Warning
closed-loop or spade-type with upturned lugs. These terminations should be the appropriate
size for the wires and should clamp both the insulation and conductor. (To see translated
versions of this warning, refer to the Regulatory Compliance and Safety Information
document that accompanied your router.)
Caution
contact screws. The recommended torque is 8.2 0.4 inch-lb .
Warning
switch handle and reinstate power by moving the handle of the circuit breaker to the ON
position. (To see translated versions of this warning, refer to the Regulatory Compliance
and Safety Information document that accompanied your router.)

Connecting to a Network

This section explains how to connect the router to your network. The Ethernet or Token
Ring ports are used to connect the router to a LAN. The synchronous serial and ISDN ports
are used to connect the router to a WAN.
The cables required to connect the router to a network are not provided with the router. For
ordering information, refer to the section "Obtaining Service and Support" in the
"Overview of the Router" chapter. For cable pinouts, refer to the appendix "Cable
Specifications."
Although the illustrations in this section show the model 2513 router, the procedures are
the same for all of the router models.
Warning
lightning activity. (To see translated versions of this warning, refer to the Regulatory
Compliance and Safety Information document that accompanied your router.)
When stranded wiring is required, use approved wiring terminations, such as
Do not overtorque the terminal block captive thumbscrew or terminal block
After wiring the DC power supply, remove the tape from the circuit breaker
Do not work on the system or connect or disconnect cables during periods of
Connecting to a Network
Installing the Router 3-13
