Page 1: User Manual
LCD display solutions User Manual 27” FHD 1920 x 1080 LCD LCD-AP-W27 Aluminum front bezel LCD-NAP-W27 Front NEMA4 / IP65 LCD-OP-W27 Universal Mounting Open Frame... -
Page 2: Legal Information
Legal Information First English printing, October 2002 Information in this document has been carefully checked for accuracy; however, no guarantee is given to the correctness of the contents. The information in this document is subject to change without notice. We are not liable for any injury or loss that results from the use of this equipment. -
Page 3: Table Of Contents
Contents < Part. 1 > LCD-AP-W27 / LCD-NAP-W27 Package Content Structure Diagram & Dimension P.2 - 3 Mounting Hardware & Installation P.4 - 5 < Part. 2 > LCD-OP-W27 Package Content Structure Diagram & Dimension P.7 - 8 Mounting Hardware & Installation <... -
Page 4: Before Installation
Before Installation ■ It is very important to mount the equipment in a suitable cabinet or on a stable surface. ■ Make sure the place has a good ventilation, is out of direct sunlight, away from sources of excessive dust, dirt, heat, water, moisture and vibration. Unpacking The equipment comes with the standard parts shown in package content. -
Page 5: Lcd-Ap-W27 / Lcd-Nap-W27
< Part 1 > < 1.1 > Package Content - AP / NAP-W27 27” FHD LCD Display LCD-AP-W27 / LCD-NAP-W27 27” FHD LCD display X 1 6ft VGA cable X 1 Power cord X 1 Remote controller X 1 Wall-mount bracket set X 1... -
Page 6: Structure Diagram & Dimension
Weight 699 x 68 x 438 mm 785 x 175 x 527 mm 16.8 kg 20.4 kg LCD-AP-W27 27.5 x 2.7 x 17.2 inch 30.9 x 6.9 x 20.7 inch 37 lbs 45 lbs 699 x 68 x 438 mm 785 x 175 x 527 mm 18.6 kg... - Page 7 < 1.2 > Dimension - AP / NAP-W27 27” FHD LCD Display Front View Side View AP-W27 NAP-W27 Rear View UNIT : mm 1mm = 0.03937 inch Bottom View UM-UV-621-W27-Q317V3 www.rackmountsales.com...
-
Page 8: Mounting Hardware & Installation
< 1.3 > Wall-mount Installation - AP / NAP-W27 Step Front wall-mount bracket ■ Install left & right front wall-mount brackets at the rear side of the LCD shown above. ■ M5 screw x 8 pcs included ( Left & right side ). Rear side Step Rear wall-mount bracket... - Page 9 < 1.3 > VESA mount Installation - AP / NAP-W27 27” FHD LCD Display M6 screw VESA mount ( 100*100mm ) ■ Hardware and M6*8 pcs for VESA mount are not provided UM-UV-621-W27-Q317V3 www.rackmountsales.com...
- Page 10 < Part 2 > < 2.1 > Package Content - OP-W27 OP-W27 27” FHD LCD display X 1 6ft VGA cable X 1 Power cord X 1 Remote controller X 1 Basic I/O Audio Power Audio HDMI DVI-D S-Video Video Audio in UM-UV-621-W27-Q317V3 www.rackmountsales.com...
-
Page 11: Structure Diagram & Dimension
< 2.2 > Structure Diagram - OP-W27 27” FHD LCD Display Front view OP-W27 Top view Rear case LCD panel Rear view Universal open frame mounting Audio speaker, pair LCD membrane Extended remote sensor membrane cable ( 66cm from AD board to sensor end ) Product Dimension Packing Dimension Gross... - Page 12 < 2.3 > Dimension - OP-W27 Front View Side View OP-W27 Rear View UNIT : mm 1mm = 0.03937 inch Bottom View UM-UV-621-W27-Q317V3 www.rackmountsales.com...
- Page 13 < 2.3 > Installation - OP-W27 27” FHD LCD Display ( I ) Universal mount ( II ) VESA mount ( 100*100mm ) M6 screw ■ Hardware and M6*8 pcs for VESA mount are not provided UM-UV-621-W27-Q317V3 www.rackmountsales.com...
-
Page 14: Part. 2 > Lcd-Op-W27
< Part 3 > < 3.1 > Product Specifi cations LCD-AP/NAP-W27 LCD-OP-W27 Mechanical Design Front Panel Black, RAL 9005 Rear Casing Black, RAL 9005 Black, RAL 9005 VESA Mounting 100 x 100mm 100 x 100mm Other Mounting Panel mount Universal mount Protection 3mm protective glass Manufacturer... - Page 15 < 3.1 > Product Specifi cations 27” FHD LCD Display Regulatory Safety FCC & CE certifi ed Environmental RoHS2 & REACH compliant Environmental Operating Temperature 0 to 55°C degree Conditions Humidity 20~90%, non-condensing Altitude 16,000 ft Storage / Temperature -20 to 60°C degree Non-operating Humidity 5~90%, non-condensing...
