Page 1: User Manual
LCD display solutions User Manual 21.5” FHD LCD AP-F21 Aluminum front bezel NAP-F21 Front NEMA4 / IP65 OP-F21 Universal Mounting Open Frame Designed and manufactured by Austin Hughes... - Page 2 Legal Information First English printing, October 2002 Information in this document has been carefully checked for accuracy; however, no guarantee is given to the correctness of the contents. The information in this document is subject to change without notice. We are not liable for any injury or loss that results from the use of this equipment.
-
Page 3: Table Of Contents
Contents < Part. 1 > AP-F21 / NAP-F21 Package Content Structure Diagram & Dimension P.2 - 3 Mounting Hardware & Installation P.4 - 5 OP-F21 < Part. 2 > Package Content Structure Diagram & Dimension P.7 - 8 Mounting Hardware & Installation <... -
Page 4: Before Installation
Before Installation ■ It is very important to mount the equipment in a suitable cabinet or on a stable surface. ■ Make sure the place has a good ventilation, is out of direct sunlight, away from sources of excessive dust, dirt, heat, water, moisture and vibration. Unpacking The equipment comes with the standard parts shown in package content. - Page 5 < Part 1 > < 1.1 > Package Content - AP / NAP-F21 21.5" FHD LCD Display AP-F21 / NAP-F21 21.5" FHD LCD display X 1 6ft VGA cable X 1 Power adapter X 1 Power cord X 1 Mounting hardware X 1 pack...
-
Page 6: Front View
< 1.2 > Structure Diagram - AP / NAP-F21 Front view AP-F21 NAP-F21 Rear view Rear case LCD panel Protective 3mm glass 6mm aluminum front bazel Audio speaker, pair LCD membrane Remote sensor Power HDMI DVI-D S-Video RCA Audio in - in - out... -
Page 7: Ap-F21 / Nap-F21
< 1.2 > Dimension - AP / NAP-F21 21.5” FHD LCD Display Front View Side View AP-F21 NAP-F21 Rear View UNIT : mm 1mm = 0.03937 inch Bottom View... - Page 8 < 1.3 > Panel Mount Installation - AP / NAP-F21 M4*50mm screw M4*6mm screw Mounting bracket x 8 pcs x 8 pcs x 4 pcs Hardware set part no. UV-BK#2 Steps ■ Install 4 mounting brackets with 8 x M4*6mm screws ■...
- Page 9 < 1.3 > VESA mount Installation - AP / NAP-F21 21.5” FHD LCD Display M4 screw VESA mount ( 100*100mm ) ■ Hardware and M4*4 pcs for VESA mount are not provided UM-UV-F21-Q112V1 www.austin-hughes.com...
-
Page 10: Package Content
< Part 2 > < 2.1 > Package Content - OP-F21 OP-F21 21.5" FHD LCD display X 1 6ft VGA cable X 1 Power adapter X 1 Power cord X 1 UM-UV-F21-Q112V1 www.austin-hughes.com... - Page 11 < 2.2 > Structure Diagram - OP-F21 21.5” FHD LCD Display Front view OP-F21 Rear view Rear case LCD panel Audio speaker, pair Universal open frame mounting LCD membrane Extended remote sensor membrane cable ( 66cm from AD board to sensor end ) Power HDMI DVI-D...
-
Page 12: Part. 2 > Op-F21
< 2.2 > Dimension - OP-F21 Front View Side View OP-F21 UNIT : mm Rear View 1mm = 0.03937 inch Bottom View... - Page 13 < 2.3 > Installation - OP-F21 21.5” FHD LCD Display ( I ) Universal mount ( II ) VESA mount ( 100*100mm ) M4 screw Hardware and M4*4 pcs for VESA mounting are not provided...
-
Page 14: Product Specifi Cations
< Part 3 > < 3.1 > Product Specifi cations Mechanical AP / NAP-F21 OP-F21 Design Front Panel Black, RAL 9005 Rear Casing Dark grey, RAL 7037 Dark grey, RAL 7037 VESA Mounting 100 x 100mm 100 x 100mm Other Mounting Panel mount Universal mount Protection... - Page 15 21.5” FHD LCD Display Safety Approval FCC & CE Regulatory Operating Temperature 0 to 50°C degree Environmental Conditions Humidity 20~90%, non-condensing Storage Temperature -5 to 60°C degree Humidity 5~90%, non-condensing Shock 10G acceleration (11ms duration) Vibration 5~500Hz 1G RMS random Physical AP / NAP-F21 OP-F21...
