- Page 1 Rack Mount Display Monitor - 4K User Manual RMP-161-4K17 7U 17.3 inch Rack Mount Display Monitor Options : - DC 9~36V power input - Touchscreen - AR hardness glass...
-
Page 2: Table Of Contents
Contents RMB-17W-4K < Part. 1 > Package Content Structure Diagram & Dimension P.1 - 2 Installation < Part. 2 > Specifi cations / OSD Product Specifi cations P.4 - 5 On-screen Display Operation ( OSD ) < Part. 3 > Options Touchscreen... - Page 3 Before Installation ■ It is very important to mount the equipment in a suitable cabinet or on a stable surface. ■ Make sure the place has a good ventilation, is out of direct sunlight, away from sources of excessive dust, dirt, heat, water, moisture and vibration. Unpacking The equipment comes with the standard parts shown in package content.
-
Page 4: Package Content
< Part 1 > < 1.1 > Package Content Rack mount monitor unit X 1 - 1.8 M Display port cable X 1 - 1.8 M HDMI cable X 1 - Power cord X 1 < 1.2 > Structure Diagram Front view 1 LCD PANEL 2 LCD OSD... - Page 5 < 1.2 > Dimension Product Dimension Packing Dimension Gross Model (W x D x H) (W x D x H) Weight Weight 9 kg 7 kg RMP-161-4K17 482 x 62 x 310 mm 620 x 210 x 400 mm...
-
Page 6: Installation
< 1.3 > Rack Mounting Installation Step Mount the RMP-161-4K17 display panel with M6 screw set 4 x M6 screw set are required M6 screw sets are not provided. Step 90° tilt adjustment while mounted in rack: +45°~-45°... -
Page 7: Product Specifi Cations
< Part 2 > < 2.1 > Product Specifi cations RMP-161-4K17 Manufacturer Panel Panel Size ( diagonal ) 17.3 inch widescreen Display pixel ( dots x lines ) 3840 x 2160 / 1920 x 1200 / 1920 x 1080 Brightness ( typ. ) Contrast Ratio ( typ.) - Page 8 Applicable Display Port Input PC Signal 3840 x 2160 x 60Hz Format 1920 x 1080 x 60Hz 1600 x 1200 x 60Hz 1360 x 768 x 60Hz 1280 x 1024 x 60 / 75Hz 1280 x 768 x 60Hz 1024 x 768 x 60 / 70 / 75Hz 800 x 600 x 60 / 72 / 75Hz 720 x 400 x 70Hz 640 x 480 x 60 / 72 / 75Hz...
-
Page 9: On-Screen Display Operation ( Osd )
< 2.2 > On-screen Display Operation ( OSD ) Menu/Enter Source Video input selection... -
Page 10: Part. 3 > Options 3.1 Touchscreen
< Part 3 > < 3.1 > Options : Touchscreen F21" USB Touchscreen Specifi cation e-Resistive e-Capacitive Model 5-Wire Resistive Capacitive Technology Single Single Touch Point Stylus or Finger Finger Method ≤ 50g / Stylus=R0.8 ≤ 50g Activation Force 10 million touches 300 million touches Durability 15 ms...
