Summary of Contents for Crystal Image Technologies LCD-AP-K17
- Page 1 LCD display solutions User Manual 17” 4K 3480 x 2160 LCD LCD-AP-K17 Aluminum front bezel LCD-NAP-K17 Front NEMA4 / IP65 LCD-DP-K17 Aluminum front cover LCD-OP-K17 Universal open frame UM-UV-621-K17-Q318V2 www.rackmountsales.com...
- Page 2 Legal Information First English printing, August 2018 Information in this document has been carefully checked for accuracy; however, no guarantee is given to the correctness of the contents. The information in this document is subject to change without notice. We are not liable for any injury or loss that results from the use of this equipment.
-
Page 3: Table Of Contents
Contents LCD-AP-K17 / NAP-K17 < Part. 1 > Package Content Structure Diagram & Dimension P.2 - 3 Mounting Hardware & Installation P.4 - 5 LCD-DP-K17 < Part. 2 > Package Content Structure Diagram & Dimension P.7 - 8 Mounting Hardware & Installation LCD-OP-K17 <... - Page 4 Before Installation ■ It is very important to mount the equipment in a suitable cabinet or on a stable surface. ■ Make sure the place has a good ventilation, is out of direct sunlight, away from sources of excessive dust, dirt, heat, water, moisture and vibration. Unpacking The equipment comes with the standard parts shown in package content.
-
Page 5: Lcd-Ap-K17 / Nap-K17
< Part 1 > < 1.1 > Package Content - LCD-AP / NAP-K17 17” 4K LCD Display LCD-AP-K17 / NAP-K17 17” 4K LCD Display X 1 6ft DP cable X 1 Power adapter X 1 Power cord X 1 Mounting hardware X 1 pack... - Page 6 < 1.2 > Structure Diagram - LCD-AP / NAP-K17 Front view Side view LCD-AP-K17 NAP-K17 Rear case Rear view LCD panel 6mm aluminum front bazel Audio speaker, pair LCD membrane Product Dimension Packing Dimension Gross Model (W x D x H)
- Page 7 < 1.2 > Dimension - LCD-AP / NAP-K17 17” 4K LCD Display Front View Side View LCD-AP-K17 LCD-NAP-K17 Rear View UNIT : mm 1mm = 0.03937 inch M6*4 pc s Bottom View UM-UV-621-K17-Q318V2 www.rackmountsales.com...
- Page 8 < 1.3 > Panel Mount Installation - LCD-AP / NAP-K17 M4*50mm screw M4*6mm screw Mounting bracket x 8 pcs x 8 pcs x 4 pcs Hardware set part no. UV-BK#2 Steps ■ Install 4 mounting brackets with 8 x M4*6mm screws ■...
- Page 9 < 1.3 > VESA mount Installation - LCD-AP / NAP-K17 17” 4K LCD Display VESA mount ( 100*100mm ) ■ Hardware and M6*4 pcs for VESA mount are not provided UM-UV-621-K17-Q318V2 www.rackmountsales.com...
- Page 10 < Part 2 > < 2.1 > Package Content - LCD-DP-K17 LCD-DP-K17 17” 4K LCD Display X 1 6ft DP cable X 1 Power adapter X 1 Power cord X 1 Basic I/O Audio Power HDMI 1.4 HDMI 2.0 UM-UV-621-K17-Q318V2 www.rackmountsales.com...
- Page 11 < 2.2 > Structure Diagram - LCD-DP-K17 17” 4K LCD Display Front view Side view LCD-DP-K17 Rear view Rear case LCD panel Front cover Audio speaker, pair LCD membrane Product Dimension Packing Dimension Gross Model (W x D x H) (W x D x H) Weight Weight...
-
Page 12: Part. 2 > Lcd-Dp-K17
< 2.2 > Dimension - LCD-DP-K17 Front View Side View LCD-DP-K17 Rear View UNIT : mm 1mm = 0.03937 inch Bottom View UM-UV-621-K17-Q318V2 www.rackmountsales.com... - Page 13 < 2.3 > VESA Installation - LCD-DP-K17 17” 4K LCD Display VESA mount ( 100*100mm ) ■ Hardware and M6*4 pcs for VESA mount are not provided UM-UV-621-K17-Q318V2 www.rackmountsales.com...
-
Page 14: Package Content
< Part 3 > < 3.1 > Package Content - LCD-OP-K17 LCD-OP-K17 17” 4K LCD Display X 1 6ft DP cable X 1 Power adapter X 1 Power cord X 1 Basic I/O Audio Power HDMI 1.4 HDMI 2.0 UM-UV-621-K17-Q318V2 P.10 www.rackmountsales.com... - Page 15 < 3.2 > Structure Diagram - LCD-OP-K17 17” 4K LCD Display Side view Front view LCD-OP-K17 Rear view Rear case LCD panel Audio speaker, pair Universal open frame mounting LCD membrane Product Dimension Packing Dimension Gross Model (W x D x H) (W x D x H) Weight Weight...
-
Page 16: Part. 3 > Lcd-Op-K17
< 3.2 > Dimension - LCD-OP-K17 Front View Side View LCD-OP-K17 Rear View UNIT : mm 1mm = 0.03937 inch M6*4 pc s Bottom View UM-UV-621-K17-Q318V2 P.12 www.rackmountsales.com... - Page 17 < 3.3 > Installation - LCD-OP-K17 17” 4K LCD Display ( I ) Universal mount ( II ) VESA mount ( 100*100mm ) Hardware and M6*4 pcs for VESA mounting are not provided UM-UV-621-K17-Q318V2 P.13 www.rackmountsales.com...
