Figure C-9 V.35 Cable Assembly
J1-46
J1-45
J1-16
J1-15
J1-1
J1-30
J1-31
J1-60
Table C-11 V.35 DTE Cable Pinouts (DB-60 to 34-Pin)
60 Pin Signal
J1-49 MODE_1
J1-48 GND
J1-50 MODE_0
J1-51 GND
J1-52 MODE_DCE
J1-53 TxC/NIL
J1-54 RxC_TxCE
J1-55 RxD/TxD
J1-56 GND
J1-46 Shield_GND
J1-45 Circuit_GND
Shield –
J1-42 RTS/CTS
Shield –
Synchronous Serial Cable Assemblies and Pinouts
60-pin connector (J1)
Connectors are not to scale
Description Direction 34 Pin
Shorting group –
Shorting group –
Shorting group –
Single –
Twisted pair no. 12 –
–
Twisted pair no. 9 —>
–
15-pin connector (J2)
J2-B
J2-D
J2-A
J2-C
J2-KK
J2-MM
J2-LL
J2-NN
Signal
– –
– –
– –
J2-A Frame GND
J2-B Circuit GND
Shield –
J2-C RTS
Shield –
Cable Specifications C-17
