Satel Abax2 ASD-200 Manual
Wireless smoke and heat detector
Hide thumbs
Also See for Abax2 ASD-200:
- Manual (16 pages) ,
- Quick start manual (15 pages) ,
- Instructions manual (9 pages)
Related Manuals for Satel Abax2 ASD-200
Summary of Contents for Satel Abax2 ASD-200
- Page 1 Wireless smoke and heat detector ASD-200 Firmware version 2.02 asd-200_en 11/24 SATEL sp. z o.o. • ul. Budowlanych 66 • 80-298 Gdańsk • POLAND tel. +48 58 320 94 00 www.satel.pl...
- Page 2 13 August 2005). The device meets the technical regulations of the Eurasian Customs Union. SATEL aims to continually improve the quality of its products, which may result in changes in their technical specifications and software. Current information about the changes being introduced is available on our website.
-
Page 3: Table Of Contents
CONTENTS Features ........................... 2 Description ........................2 Radio communication ....................... 2 Fire alarm ......................... 3 Operating modes ......................3 Detector test ........................4 Tamper ..........................4 Test mode ......................... 4 LED indicator ........................4 Sounder ..........................4 Energy saving mode (ECO) ....................4 Detection of optical chamber soiling ................. -
Page 4: Features
ASD-200 SATEL The ASD-200 multisensor detector can detect the early stages of fire development when there is some visible smoke and/or temperature rise. It is designed for operation within the ABAX 2 / ABAX two-way wireless system. This manual applies to the detector with electronics version 1.2, which is supported by:... -
Page 5: Fire Alarm
SATEL ASD-200 Fire alarm Smoke detection An optical method is used for the detection of visible smoke. When the concentration of smoke in the optical chamber exceeds a given threshold, an alarm is triggered. The smoke sensor operating parameters are modified depending on the temperature changes recorded by the heat sensor (thermistor). -
Page 6: Detector Test
ASD-200 SATEL Detector test If you want to test operation of the detector, press the test / reset button (Fig. 1). A short sound will be heard. After a few seconds, the fire alarm should be triggered. Tamper Opening the enclosure (opening the tamper switch) is treated as tamper. -
Page 7: Selecting A Mounting Location
SATEL ASD-200 Selecting a mounting location • The detector is designed for indoor installation. • The detector should be installed in location close to the building / apartment exit (e.g. in the hall, lobby etc. – Fig. A and B). - Page 8 ASD-200 SATEL There is a danger of battery explosion when using a different battery than recommended by the manufacturer, or handling the battery improperly. Do not crush the battery, cut it or expose it to high temperatures (throw it into the fire, put it in the oven, etc.).
-
Page 9: Maintenance
LED indicator indicates fouling of the chamber (2 short flashes during periodical communication with controller / control panel). 1. Start the service mode in the control panel (if the controller is connected to a SATEL alarm control panel). - Page 10 ASD-200 SATEL 2. Remove the cover locking screw. 3. Turn the cover counter-clockwise (Fig. 6) and remove it (Fig. 7). 4. Remove the battery. 5. Pull the release lever (Fig. 8) to unlock the electronics module and turn it counter- clockwise (Fig.
-
Page 11: Battery Replacement
When the detector indicates low battery (3 short flashes of the LED indicator and 3 short beeps every 30 seconds), the battery must be replaced. 1. Start the service mode in the control panel (if the controller is connected to a SATEL alarm control panel).
