Operating Guide | iC7-Automation Functional Safety Functional Safety for Frequency Converters with STO, Not Upgradable (+BEF1)
Table 15: Operating Conditions for Functional Safety
Function
Operating altitude
Environmental conditions
Check the operating conditions for each drive from the product-specific design guide or operating guide. Latest versions of Danfoss
product guides are available for download at https://www.danfoss.com/en/service-and-support/documentation/.

Cable Specifications

3.5.4
Table 16: Cable Sizing for Connectors X31, X32
Wire type
Solid
Flexible
Flexible with ferrule w/o plastic sleeve
Flexible with ferrule w plastic sleeve
Danfoss A/S © 2024.08
(continued)
Data
According to the AC drive specifications.
The product must be installed in an environment corresponding to
EN IEC 61800-5-1:2017 PD2 – non-condensing.
For PD2 condensing environments, the product must be installed in IP54/NEMA 12 cabi-
net as per EN IEC 60529 AMD 2:2013, or equivalent.
2
Cross-section [mm (AWG)]
0.5–1.5 (24–16)
0.5–1.5 (24–16)
0.5–1.5 (24–16)
0.5 (24)
Stripping length [mm (in)]
10 (0.4)
10 (0.4)
10 (0.4)
10 (0.4)
