- Page 1 Instruction Guide 4A81L Holman Rancho Cordova, CA 95742 800-343-7486 InstallationSupport@Holman.com 20221014R4 DATE: ________________...
-
Page 2: Table Of Contents
9/16” Socket and Wrench 1/2” Socket and Wrench Before You Begin Read all instructions prior to assembling or installing any Holman product. Always locate your installation locations prior to performing any work. Most times, it is easier to install on top of roof, after the mount kit has been installed. -
Page 3: Parts List
Instructions – 4A81L Parts List For Technical Support Call: 800-343-7486, Monday-Friday, 7AM - 4 PM (PST) Page 2... -
Page 4: Hardware
Instructions – 4A81L Hardware For Technical Support Call: 800-343-7486, Monday-Friday, 7AM - 4 PM (PST) Page 3... -
Page 5: Step 1 - Remove End Stops
Instructions – 4A81L DO NOT EXCEED MANUFACTURERS WEIGHT CAPACITY FOR ROOF! Step 1 – Remove End Stops If haven’t already done so, remove end stops from opposite end of both bows where the existing ladder rack is installed. Step 2 – Install Side Tube ... -
Page 6: Step 3 - Install Hanger Bracket
Instructions – 4A81L Be sure the bend is towards the front and to the outside of the vehicle as shown. Be sure to leave one square slot open at the rear of the J-tube assembly. Bolt the J-tube assembly to the rear bow using 5/16” x 2” carriage bolt, a 5/16” flat washer and a 5/16”... -
Page 7: Step 4 - Attach Clamp Tube And L-Bracket
Instructions – 4A81L Step 4 – Attach Clamp Tube and L-Bracket Place clamp and lock L bracket on top of installed bows. Do not install hardware now. Insert plastic bushings into the clamp and lock L bracket and the hanger bracket installed in Step 2, with flanges as shown so they cannot come out at a later time. -
Page 8: Step 5 - Mount Handle
Instructions – 4A81L Bolt clamp and lock L bracket to bows using 3/8” x 1” carriage bolt, 3/8” flat washer and a 3/8” lock nut as shown. (This view shown is without clamp tube.) TIGHTEN. Step 5 – Mount Handle ... -
Page 9: Step 7 - Mount Ladder Hook
Instructions – 4A81L Step 7 – Mount Ladder Hook Bolt ladder hook bracket to the bow in the orientation shown using a 3/8” x 1” carriage bolt, a 3/8” flat washer and a 3/8” lock nut. Be sure the bracket is square to the bow. - Page 10 Instructions – 4A81L Angle Pad Orientations and Locations Standard Flipped Orientation Orientation Clamp Mechanism Orientation and Angled Pad Positions Examples of Ladder Clamps Firmly Against Ladder Rungs Be sure to position the ladder hook in a way so the hook clamps the ladder tight into place. A tight fit ensures the ladder cannot fall off the rack.
