- Page 1 Manual | EN CP39xx-14xx-0010 Stainless steel Control Panel 2024-09-12 | Version: 1.6...
-
Page 3: Table Of Contents
Table of contents Table of contents 1 Notes on the documentation........................ 5 2 For your safety ............................ 6 Signal words............................ 6 Intended use ............................. 6 Fundamental safety instructions ....................... 7 Operator's obligation to exercise diligence.................. 7 Notes on information security...................... 8 3 Product overview ............................ - Page 4 Table of contents Version: 1.6 CP39xx-14xx-0010...
-
Page 5: Notes On The Documentation
Copyright © Beckhoff Automation GmbH & Co. KG. Publication of this document on websites other than ours is prohibited. Offenders will be held liable for the payment of damages. All rights reserved in the event of the grant of a patent, utility model or design. -
Page 6: For Your Safety
Exclusion of liability Beckhoff shall not be liable in the event of non-compliance with this documentation and thus the use of the devices outside the documented operating conditions. -
Page 7: Fundamental Safety Instructions
For your safety Fundamental safety instructions The following safety instructions must be observed when handling the device. Application conditions • Do not use the device under extreme environmental conditions. • Only use the device in hazardous areas if it is explicitly designed for this purpose. •... -
Page 8: Notes On Information Security
For your safety Notes on information security The products of Beckhoff Automation GmbH & Co. KG (Beckhoff), insofar as they can be accessed online, are equipped with security functions that support the secure operation of plants, systems, machines and networks. Despite the security functions, the creation, implementation and constant updating of a holistic security concept for the operation are necessary to protect the respective plant, system, machine and networks against cyber threats. -
Page 9: Product Overview
Product overview Product overview The Control Panels of the CP39xx-14xx-00x0 series in stainless steel finish the strict hygiene requirements of the pharmaceutical, food and packaging industries. They can be used as control and operating devices directly in the field. The control panels are designed for installation on a 48 mm mounting arm system. The control panels have the following features: •... -
Page 10: Structure
Fig. 2: CP39xx-1400-0010 structure Table 1: Legend CP39xx-1400-0010 structure Component Description Optional mounting arm adapter Beckhoff adapter for installation on the mounting arm from below or above Side cover Access to the connection compartment Display and touch screen glass Operating the control panel... - Page 11 Product overview Table 2: Legend CP39xx-1401-0010 & CP39xx-1414-0010 structure Component Description Optional mounting arm adapter Beckhoff adapter for installation on the mounting arm from below or above Side cover Access to the connection compartment Cover push button extension Access to the wiring of the push button extension...
-
Page 12: Interface Description
Emergency stop connection CP39xx-1414-0010 If you have ordered the control panel with a Beckhoff mounting arm adapter, the interfaces are located on the back of the device inside the mounting arm adapter. You must first gain access to the interfaces. The procedure is the same, regardless of whether you have ordered the mounting arm adapter with upwards or downwards orientation. - Page 13 Product overview Fig. 5: Access connection compartment ð You now have access to the connection compartment. CP39xx-14xx-0010 Version: 1.6...
-
Page 14: Usb
Product overview 3.2.1 In the connection compartment of the control panel, there is a USB interface behind a screw cap for connecting peripheral devices with a USB connection. The USB standard 2.0 is supported. 4 3 2 1 Fig. 6: USB interface pin numbering Table 4: USB interface pin assignment Connection Vbus... -
Page 15: Cp-Link 4 Input
Product overview 3.2.2 CP-Link 4 input All control panels of the CP39xx-14xx-0010 series have a CP-Link 4 input in the form of an 8-pin M12 socket. Via the interface, the control panel can be connected to an industrial PC at a distance of up to 100 m. The connection can be made either directly with an industrial PC with a corresponding PCIe module or indirectly via an intermediate transmitter box. - Page 16 Product overview CP-Link 4 with transmitter box If the industrial PC is not equipped with a PCIe module, a transmitter box is required for connecting a control panel. The CU8802-000x transmitter boxes (Two Cable Display Link) and CU8803-000x (One Cable Display Link) are available for this purpose.
- Page 17 Product overview Fig. 11: CP-Link 4. CU8803-000x The following ordering options are available for the transmitter boxes: • CU8802-0000: DVI-to-DVI cable included in the box • CU8802-0001: DisplayPort to DVI cable included with box • CU8803-0000: DVI-to-DVI cable included in the box •...