-
Page 18: Product Specifi Cations
< Part 4 > < 4.1 > Product Specifi cations Mechanical AP-K17 NAP-K17 DP-K17 OP-K17 Design Protection 6mm front cover NEMA 4 / IP 65 front cover open frame Front Panel Black, RAL 9005 Rear Casing Black, RAL 9005 VESA Mounting 100 x 100mm Universal Other Mounting... - Page 19 < 4.1 > Product Specifi cations 17” 4K LCD Display Environmental Operating Temperature 0 to 55°C degree Conditions Humidity 20~90%, non-condensing Altitude 16,000 ft Storage / Temperature -20 to 60°C degree Non-operating Humidity 5~90%, non-condensing Altitude 40,000 ft Shock 10G acceleration (11ms duration) Vibration 10~300Hz 0.5G RMS random vibration Physical...
-
Page 20: On-Screen Display Operation ( Osd )
< 4.2 > On-screen Display Operation ( OSD ) Power light Green = On Orange = Power saving Membrane Switch Function Power on / off LCD Display the OSD menu Scrolls through menu options and adjusts the displayed control (To auto adjustment by pressing the button for 5 seconds) Exit the OSD screen Toggle analog, digital &... - Page 21 < 4.2 > On-screen Display Operation ( OSD ) 17” 4K LCD Display Picture Brightness : Adjust the screen brightness Contrast : Adjust the difference between the image background ( black level ) and the foreground ( white level ) Black level : Adjust background black level of the screen : Screen in power saving mode Position...
- Page 22 < 4.2 > On-screen Display Operation ( OSD ) 17” 4K LCD Display Reset Reset : Return the adjustment back to factory setting PIP mode : Enter into PIP / PBP setting - PIP MODE / PBP 2WIN ( Main screen + 1 sub screen ) / PBP 3WIN ( Main screen + 2 sub screen ) / PBP 4WIN ( Main screen + 3 sub screen ) Select the signal input of each sub screen...
-
Page 23: Picture In Picture ( Pip ) / Picture By Picture ( Pbp )
< 4.3 > How to Use Picture In Picture ( PIP ) / Picture By Picture ( PBP ) < 4.3.1 > Picture in Picture ( PIP ) Mode Display the Sub screen in the Main screen. OSD Menu → MISC → PIP Mode → Large / Small / OFF Main screen Sub screen Position... - Page 24 < 4.3 > How to Use Picture In Picture ( PIP ) / Picture By Picture ( PBP ) < 4.3.2 > Picture By Picture ( PBP ) Mode Display the Sub screen next to the Main screen. OSD Menu → MISC → PIP Mode → PBP Main screen Sub screen Size...
-
Page 25: Part 5 > Options
< Part 5 > Options 17” 4K LCD Display < 5.1 > Option Table Options AP / NAP Remote controller MCS multi-screen control Touchscreen MIL-type / lockable connector DC Power UM-UV-621-K17-Q318V2 P.21 www.rackmountsales.com... -
Page 26: Remote Controller ( Rc-2 )
< 5.2 > Remote Controller ( RC-2 ) INPUT MUTE -/-- FREEZE AUTO MENU SELECT ASPECT SLEEP ENTER EXIT BACK SWAP SOURCE POSITION AUDIO INPUT Select the source Switches on or off the TV Only use in TV mode. Select channels. For channel numbers 10 0 - 9 and above, enter the second digit within two seconds. - Page 27 < 5.3 > Options : 3G / HD / SD-SDI input 17” 4K LCD Display Crystal Image SDI input is an ideal solution for the broadcast- grade video and high resolution CCTV market. Designed for use with Crystal Image displays, a SDI input module can support up to 1080p @60Hz resolution without using additional space or power and it comes standard with a 2-year warranty.
- Page 28 < 5.4 > Options : MCS More control is always good. Especially when it is necessary and easy. Crystal Image provides MCS solution to control the OSD of ( Multi-display Control ) various CIT LCD displays up to 64 units. The RS-232C is used for the communication between the PC and the fi...
-
Page 29: Touchscreen & Driver
17” 4K LCD Display < 5.5 > Options : Touchscreen & driver K17" USB Touchscreen Specifi cation Model e-Resistive TPC-10 Multi-touch Technology Projected Capacitive 5-Wire Resistive Touch Point Single Input Type Finger or Capacitive Stylus Finger or Stylus Resolution 4096 x 4096 2048 x 2048 Touch Point Accuracy ±... -
Page 30: Dc Power
< 5.5 > Options : Touchscreen & driver K17TPC-10 Driver Connect the USB cable from the USB port on the LCD to a computer. The touch screen supports easy Plug-and-Play operations. There is no need to install additional drivers on the computer. TRB Driver Please follow the below steps to setup the touch screen:- Step 1. -
Page 31: Mil-Type Or Lockable Connector
< 5.7 > Options : MIL-type or Lockable Connector 17” 4K LCD Display Input Part no. MIL Standard MIL - type MS3470W8-33P MIL - DTL - 26482 DC Power Connector ( Male ) MS3470W14-15P MIL - DTL - 26482 ( Male ) There are several additional MIL DC and VGA connector types with varying design characteristics to meet cost considerations and to provide users with the most design fl... - Page 32 The company reserves the right to modify product specifi cations without prior notice and assumes no responsibility for any error which may appear in this publication. All brand names, logo and registered trademarks are properties of their respective owners. UM-UV-621-K17-Q318V2 P.28 www.rackmountsales.com...
