Garden-Series Model G6
SKU - SL-MODELG7-L
INSTALLATION GUIDE
REV: 2.0_09/2024

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Garden Series and is the answer not in the manual?

Questions and answers

Related Manuals for saunalife Garden Series

Summary of Contents for saunalife Garden Series

  • Page 1 Garden-Series Model G6 SKU - SL-MODELG7-L INSTALLATION GUIDE REV: 2.0_09/2024...

  • Page 2: Table Of Contents

    Contents Installation requirements ....................... 3 Transport ............................4 Protective OSB box disassembling ....................5 Disassembling steps: ........................... 5 Final assembly ..........................7 Needed tools for the assembly ......................7 Included assembly materials ....................... 7 Final Assembly Instructions: ....................... 8 Instructions for adjusting sauna door ................... 12 Adjusting the hinge ...........................

  • Page 3: Installation Requirements

    Installation requirements The base or foundation for Sauna must be leveled and stable. Sauna must be at least 3 inches higher from the surrounding ground. All base beams must have a support under them. Weight of the sauna: 3306 lbs. Recommendation: We recommend placing Sauna on concrete blocks or strips that have a compressed gravel underneath.

  • Page 4: Transport

    Transport Sauna is packed into protective OSB box. Do not disassemble the OSB box until after lifting the sauna into its final location. Total weight of the sauna with OSB box is 3637 lbs. Sauna can be lifted from above with crane: Sauna can be lifted from below with forklift:...

  • Page 5: Protective Osb Box Disassembling

    Protective OSB box disassembling Dismantle the protective OSB box before final assembly. OSB boards are fastened with small screws covered with round stickers. The OSB boards, including the screw cover stickers, are painted black. The stickers prevent paint from getting into the screw heads and the screws are much easier to find. Disassembling steps: 1.
  • Page 6 5. Once all the boards around the sauna have been removed, you can start dismantling the board supports at the top and bottom of the sauna 6. At the top are OSB strips with battens that are attached to the top with screws 7.

  • Page 7: Final Assembly

    Final assembly Final assembly shall be organized by the client. All electrical connections must be made by certified electrician. Final assembly includes installing of the: • Parapet metal; • Decorative base boards; • Rainwater system; • Main power cable; (+ control unit) •...

  • Page 8: Final Assembly Instructions

    Final Assembly Instructions: Sauna cannot be exposed to the weather conditions without parapet metals Parapet metals installation. 1. Unwrap metals carefully, do not scratch paint surface with sharp objects 2. Place the metal on the parapet. The longer piece is for the front and the shorter ones are for the left and right sides.
  • Page 9 Rainwater system installation 1. Begin the assembly process by securing gutter brackets to the wall using 5x70 woodscrews, with 2 screws per bracket. Distribute the gaps equally between the five brackets along the length of the gutter. 2. The brackets should be mounted with a slight downward angle towards the drain outlet 3.
  • Page 10 6. Install downpipe brackets use 5x70 screws two or each on the centerline of the drop outlet. Use 5x70 screws two or each. Brackets are required on both ends of the downpipe - at the connection with the drop outlet and at the elbow outlet.
  • Page 11 Base boards installation Purpose of the base boards is decorative. Baseboards have been cut in the correct length and have pre-drilled holes in them. When installing the baseboards, make sure you are using the right board on the correct side. Attach each baseboard to the base beams using 4x50mm (black) woodscrews.

  • Page 12: Instructions For Adjusting Sauna Door

    Instructions for adjusting sauna door Adjusting the hinge The door hinge N3248-110 TMKSS use allows for vertical and horizontal adjustment. Door leaf adjustment up/down, see Figure 3. Remove the protective cap 1 from one door hinge (using a 5mm Allen key). By turning the Allen bolt 2 below it clockwise (using a 5mm Allen key).