-
Page 18: Power Supply Cp39Xx-1400-0010 & Cp39Xx-1414-0010
There should be at least 22 V at the power supply plug of the control panel, so that the device remains switched on during voltage fluctuations. You can obtain a replacement plug from your Beckhoff Sales using the following ordering option: •... -
Page 19: Power Supply Cp39Xx-1401-0010 And Wiring Push Button Extension
Product overview 3.2.4 Power supply CP39xx-1401-0010 and wiring push button extension The Control Panel CP39xx-1401-0010 is supplied with a nominal input voltage of 24 V. The power supply and the wiring of the push button extension are connected via the 19-pin M23 socket. Fig. 13: Power supply and wiring pin numbering Table 7: Power supply and wiring pin assignment Signal... -
Page 20: Emergency Stop
Product overview 3.2.5 Emergency stop The 4-pin M12 socket is used to connect the emergency stop in the push button extension. Fig. 14: Emergency stop pin numbering Table 8: Emergency stop pin assignment Signal Normally closed contact 1 Normally closed contact 1 Normally closed contact 2 Normally closed contact 2 Version: 1.6... -
Page 21: Name Plate
Product overview Name plate The name plate provides information about the control panel equipment. The name plate shown here serves only as an example. Fig. 15: Name plate Table 9: Legend name plate Description Model: The last four digits indicate the device generation Serial number (BTN) Date of manufacture Display... -
Page 22: Accessories
Control Panels of the CP39xx-14xx-0010 series, with which you can replace the seals and screws of the Beckhoff mounting arm adapters C9900-M759 and C9900-M764 as well as the mounting arm tubes C9900-M735 and C9900-M736. Check the seals of the mounting arm adapters and mounting arm tubes regularly for leaks, as they protect the connections and cables of the control panels from aggressive cleaning agents, water and dirt. - Page 23 Product overview Fig. 17: Push button extension seal The C9900-E295 option is also available for the control panels with push button extension. This is an RFID reader. This is integrated via USB and mounted under the front laminate of the push button extension. Fig. 18: RFID reader CP39xx-14xx-0010 Version: 1.6...
-
Page 24: Commissioning
You can either order a Beckhoff protective film individually and fit it yourself retrospectively, or you can order the film for fitting directly ex factory. Please refer to the price list for the available protective films according to the display size of your device. -
Page 25: Transport And Unpacking
4. Check your delivery for completeness by comparing it with your order. 5. Check the contents for visible shipping damage. 6. In case of discrepancies between the package contents and the order, or in case of transport damage, please inform Beckhoff Service (see Chapter 10.1 Support and Service) CP39xx-14xx-0010 Version: 1.6... -
Page 26: Mounting
• C9900-M736: holder for 48 mm tube (must be welded) The following chapters explain the procedure for mounting the options mentioned on the control panel. Dimensions The dimensions of the control panel can be found on the Beckhoff website: https://www.beckhoff.com/de- de/support/downloadfinder/suchergebnis/?c-1=27833209 All dimensions are in mm. -
Page 27: Installing The Mounting Arm Adapter
Commissioning 4.2.1 Installing the mounting arm adapter Before mounting the Beckhoff mounting arm adapter (C9900-M759), you must decide whether it should be aligned downwards or upwards. Fig. 19: Orientation of the mounting arm adapter To mount the mounting arm adapter on the control panel, follow the steps below: 1. -
Page 28: Installation Of Mounting Arm Adapter Plate
Commissioning Fig. 21: Installing the mounting arm adapter ð You have installed the mounting arm adapter. 4.2.2 Installation of mounting arm adapter plate You have the option of installing the adapter plate (C9900-M764) between the control panel and the mounting arm adapter. This allows you to tilt the panels by +10 ° or -10 °. The ordering option consists of two parts, the adapter plate (1) and the wedge (2). - Page 29 Commissioning Fig. 23: Mounting wedge 4. Screw the adapter plate back onto the wedge using the four M5 screws (section C). 5. Use the latching lugs on the adapter plate for further mounting of the mounting arm adapter (section D). Fig. 24: Mounting adapter plate ð...
-
Page 30: Mounting Arm Tube Installation
The mounting procedure is the same in both cases. You can either order a tube holder with a 48 mm tube already welded on from Beckhoff or a tube holder where you have to weld the tube yourself (see chapter 4.2 Mounting [} 26]). -
Page 31: Connecting The Control Panel
Commissioning Connecting the control panel CAUTION Risk of electric shock Dangerous touch voltages can lead to electric shock. To avoid electric shock, observe the following: • Never connect or disconnect the device cables during a thunderstorm. • Provide protective earthing for handling the device. To make the device ready for operation, you have to connect it. -
Page 32: Circuit Diagrams
Commissioning 4.3.1 Circuit diagrams The following circuit diagrams are used to plan the wiring for the Control Panels CP39xx-1401-0010 and CP39xx-1414-0010. Fig. 27: Circuit diagram CP39xx-1401-0010 Version: 1.6 CP39xx-14xx-0010... - Page 33 Commissioning Fig. 28: Circuit diagram CP39xx-1414-0010 CP39xx-14xx-0010 Version: 1.6...
