Satel abax2 AFD-200 Manual
Wireless water flood detector
Hide thumbs
Also See for abax2 AFD-200:
- Manual (16 pages) ,
- Quick start manual (15 pages) ,
- Instructions manual (9 pages)
Related Manuals for Satel abax2 AFD-200
Summary of Contents for Satel abax2 AFD-200
- Page 1 Wireless water flood detector AFD-200 Firmware version 1.00 afd-200_en 05/24 SATEL sp. z o.o. • ul. Budowlanych 66 • 80-298 Gdańsk • POLAND tel. +48 58 320 94 00 www.satel.pl...
- Page 2 (the device was placed on the market after 13 August 2005). SATEL aims to continually improve the quality of its products, which may result in changes in their technical specifications and software. Current information about the changes being introduced is available on our website.
-
Page 3: Table Of Contents
CONTENTS Features ........................... 2 Description ........................2 Radio communication ....................... 2 Flooding detection ......................3 Detection of detector overturn ..................3 Energy saving mode (ECO) ....................3 Test mode ......................... 3 LED indicator and sounder ....................3 Battery status control ......................3 Electronics board ...................... -
Page 4: Features
AFD-200 SATEL The AFD-200 detector detects indoor water flooding. It can be installed in spaces where there are water facilities or in other spaces at risk of flooding. It is designed to work within the ABAX 2 two-way wireless system. The detector is supported by: •... -
Page 5: Flooding Detection
SATEL AFD-200 Flooding detection The detector reports flooding / end of flooding. The information is sent a few seconds after the event occurred. Detection of detector overturn When the detector is turned on its side or upside down, after 1 minute the LED indicator and the sounder will indicate trouble. -
Page 6: Installation
AFD-200 SATEL 4. Installation There is a danger of battery explosion when using a different battery than recommended by the manufacturer, or handling the battery improperly. Do not crush the battery, cut it or expose it to high temperatures (throw it into the fire, put it in the oven, etc.). -
Page 7: Specifications
SATEL AFD-200 3. Close the detector enclosure (note that the cover only fits in one position) and secure it with a screw (Fig. 5). 4. Place the detector in a puddle of water to make sure that an alarm is generated. - Page 8 AFD-200 SATEL ACU-280 ......................up to 600 m Battery........................CR123A 3 V Battery life expectancy ..................up to 5 years Temperature measurement range ............... -10°C...+55°C Temperature measurement accuracy ................±1°C Standby current consumption ..................45 µA Operating temperature range ................-10°C...+55°C Maximum humidity ......................
