- Page 1 dedicated KVM switch and rackmount screen technology User Manual RMD-152-17 / 19 1U 17” / 19” Rackmount Display Drawer Short depth version Options : - AV / DVI-D / HDMI - Audio / DC power - Touchscreen UM-CV-RP1417-Q411V2 www.rackmountsales.com...
- Page 2 Legal Information First English printing, October 2002 Information in this document has been carefully checked for accuracy; however, no guarantee is given to the correctness of the contents. The information in this document is subject to change without notice. We are not liable for any injury or loss that results from the use of this equipment.
-
Page 3: Table Of Contents
Contents RP-17 RP-19 < Part 1 > Package Contents Structure Diagram & Dimension Installation P.3 - 4 On-screen Display Operation ( OSD ) LCD Specifi cation Options : AV / DVI-D / HDMI P.7 - 8 : Audio / DC Power : Touchscreen &... -
Page 4: Part 1
Before Installation ■ It is very important to mount the equipment in a suitable cabinet or on a stable surface. ■ Make sure the place has a good ventilation, is out of direct sunlight, away from sources of excessive dust, dirt, heat, water, moisture and vibration. Unpacking The equipment comes with the standard parts shown in package content. -
Page 5: Structure Diagram & Dimension
< 1.2 > Structure Diagram & Dimension RP-1417 / 1419 LCD panel Carry handle to release the 2-pt lock “One Man” Installation Slide 2-point lock LCD OSD membrane Product Dimension Packing Dimension Gross Model (W x D x H) (W x D x H) Weight Weight 441.6 x 480 x 44.4 mm... -
Page 6: Installation
< 1.3 > Installation - How to install One Man Installation Slides Step Rear side ■ Attach the left and right mounting bracket to rack Right bracket 19” mounting rails. ■ Adjust the rear mounting bracket to fi t your rack. ■... - Page 7 < 1.3 > Installation - How to Use the Slides RP-1417 / 1419 Figure 1. ■ A black arrow release button is located on the front of each slide. (shown in Figure 1). ■ Figure 2. Pull and hold the black arrow button on either side of the display drawer to unlock.
-
Page 8: On-Screen Display Operation ( Osd )
< 1.4 > On-screen Display Operation ( OSD ) Power light Green = On Orange = Power saving Membrane Switch Function Power on / off LCD Display the OSD menu Scrolls through menu options and adjusts the displayed control (To auto adjustment by pressing the button for 5 seconds) Exit the OSD screen Toggle analog, digital &... -
Page 9: Lcd Specifi Cation
< 1.5 > LCD Specifi cation RP-1417 / 1419 Item Description LCD Manufacturer Diagonal Size 17" TFT 19" TFT Max. Resolution 1280 x 1024 1280 x 1024 Brightness (cd/m²) Color Support 16.7 M 16.7 M Contrast Ratio (typ.) 1000:1 1000:1 Viewing Angle (H/V) 160˚... -
Page 10: Options : Av / Dvi-D / Hdmi
< 1.6 > Options : AV / DVI-D / HDMI / Audio / DC power AV Option ( BNC + S-Video ) ■ Option includes 1 x 6ft S-Video cable Power S-Video DVI-D Option ■ Option includes 1 x 6ft DVI-D cable Power DVI-D The product dimension will change from 480mm to 530mm in depth for DVI-D option... - Page 11 < 1.6 > Options : Touchscreen & driver RP-1417 / 1419 e-Resistive Specifi cation Model -17TRB / -17TRS -19TRB / -19TRS Screen size 17" 19" Interface USB / serial Optical transmittance 80% ± 3% Surface hardness ≥3H (JIS K5400) Operating system Windows 98 / 2000 / ME / XP / NT / CE, DOS, Linux e-Capacitive Specifi...
