Product Description
Figure 3.3
1
2
3
4
The connector housing is located on the shield.
3.3
Included in Delivery
The delivery package contains:
•
•
•
•
•
8
1
4
3
Ethernet connection layout
TD+
RD+
TD-
RD-
R2000 2D laser scanner
Quick start guide
Protective cover for MultiPort and Ethernet
3 x socket cap screws, M5 x 10
3 x washers, size 5
2
