  • Page 89: Disassembly Of Control Panel

    6.3.20 Disassembly of Control panel Use tweezer to pry up eight buckles at the edge of control panel, unplug the FFC and power switch cable, then remove the control panel. 6.3.21 Disassembly of top cover assembly 1. Remove the left and right covers of the printer, remove the controller board protecting cover, and disconnect the lines connecting the panel and the controller board.
  • Page 90 3.Remove two fixed screws on the left lug boss, then remove the USB flash disk port. 4.Use a six-angle screwdriver (T10) to remove two screws, and use tweezer to pry up three buckles. 5. Lift the top cover, hold the two side edges by hand and take out the top cover. Page:...

  • Page 91: Disassembly Of Laser

    6.3.22 Disassembly of laser 1. Remove the left and right covers of the printer, remove the controller board protecting cover, and disconnect 3 flat connecting lines on controller board and 2 flat connecting lines on high voltage board 2. Disconnect the flat connecting harness (A) and release the locking spring (B) by the spring hook 3.

  • Page 92: Disassembly Of Exit Sensing Arm And Exit Sensor Board

    6.3.23 Disassembly of exit sensing arm and exit sensor board 1. Remove the top cover of the printer, and back out the sensing arm towards the right as indicated by the arrow. Left sensing arm Right sensing arm Be careful not to damage the sensing handle when...

  • Page 93: Disassembly Of Pickup Clutch

    2. Take the cable A out of the inner via hole, and use a six-angle screwdriver (T10) to loosen 6 fixing screws, and then remove the main drive assembly. 6.3.25 Disassembly of pickup clutch Remove the main drive assembly. Use tweezers to remove the E-clip (A), and then remove the gear of the pickup clutch (B).

  • Page 94: Disassembly Of Cooling Fan

    6.3.27 Disassembly of cooling fan Remove the right cover, disconnect the connecting line of the high-voltage board, and then remove the fan (pay attention to the direction of the fan when installing, and the gasket needs to be stuck on the indicated area of the fan) 6.3.28 Disassembly of high voltage board (HVPS) assembly 1.

  • Page 95: Disassembly Of Power Supply Board (Lvps) Assembly

    6.3.29 Disassembly of power supply board (LVPS) assembly 1. Remove the right cover of the printer. Remove the connector protecting cover after removing the screws with a cross screwdriver, and then press tweezers against two buckles inwards Connector protecting cover 2.

  • Page 96: Disassembly Of Rubber Roller

    3. Use a six-angle screwdriver to remove the two fixing screws, and then take out the power supply board (LVPS) 6.3.30 Disassembly of rubber roller 1. Place the printer as shown below, and then remove the leather sheath of the rubber roller by hands.

  • Page 97: Disassembly Of Tray Sensor Switch

    6.3.31 Disassembly of tray sensor switch 1. Remove the controller board protecting cover, and disconnect the connecting lines of the controller board. 2. Use a six-angle screwdriver to remove the 4 fixing screws on the bottom holder of the printer, and then remove the holder (Tips: toner contamination may occur, in case that the printer is placed sidelong.

  • Page 98: Disassembly Of Fuser

    6.3.32 Disassembly of fuser 1. Open the front and rear covers, remove the top cover and the controller board protecting cover, and disconnect the connecting line 2. Disconnect the fuser connecting line at the high voltage board, push aside the power supply board protecting cover and then disconnect the connecting line.

  • Page 99: Disassembly Of Automatic Feed Sensor

    6.3.34 Disassembly of automatic feed sensor 1. Remove the rear cover of the printer, use a six-angle screwdriver (T10) to remove 4 fixing screws on the bottom holder of the printer, and then remove the holder 2. Disconnect the sensor cable (A), use a six-angle screwdriver (T10) to remove one fixing screw (B), and then take out the sensor 6.3.35 Disassembly of waste toner cartridge sensor...

  • Page 100: Disassembly Of Fuser Probe Sensor

    6.3.36 Disassembly of fuser probe sensor Open the rear cover, use a six-angle screwdriver (T10) to remove one screw on the fuser sensor, and then use tweezers to pry up the right buckle, disconnect the cable and take out the sensor 6.3.37 Disassembly of manual feed sensor Use a six-angle screwdriver (T10) to remove the 4 fixing screws at the bottom of the printer, and...

  • Page 101: Precautions For Replacement Of Spare Parts

    Precautions for replacement of spare parts: 7.1 Manually performing the calibration function after replacing any accessories 7.1.1 Calibration method (FB model) When the environment where your printer is used changes greatly, the printer may automatically perform color calibration for better printing results. In case of ghosting or large color difference, you can manually calibrate colors as follows: 1.
  • Page 102 Note: • When your printer performs a certain amount of print jobs, it will automatically perform color calibration. • When you replace the laser toner cartridge with a new one, the printer will automatically perform color calibration. Page:...

  • Page 103: Maintenance Instructions For Replacement Of Controller Board, Laser, Idc Spare Parts

    7.1.3 Maintenance instructions for replacement of controller board, laser, IDC spare parts When replacing the controller board, laser (LSU) and IDC (toner spot sensor) spare parts of this series of machines, the corresponding calibration data of the spare part must be imported into the printer prior to use, otherwise the printing quality effect may be affected, and the operation is as follows: 7.1.3.1 Instructions for controller board replacement...
  • Page 104 1. Enter the SN of the IDC that the printer uses finally in the after-sales system interface, and click “Download IDC Parameter File” and save it; 2. Enter the printer SN in the after-sales system interface, click “Download IDC has been replaced, Calibration Data File”...
  • Page 105 7.1.3.2 Instructions for laser LSU replacement 1. Obtaining maintenance information Maintenance history Information to be obtained There is no LSU or IDC history It is necessary to obtain the serial number SN of the LSU to be replaced for maintenance records the printer, and the serial number SN of the current printer.
  • Page 106 7.1.3.3Instructions for IDC replacement 1. Obtaining maintenance information Maintenance history Information to be obtained There is no IDC history maintenance It is necessary to obtain the serial number SN of the LDC to be replaced for records of the the printer. machine It is necessary to obtain the serial number SN of the LDC...

  • Page 107: Appendix 1 Circumference Of Each Roller Of This Equipment

    Appendix 1 Circumference of Each Roller of this Equipment Names Portrait cycle mm First transfer roller 25.12 Second transfer roller 59.66 Stretch roller 28.26 ITU backup roller 43.96 ITU cleaning backup roller 43.96 ITU driving roller 64.7782 Transfer belt 655.004 Photoconductor drum 75.4 Developer roller...

  • Page 108: Appendix 2 Descriptions Of Product Serial Number

    Appendix 2 Descriptions of Product Serial Number All machines are affixed with their own product serial number labels. The meaning of the product serial number code and the location of the label are described below. Code meaning: Production Date Commodity Machine code serial number...

  • Page 109: Appendix 3 Descriptions Of Terminologies In This Manual

    Appendix 3 Descriptions of Terminologies in this Manual The following table includes the explanations of all the terminologies involved in this manual. Terminologies Explanations Safety standard for a kind of laser products Liquid crystal display Scanner Number of pages printed per minute HVPS High voltage power supply board LVPS...