-
Page 16: Osd For Basic Inputs ( Vga + Dvi-D )
< 3.2 > OSD for Basic Inputs ( VGA + DVI-D, for AD board 2.1 ) Power light Green = On Orange = Power saving Membrane Switch Function Power on / off LCD Display the OSD menu Scrolls through menu options and adjusts the displayed control (To auto adjustment by pressing the button for 5 seconds) Exit the OSD screen... -
Page 17: Osd For Upgrade Inputs ( Vga, Dvi-D, Hdmi, Av, Audio )
< 3.2 > OSD for Upgrade Inputs 21.5” FHD LCD Display ( VGA, DVI-D, HDMI, AV and Audio, for AD board 3.0 ) Picture Picture mode : Standard / Vivid / Soft / User mode to choose Brightness : Adjust background black level of the screen image Contrast : Adjust the difference between the image background (black level) and the foreground (white level) - Page 18 < 3.2 > OSD for Upgrade Inputs ( VGA, DVI-D, HDMI, AV and Audio, for AD board 3.0 ) Auto search : Automatically search Manual search : Search the TV manual Fine tune : Fine tune the TV signal Color system : Adjust the TV color Sound system : Adjust the TV sound...
-
Page 19: Part 4 > Options
< Part 4 > Options 21.5” FHD LCD Display < 4.1 > Option Table Basic Options AP / NAP SDI *** HDMI S-Video + RCA Audio Touchscreen MCS multi-display control *** DC Power MIL-type / lockable connector Quad display TV * ( 1 ) The user can only select either SDI or MCS inputs. -
Page 20: Options : 3G / Hd / Sd-Sdi Input
< 4.2 > Options : 3G / HD / SD-SDI input Austin Hughes’ SDI input is an ideal solution for the broadcast- grade video and high resolution CCTV market. Designed for use with UltraView Full HD 1080p and ultra high resolution 1920 x 1200 LCD displays, Austin Hughes provides a SDI input module without using additional space or power and it comes standard with a 2-year warranty. -
Page 21: Multi-Display Control
< 4.3 > Options : MCS 21.5” FHD LCD Display More control is always good. Especially when it is necessary and easy. Austin Hughes provides MCS solution to control the OSD of ( Multi-display Control ) various UltraView LCD display up to 64 units. The RS-232C is used for the communication between the PC and the fi... - Page 22 < 4.3 > Options : MCS P.18 UM-UV-F21-Q112V1 www.austin-hughes.com...
-
Page 23: Options : Touchscreen & Driver
< 4.4 > Options : Touchscreen & driver 21.5” FHD LCD Display F21.5" USB Touchscreen Specifi cation e-Resistive e-Capacitive Multi-touch Model TMC2 5-Wire Resistive Capacitive Projected Capacitive Technology Single Single Dual Touch Point Stylus or Finger Finger Finger Method ≤ 50g / Stylus=R0.8 ≤... - Page 24 < 4.4 > Options : Touchscreen & driver TMC2 Driver Connect the USB cable from the USB port on the LCD to a computer. The touch screen supports easy Plug-and-Play operations. There is no need to install additional drivers on the computer. <...
- Page 25 < 4.6 > Options : MIL-type or Lockable Connector 21.5” FHD LCD Display Input Part no. MIL Standard MS3470W8-33P MIL - DTL - 26482 MIL - type DC Power Connector ( Male ) MS3470W14-15P MIL - DTL - 26482 ( Male ) There are several additional MIL DC and VGA connector types with varying design characteristics to meet cost considerations and to provide users with the most design fl...
- Page 26 < 4.7 > Options : Quad Display QD Specifi cation Item Description Model Number QD (NTSC) QD (PAL) Number of Color 16.7 M 16.7 M Imaging System NTSC Resolution 1024 x 525 1024 x 625 Refresh Rate 1.0 Vpp, 75 Ohm x 4 Camera Input Video Input 1.0 Vpp, 75 Ohm x 1...
- Page 27 < 4.8 > Options : TV ( Analog ) 21.5” FHD LCD Display Audio Power S-Video HDMI DVI-D in - in - out PC Video ( 1 ) For TV option, the AD board will be upgraded to version 3.0, and this comes standard with HDMI, DVI-D, VGA, S-Video, RCA , audio inputs and RC-2 remote controller.
- Page 28 How to Use RC-2 Remote Controller 21.5” FHD LCD Display INPUT MUTE -/-- AUTO FREEZE MENU SELECT ASPECT SLEEP ENTER BACK EXIT SWAP SOURCE POSITION AUDIO Select the source INPUT Switches on or off the TV Only use in TV mode. Select channels. For channel numbers 10 0 - 9 and above, enter the second digit within two seconds.
