- Page 1 Smart plug ASW-200 Firmware version 1.02 asw-200_en 05/24 SATEL sp. z o.o. • ul. Budowlanych 66 • 80-298 Gdańsk • POLAND tel. +48 58 320 94 00 www.satel.pl...
- Page 2 13 August 2005). The device meets the technical regulations of the Eurasian Customs Union. SATEL aims to continually improve the quality of its products, which may result in changes in their technical specifications and software. Current information about the changes being introduced is available on our website.
-
Page 3: Table Of Contents
CONTENTS Features ........................... 2 Description ........................2 Button ..........................3 LED indicator ........................3 Radio communication ....................... 3 Operating modes ......................4 Protection against overload and overheating ..............4 Start-up ..........................4 Configuring the LED indicator settings ................5 Specifications ........................5... -
Page 4: Features
ASW-200 SATEL The ASW-200 smart plug is used to remote control electrical appliances. The device is available in two versions: • ASW-200 E with E type socket (EURO), • ASW-200 F with F type socket (SCHUKO). The plug is designed for operation within the ABAX 2 / ABAX two-way wireless system. -
Page 5: Button
SATEL ASW-200 LED indicator. Button The button is used to: • control the plug (available functions depend on the operating mode – see “Operating modes”), • configure the LED indicator (see “Configuring the LED indicator settings”), • block / unblock the capability to add the plug to the system (press and hold for 10 seconds). -
Page 6: Operating Modes
ASW-200 SATEL Operating modes You can select the operating mode when configuring the ASW-200 plug settings (see the controller / control panel manual). mode 0 – remote control only. Pressing the button does not control the plug (appliance connected to it) but information is sent to the controller whenever the button is pressed. -
Page 7: Configuring The Led Indicator Settings
SATEL ASW-200 If you need to perform any service or maintenance work on the appliance, disconnect it from the ASW-200 plug first. Leaving the appliance connected when the plug is inserted into the 230 VAC socket causes a risk of electric shock. - Page 8 ASW-200 SATEL Weight: ASW-200 E ......................... 60 g ASW-200 F ......................... 61 g...