-
Page 34: Grounding The Control Panel
Commissioning 4.3.2 Grounding the control panel Potential differences are minimized and electrical currents are diverted to the ground through grounding or potential equalization of electronic devices. This is to prevent dangerous touch voltages and electromagnetic interference. The PE protective earth connection (see Fig. 29) is located in the connection compartment on the rear of the control panel and is used to ensure both protective earthing and functional earthing of the device. -
Page 35: Connecting Cables And Power Supply
When connecting the device to an industrial PC with UPS output, Beckhoff recommends using this for the connection. In the case of CP-Link 4, connect the CU880x transmitter boxes to the UPS output of the PC. - Page 36 Commissioning Fig. 30: XAE Project 2. Click I/O on the left in the tree view, and then right-click Devices. 3. In the context menu click Scan. Fig. 31: Scan device 4. First select the device that was found and confirm the selection with OK. Version: 1.6 CP39xx-14xx-0010...
- Page 37 Commissioning Fig. 32: Select device 5. Confirm the request with Yes, in order to scan for box modules. Fig. 33: Scan for box modules 6. Confirm the request whether to enable FreeRun with Yes. The device is inserted as a box in the tree view and displayed with the respective inputs/outputs (e.g.
-
Page 38: Decommissioning
Decommissioning Decommissioning NOTICE Hardware damage due to power supply A connected power supply can cause damage to the device during disassembly. • Disconnect the power supply from the device before starting to disassemble it. As part of the decommissioning of the device, you must first disconnect the power supply and cables. Afterwards, you can dismount the device from the mounting arm. -
Page 39: Disassembly And Disposal
Decommissioning Disassembly and disposal Before you can remove the control panel from the mounting arm tube, you must first disconnect the power supply and the cables (see chapter 5.1 Disconnecting the power supply and cables [} 38]). Disassembly mounting arm tube NOTICE Damage to property due to falling down If the control panel is suspended from the ceiling and you undo the set screw of the mounting arm adapter... - Page 40 Decommissioning Fig. 36: Disassembly mounting arm adapter ð You have successfully removed the mounting arm adapter from the control panel. Disassembly of mounting arm adapter plate To remove the mounting arm adapter plate from the control panel, follow the steps below: 1.
-
Page 41: Maintenance
You can clean the front screen of the device during operation. In order to avoid inadvertent touch entries when doing this, you must first set the device to "Cleaning Mode" with the help of the Beckhoff Control Tool. Also make sure that you not only clean the display area, but also the edge of the glass pane. Impurities in... - Page 42 Maintenance Fig. 38: Select "Cleaning Mode" You can set the duration for which the panel PC should remain in "Cleaning Mode". The period can be set between 5 and 120 seconds. Right-click the sun symbol again and click "Options". Now select the appropriate duration (see Fig.).
-
Page 43: Troubleshooting
Measures No control panel function Lack of power supply to the control Check the power supply cable panel Call Beckhoff Service Other cause The control panel only works Defective backlight in the display Call Beckhoff Service partially or only temporarily (e.g. -
Page 44: Technical Data
21.5-inch display 1920 x 1080 Supply voltage 24 V (20.4- 28.8 V Power consumption Data sheet power consumption and power loss in the download finder: https://www.beckhoff.com/en-en/support/download-finder/search- result/?download_group=691754572 Emergency stop 1.30.273.511/0300 RAFI Rafix FS+ The emergency stop is reset by rotating Lifetime... - Page 45 Technical data Product designation CP39xx-14xx-0010 Transport and storage The same values for air humidity and shock resistance are to be observed during transport and storage as in operation. Suitable packaging of the control panel can improve the resistance to impact during transport.
-
Page 46: Chemical Resistance
Liquids and vapors that act on the device for several minutes must temperature not exceed a temperature of 45 °C on the control panel. Flush-mounted Beckhoff touch screens are resistant to many solvents. The following solvents have been explicitly tested. Solvent resistance... -
Page 47: 10 Appendix
33415 Verl Germany Phone: + 49 5246/963-0 email: info@beckhoff.de The addresses of the worldwide Beckhoff branches and agencies can be found on our website at http:// www.beckhoff.com/. You will also find further documentation for Beckhoff components there. CP39xx-14xx-0010 Version: 1.6... -
Page 48: Approvals
Appendix 10.2 Approvals Your device has at least the following approvals: • CE • EAC • UKCA • FCC You will find all other applicable approvals on the name plate of your device. FCC approvals for the United States of America FCC: Federal Communications Commission Radio Frequency Interference Statement This device was tested and complies with the limits for a digital device of class A, according part 15 of the FCC regulations. - Page 50 More Information: www.beckhoff.com/cp39xx-cp79xx-stainless-steel-control-panels Beckhoff Automation GmbH & Co. KG Hülshorstweg 20 33415 Verl Germany Phone: +49 5246 9630 info@beckhoff.com www.beckhoff.com...
