- Page 1 Read the entire manual before assembly. � Get the tools you need. � April 2023 Garden Series Model G4 Outdoor Sauna...
- Page 2 Oc::i 2000 45x130 2490 2000 � � 45x65 2260 2000 45x130 2260 GROUNDFRAME 90x45 2380 FLOORBEAMS 45x45 2070 FLOORBEAMS 45x45 1990 FLOORBEAMS 45x45 1890 FLOORBEAMS 45x45 Purlins 2000 70x170 2490 WINDOW 765x1900 DOOR 800x1900 Garden Series Model G4 Outdoor Sauna...
- Page 3 Model G4 Outdoor Sauna 45x130 mm According to Spec FB/GF LAGERHOLZ 1995 TERRACE FLOOR BOARDS c::==::J 2090 0.84m TERRACE FLOOR BOARDS c::==::J 170 2490 PURLINS 7,3m 2913 ROOF BOARDS ( 1341 mm + 1572 mm ) � 140 2530 FRONTBOARD c::==::J 140 1550 GABLEBOARD...
- Page 4 Fasten the base frame with screws. If possible, fasten the base frame to the � Foundation Diagonals must be of the same lengths. � Drill holes before screws. � Use waterlevel and measuring tape Groundframe...
- Page 5 The wall plank must be 10 mm above the edge of the base frame. � The first wall plank row must be fixed with screws to the base frame. � First wall row...
- Page 6 Use hammer and hammer block. � Installing walls...
- Page 7 Use hammer and hammer block. � Install the positions below comletely. � Continue with new wall � details. Installing walls...
- Page 8 Use hammer and hammer block. � Step 1 Step 2 Step 3 Installing walls / Purlins...
- Page 9 Use hammer and hammer block. � Step 1 Step 2 Fasten the purlins with screws. � Make sure the upper side of the purlins is oblate. If necessary, adjust the tapping of the purlins. Fasten the gable parts with screws. � Purlins...
- Page 10 Install the ventilation grill in the back wall. � Step 1 Step 2 Fasten the roof boards with screws. Start � with the groove edge on the board. Ventilation grill/Roof boards...
- Page 11 Complete the installation of parts RB1 � Step 1 Step 2 Cut the last roof board to the correct width. � The edge must be aligned with the wall plank and the purlins. Roof boards...
- Page 12 Cut correct lengths and fasten frontboards fixing with � screws. Roof boards...
- Page 13 Install roof shingles, use small nails. � Step 1 Step 2 Fasten the frontboard with screws. � Cut the correct angle and fasten gableboards with screws. � Roof cover / Covering strips...
- Page 14 Fasten the floor / terrace boards with screws. � Cut the final floor/ terrace board to the correct � width. Cut the floor stripes on right angle and size, then � install with screws. � Floor / Terrace boards / Floor stripes...
-
Page 15: Door / Window
Slats can only be screwed to the door and window frame and not to � the wall. Door / Window... - Page 16 To fix the door and windows to the house use only slats. � Slats can only be screwed to the door and window frame and not to the wall. � Left / Right Up / Down In / Out Adjust the door. � Door / Window...
- Page 18 Element 1 Det 2 Det 3 Element 3 Element 2 Det 4 Det 1 Det 5...
- Page 19 25mm screws Element 3...
- Page 20 Drill the pilot holes for the screws 70mm 70mm screws screws 70mm 70mm 70mm screws screws screws 40mm 40mm 40mm 40mm screws screws screws screws Connect element 3 to the wall...