  • Page 13: Sauna Electrical Connections

    Sauna electrical connections Saunas have been prewired. All electrical connections for LED lights, speakers and ventilator are made in factory (Figure 1). All the electrical connections must be made by certified electrician. Electrical connections 1. There are two electrical boxes (120 VAC and 240 VAC) located behind wooden door on the side of the sauna.
  • Page 14 Drill a 2.5-inch hole through the wall panel as indicated in Figure 4. Inside the cavity box, the string leading to the electrical box should be used to pull the controller cable through conduit after tying them together. Always follow the manufacturer's installation manual to select the appropriate cable for the installation.
  • Page 15 Figure 4.
  • Page 16 Figure 5.
  • Page 17 Figure 1. SAUNALIFE G7 CONNECTIONS DONE IN FACTORY TOP BENCH EX.LIGHTS 1 1 1 1 5 5 5 5 4 4 4 4 5 5 4 4 DOOR SENSOR LOWER BENCH XLG-200-12A CONTROL CABINET POWER SR-2501NEA PE L1 L2 VENTILATOR...
  • Page 18 Figure 2. SAUNALIFE G7 CONNECTIONS AFTER SAUNA INSTALLATION TOP BENCH EX.LIGHTS 1 1 1 1 5 5 5 5 4 4 4 4 5 5 4 4 DOOR SENSOR LOWER BENCH XLG-200-12A CONTROL CABINET POWER SR-2501NEA PE L1 L2 VENTILATOR...

  • Page 19: User Guide

    User guide Using and connecting Bluetooth speakers 1. Make sure that Sauna is connected to external power 2. There is a red light on the speakers if they are not connected to any device 3. Turn on Bluetooth on your phone and search for available devices 4.

  • Page 20: Maintenance

    Maintenance General upkeep ⎯ After each use, ensure that the sauna is properly ventilated. Turn on the ventilation system to help dry out any excessive moisture. ⎯ Gently clean the surfaces of benches and cladding with a damp cloth to remove any sweat or dirt buildup.

  • Page 21: Warranty Conditions For Saunum Saunas

    SAUNA LIFE SAUNA LIMITED LIFETIME WARRANTY Harvia Heater / Stone Chart Sauna Life extends this Limited Warranty solely to the original retail consumer purchaser of any Sauna Life sauna purchased from one of its authorized resellers. LIMITED LIFETIME SAUNA WARRANTY Sauna Life warrants that the Sauna Life sauna shall be free from defects in workmanship under normal conditions of use and service for the lifetime of the sauna for residential applications after delivery to the original retail purchaser.

  • Page 22: Spare Parts

    Spare parts Order Part Name Part Picture number 9050023 Feed-through terminal block 9050025 Feed-through terminal block 9050043 End and partition plate for terminal block 9050059 Feed-through terminal block 9050060 Feed-through terminal block 9050061 End and partition plate for terminal block 9050063 Cross-connector for terminal block 9050075...
  • Page 23 Order Part Name Part Picture number 2020002 Tangential fan NCA 60-120/23 9040007 LED STRIP LIGHT 9040004 Exterior light Forest 9040008 GU10 spot light bulb 9050005 Speakers 4030035 Parapet metal right 4030036 Parapet metal left 4030011 Parapet metal front 4030014 Roof drip metal 4030041 Window metal 4030015...
  • Page 24 Order Part Name Part Picture number 4030005 Rainwater down pipe 4030006 Rainwater down pipe bracket 4030007 Rainwater outlet 4030002 Rainwater drop outlet 7060003 Cladding board (1 pc 2,4m) 7060004 Base board (1 pc 2,8m) 2020012 Air outlet cover 260x190mm 2020011 Air inlet cover 140x190mm 7050038 Cladding board STS3 15x120mm (1 pc 2,7m)
  • Page 25 Order Part Name Part Picture number 7070066 Floor grid board 28x28mm (1 pc 2,4m) 2020008 Air inlet cover 2020006 Air outlet cover 2010003 Trap cover 5030018 Door hinge 5030017 Cylinder accessory set 5030016 Lock case 5030015 Lock cylinder 5030014 Concealed door closer 5030013 Door handle...
  • Page 26 PROJECT DRAWING Spare Parts ADDRESS CONTRACT SCALE FORMAT DESIGNER DATE 26.04.2024 CODE CHECK PAGE...
  • Page 27 SKU - SL-MODELG7-L REV: 2.0_09/2024...
