Summary of Contents for Crystal Image Technologies PD-F117A-MIL
- Page 1 Rugged Portable Display Part# PD-F117A-MIL User Manual - 1 -...
- Page 2 This manual, covering various aspects of the equipment such as installation, setup and cascade, will help you make full use of this portable display. Please read this manual carefully and operate the equipment according to the manual to avoid damage to this product its accessories.
-
Page 3: Table Of Contents
Table of Contents Product Specification...……………………………………………………………-4- Front View..…….....……………………………………….....……-5- Rear View..…….....……………………………………….....….…-6- Connection..…….....………………………………………....……-7- LCD KVM Console and KVM Cascade Installation….........…-8- LCD OSD Menu Setup..……………………………………….....……-9- Certificate.…….....………………………………………......……-10- - 3 -... -
Page 4: Product Specification
1. Product Specifications Brightness 1000cd/m2 Contrast 650:1 Angle of visibility 140°(H),120°(V) Color display 262K Keyboard and Mouse Sealed 104-keys IP65 silicone keyboard and touchpad with backlight Local Control Keyboard/Mouse USB 2.0 Terminal DVI-D 24 pin DVI-D female connector HD-15 female connector HDMI HDMI female Video resolution... -
Page 5: Front View
2. Front view Part Function Description Rubber bumpers High brightness LCD display 104-keys IP65 silicone keyboard and touchpad with backlight Rubber handle Aluminum locker Slide to lock/unlock LCD panel LCD OSD button LCD button to control Screen Display position and image setting. -
Page 6: Rear View
3. Rear view Component Function Description DC Power port Lock connector for external power adapter (AC100~240V) HDMI port Connect to server or KVM Power Switch Turn on/off equipment main power Connect to server or KVM VGA port USB port Connect to server for keyboard and mouse DVI port Connect to server or KVM USB 2.0... -
Page 7: Connection
4. Connection Please follow the installation drawing and instructions below for standard installation: * Please Shu down the Power of Equipment Needs to be Connected * Please Pay Attention to Earthing of Equipment The standard installation is completed, and portable display can be powered on. Then power on connected hosts. -
Page 8: Lcd Kvm Console And Kvm Cascade Installation
5. LCD KVM Console and KVM Cascade Installation The portable display can be directly connector to another KVM Switch as cascade to perform unified management all connected hosts. Please follow the installation drawing and instructions for standard installation: Make sure to power off all equipment to be connected and existing equipment. Switching slide switch on USB position Use an USB / VGA cable to connected the LCD and KVM switch console port. -
Page 9: Lcd Osd Menu Setup
6. LCD OSD Menu Setup OSD Control buttons LCD OSD can establish and setup LCD display. Setup instructions of four buttons are as follows: Button Functions Turn on or off the LCD Display POWER Activate OSD menu, select a menu and press MENU key to confirm the MENU selection and enter the submenu. -
Page 10: Certificate
7. Certificates This product has been tested and is proved to meet requirements of Grade B electronic devices and specifications of Section 15 of FCC certification. Please observe following two conditions in operation that: (1) The equipment will not generate any harmful interruption. (2) If the equipment is interrupted, it may cause unnecessary operations.