-
Page 16: On-Screen Display Operation ( Osd )
< 3.2 > On-screen Display Operation ( OSD ) Power light Green = On Orange = Power saving Membrane Switch Function Power on / off LCD Display the OSD menu Scrolls through menu options and adjusts the displayed control (To auto adjustment by pressing the button for 5 seconds) Exit the OSD screen Toggle analog, digital &... - Page 17 < 3.2 > On-screen Display Operation ( OSD ) 27” FHD LCD Display Audio Audio mode : Movie / Voice / Normal / Music mode to choose Volume : Adjust the volume of sound Bass : Set the value of bass sound Treble : Set the value of treble sound Balance :...
-
Page 18: Picture In Picture ( Pip ) / Picture By Picture ( Pbp )
< 3.3 > How to Use Picture In Picture ( PIP ) / Picture By Picture ( PBP ) < 3.3.1 > Picture in Picture ( PIP ) Mode Display the Sub screen in the Main screen. OSD Menu → MISC → PIP Mode → Large / Small / OFF Main screen Sub screen Position... - Page 19 27” FHD LCD Display < 3.3.2 > Picture By Picture ( PBP ) Mode Display the Sub screen next to the Main screen. OSD Menu → MISC → PIP Mode → PBP Main screen Sub screen Size LCD Monitor Main / Sub screen 1920 x 1200 955 x 716 1920 x 1080...
-
Page 20: Remote Controller ( Rc-2 )
< 3.4 > Remote Controller ( RC-2 ) INPUT MUTE -/-- FREEZE AUTO MENU SELECT ASPECT SLEEP ENTER BACK EXIT SWAP SOURCE POSITION AUDIO INPUT Select the source Switches on or off the TV Only use in TV mode. Select channels. For channel numbers 10 0 - 9 and above, enter the second digit within two seconds. -
Page 21: Part 4 > Options
< Part 4 > Options 27” FHD LCD Display < 4.1 > Option Table Options AP / NAP Touchscreen MCS multi-screen control MIL-type / lockable connector DC Power P.17 UM-UV-621-W27-Q317V3 www.rackmountsales.com... - Page 22 < 4.2 > Options : 3G / HD / SD-SDI input Austin Hughes’ SDI input is an ideal solution for the broadcast- grade video and high resolution CCTV market. Designed for use with UltraView displays, a SDI input module can support up to 1080p @60Hz resolution without using additional space or power and it comes standard with a 2-year warranty.
- Page 23 < 4.3 > Options : MCS 27” FHD LCD Display More control is always good. Especially when it is necessary and ( Multi-display Control ) easy. Austin Hughes provides MCS solution to control the OSD of various UltraView LCD display up to 64 units. The RS-232C is used for the communication between the PC and the fi...
-
Page 24: Projected Capacitive ( 10-Point Touch )
< 4.4 > Options : Touchscreen & driver W27" USB Touchscreen Specifi cation Model W27TPC-10 Multi-touch Technology Projected Capacitive Touch�Point Input Type Finger or Capacitive Stylus Resolution 2048 x 2048 Touch Point Accuracy ± 25 mm offset Response Speed Max. 20 ms Activation Force ≤... - Page 25 < 4.5 > Options : DC Power 27” FHD LCD Display Model 125V 250V Input rating Input voltage: 24-Volt 48-Volt 110-Volt 300-Volt Input range: 18 ~ 36V 36 ~ 75V 66 ~ 160V 180 ~ 425V Input current - No load 180 mA 90 mA 80 mA...
-
Page 26: Mil-Type Or Lockable Connector
< 4.6 > Options : MIL-type or Lockable Connector Input Part no. MIL Standard MIL - type MS3470W8-33P MIL - DTL - 26482 DC Power Connector ( Male ) MS3470W14-15P MIL - DTL - 26482 ( Male ) There are several additional MIL DC and VGA connector types with varying design characteristics to meet cost considerations and to provide users with the most design fl... -
Page 27: Tv ( Analog )
< 4.7 > Options : TV ( Analog ) 27” FHD LCD Display Audio Power Audio HDMI DVI-D S-Video Video Audio in For RC-2 remote controller specifi cations, please refer to P.16 P.23 UM-UV-621-W27-Q317V3 www.rackmountsales.com... - Page 28 The company reserves the right to modify product specifi cations without prior notice and assumes no responsibility for any error which may appear in this publication. All brand names, logo and registered trademarks are properties of their respective owners. UM-UV-621-W27-Q317V3 www.rackmountsales.com...
