- Page 1 SKU - SL-MODELG6-L INSTALLATION GUIDE REV: 2.0_09/2024...
- Page 2 Contents ............
-
Page 3: Installation Requirements
Installation requirements The base or foundation for Sauna must be leveled and stable. Sauna must be at least 3 inches higher from the surrounding ground. All base beams must have a support under them. Weight of the sauna: 2645 lbs. Recommendation: We recommend placing Sauna on concrete blocks or strips that have a compressed gravel underneath. - Page 4 Transport Sauna is packed into protective OSB box. Do not disassemble the OSB box until after lifting the sauna into its final location. Total weight of the sauna with OSB box is 2976 lbs. Sauna can be lifted from above with crane: Sauna can be lifted from below with forklift:...
- Page 5 Protective OSB box disassembling Dismantle the protective OSB box before final assembly. OSB boards are fastened with small screws covered with round stickers. The OSB boards, including the screw cover stickers, are painted black. The stickers prevent paint from getting into the screw heads and the screws are much easier to find. Disassembling steps: 1.
- Page 6 5. Once all the boards around the sauna have been removed, you can start dismantling the board supports at the top and bottom of the sauna 6. The sauna has a wooden frame at the top that is not attached to the sauna itself.
-
Page 7: Final Assembly
Final assembly Final assembly shall be organized by the client. All electrical connections must be made by certified electrician. Final assembly includes installing of the: • Parapet metal; • Decorative base boards; • Rainwater system; • Main power cable; (+ control unit) •... - Page 8 Final Assembly Instructions Base boards installation Purpose of the base boards is decorative. Baseboards have been cut in the correct length and have pre-drilled holes in them. When installing the baseboards, make sure you are using the right board on the correct side. Attach each baseboard to the base beams using 4x50mm (black) woodscrews.
- Page 9 Rainwater system installation 1. Begin the assembly process by securing gutter brackets to the wall using 5x70 woodscrews, with 2 screws per bracket. Distribute the gaps equally between the five brackets along the length of the gutter. 2. The brackets should be mounted with a slight downward angle towards the drain outlet 3.
- Page 10 6. Install downpipe brackets use 5x70 screws two or each on the centerline of the drop outlet. Use 5x70 screws two or each. Brackets are required on both ends of the downpipe - at the connection with the drop outlet and at the elbow outlet.
- Page 11 Instructions for adjusting sauna door Adjusting the hinge Remove covers from the hinges from the inside of the sauna to reveal the bolts Unscrew the bolts a bit on both hinges to loosen the door leaf Adjust the door leaf position inside the frame. If gaps between door glass and frame are equal and parallel then tighten the bolts Place back the hinge cover.
- Page 12 Sauna electrical connections Saunas have been prewired. All electrical connections for LED lights, speakers and ventilator are made in factory (Figure 1). All the electrical connections must be made by certified electrician. Electrical connections 1. There are two electrical boxes (120 VAC and 240 VAC) located behind wooden door on the side of the sauna.
- Page 13 Drill a 2.5-inch hole through the wall panel as indicated in Figure 4. Inside the cavity box, the string leading to the electrical box should be used to pull the controller cable through conduit after tying them together. Always follow the manufacturer's installation manual to select the appropriate cable for the installation.
- Page 14 Figure 4.
- Page 15 Figure 5.
- Page 16 Figure 1. SAUNALIFE G6 CONNECTIONS DONE IN FACTORY 1 1 1 1 5 5 4 4 5 5 4 4 POWER DOOR SENSOR BENCH LIGHT XLG-200-12A SR-2501NEA PE L1 L2 VENTILATOR...
- Page 17 Figure 2. SAUNALIFE G6 CONNECTIONS AFTER SAUNA INSTALLATION 1 1 1 1 5 5 4 4 5 5 4 4 POWER DOOR SENSOR BENCH LIGHT XLG-200-12A SR-2501NEA PE L1 L2 VENTILATOR HEATER CONTROL BOX (connections according to manufacturer)
- Page 18 User guide Using and connecting Bluetooth speakers 1. Make sure that Sauna is connected to external power 2. There is a red light on the speakers if they are not connected to any device 3. Turn on Bluetooth on your phone and search for available devices 4.
-
Page 19: Maintenance
Maintenance General upkeep ⎯ After each use, ensure that the sauna is properly ventilated. Turn on the ventilation system to help dry out any excessive moisture. ⎯ Gently clean the surfaces of benches and cladding with a damp cloth to remove any sweat or dirt buildup. - Page 20 SAUNA LIFE SAUNA LIMITED LIFETIME WARRANTY Harvia Heater / Stone Chart Sauna Life extends this Limited Warranty solely to the original retail consumer purchaser of any Sauna Life sauna purchased from one of its authorized resellers. LIMITED LIFETIME SAUNA WARRANTY Sauna Life warrants that the Sauna Life sauna shall be free from defects in workmanship under normal conditions of use and service for the lifetime of the sauna for residential applications after delivery to the original retail purchaser.
-
Page 21: Spare Parts
Spare parts Order Part Name Part Picture number... - Page 22 Order Part Name Part Picture number...
- Page 25 PROJECT DRAWING Spare Parts ADDRESS CONTRACT SCALE FORMAT DESIGNER DATE 26.04.2024 CODE CHECK PAGE...
- Page 26 .com info@saunalife.com SKU - SL-MODELG6-L REV: 2.0_09/2024...
