Operating Guide | iC7-Automation Functional Safety

Saving to Device

4.4.7
After configuring the safety parameters for the application, save them to the device.
1. In MyDrive® Insight, navigate to Setup & Service > Functional safety > Safety configuration > Save to device.
2. Click Accept.

The parameters are verified and the status is updated from Ready to Verify.

Validating and Generating a Commissioning Report

4.4.8
For drives with functional safety option +BEF2, a commissioning report can be generated using MyDrive® Insight. The commissioning
report describes the values set for the safety-related parameters in the drive.
1.
In MyDrive® Insight, go to Device > Setup & Service > Functional safety > Validate report.
2.
Go to Device > Setup & Service > Functional safety > Commissioning Report to see the commissioning report.

After commissioning all safety functions, click the download icon on the upper right corner to download the report as
a PDF file. It is recommended to save a copy of the commissioning report to an external location.
3.
Store the acceptance test reports in the logbook of the machine.
The report must include:
A description of the safety application.
¢
A description and revisions of safety components that are used in the safety application.
¢
A list of all safety functions that are used in the safety application.
¢
A list of all safety-related parameters and their values. Listing parameters and values not related to safety is also
¢
recommended.
Documentation of startup activities, with references to failure reports and resolution of the failures.
¢
The test results for each safety function, all safety parameter values including the CRC value of the safety configuration,
¢
dates of the tests, and confirmation by the test personnel.
4.
Validate the commissioning report.
a.
Check that the hardware and configuration information is correct and that the software versions of safety-related
components and subsystems are correct.
b.
Check that the information of the commissioned module matches the information in the commissioning plan and
commissioning report.
IMPORTANT:
in the logbook of the machine.

Safe Fieldbus

4.5

PROFIsafe

4.5.1
PROFIsafe is an additional safety protocol on top of a standard transmission system (PROFINET/PROFIBUS). PROFIsafe uses several
technologies to ensure the validity and status of the fieldbus communication, making it reliable to use with safety devices.
These measures include:
Consecutive numbering.
l
36 | Danfoss A/S © 2024.08
After each change or maintenance to the system, new acceptance test reports must be stored
Functional Safety for Frequency Converters, Upgradable (+BEF2)
AQ319741840653en-000401 / 136R0268
