Work Light; Before Initial Operation; Charging Battery Pack - Cleco CellTek CTBA Instruction Manual

1
EN
Fig. 1-1: Product description CTBP(...)/CTBA(...)
1 Display
2 Function Keys
3 Output Drive
4

Work Light

5 LED showing OK or NOK
6 Reverse Switch
7 Start Trigger
8 Battery
9 SD Card
10 Micro USB-B Port
11 Socket + u-Guard (optional accessory)
Display
Default settings:
White Green
Tool running OK rundown
Work Light
Default settings:
Blue Green
Tool running OK rundown
2
only in mode when the Blink Lights When Tool in Re-
verse check box is activated at the controller under Navi-
gator > Advanced > Tool Group > I/O.
10
LED Display
Status light
If linking is selected on the controller:
6

Charging Battery Pack

Battery pack is supplied partly charged and must be
charged completely being used for the first time.
► See Original Instructions of Milwaukee charger.
► Do not use any other battery packs / chargers than
the following:
Battery pack 18 V
Order No.
T50-1000497
T50-1000498
Red
NOK rundown
Red
NOK rundown
P2543BA | REV D l 2024-06
Operating sta-
tus
Active
Active
2
Back-off
▬
Energy saver
▬ ▬
mode
Active/Setting:
▬
Linking
Active/Setting:
▬
Linking

Before Initial Operation

Capacity
2.0 Ah
5.0 Ah
Result after fas-
tening cycle
OK
NOK
–
–
Linking OK
Linking NOK
Apex Tool Group
