- Page 1 ACD-220 Wireless curtain detector Firmware version 1.00 acd-220_en 10/21 SATEL sp. z o.o. • ul. Budowlanych 66 • 80-298 Gdańsk • POLAND tel. +48 58 320 94 00 www.satel.eu...
- Page 2 13 August 2005). The device meets the technical regulations of the Eurasian Customs Union. SATEL aims to continually improve the quality of its products, which may result in changes in their technical specifications and software. Current information about the changes being introduced is available on our website.
- Page 3 CONTENTS Features ........................... 2 Description ........................2 Radio communication ....................... 2 Alarms ..........................2 Operating modes ......................2 Energy saving mode (ECO) ....................3 Test mode ......................... 3 LED........................... 3 Supervision of motion detection system ................3 Battery status control ......................3 Electronics board ......................
- Page 4 The detector is designed for operation within the ABAX 2 two-way wireless system. It is supported by: ACU-220 / ACU-280 controller with firmware version 6.03 (or newer), ...
- Page 5 The LED is enabled in the test mode which makes it easier to test the detector. For how to enter and exit the test mode, see the ABAX 2 controller manual. The LED will flash for about 5 seconds after the battery is inserted to indicate warm-up of the detector.
- Page 6 ACD-220 SATEL 4 Selecting a mounting location Do not install the detector outdoors (A). Do not point the detector towards heat sources (B), air conditioners (C) or fans (D). Install the detector in a place where the expected direction of the intruder movement will be across the coverage pattern (Fig.
- Page 7 4. Place the detector at its future mounting location. 5. Check the level of signal received from the detector by the ABAX 2 controller. If the signal level is lower than 40%, select another mounting location. Sometimes, it is sufficient to shift the device ten or twenty centimeters.
- Page 8 ACD-220 SATEL 6 Specifications Operating frequency band........ 868,0 MHz ÷ 868,6 MHz / 915 MHz – 928 MHz Radio communication range (in open area) ACU-220 ....................... up to 2000 m ACU-280 ....................... up to 1200 m Battery........................CR123A 3 V Battery life expectancy ..................
