Synchronous Serial Cable Assemblies and Pinouts
Table C-10
60 Pin
J1-7
J1-8
J1-3
J1-4
J1-5
J1-6
J1-26
J1-25
J1-15
J1-16
V.35
Figure C-9 shows the V.35 cable assembly. Table C-11 lists the DTE pinouts. Table C-12
lists the DCE pinouts. Arrows indicate signal direction: —> indicates DTE to DCE, and
<— indicates DCE to DTE.
C-16 Router Installation and Configuration Guide
EIA/TIA-449 DCE Cable Pinouts (DB-60 to DB-37) (Continued)
Signal Description
DTR/DSR+ Twisted pair no. 4
DTR/DSR–
DSR/DTR+ Twisted pair no. 2
DSR/DTR–
DCD/DCD+ Twisted pair no. 3
DCD/DCD–
RxC/TxCE+ Twisted pair no. 10
RxC/TxCE–
Circuit_GND Twisted pair no. 8
Circuit_GND
Direction 37 Pin Signal
—> J2-11 DM+
—> J2-29 DM–
<— J2-12 TR+
<— J2-30 TR–
—> J2-13 RR+
—> J2-31 RR–
<— J2-17 TT+
<— J2-35 TT–
_ J2-19 SG
_ J2-20 RC
