- Page 1 INSTALLATION INSTRUCTIONS For Seaview Light Bars: LTBSF, LTBSF2 & LTBSF4 Refer to website for most up to date instructions and videos. WWW.SEAVIEWGLOBAL.COM...
-
Page 2: Parts Included
PARTS INCLUDED LTB-SF PARTS (1420LNUT) (14SB) (516SB) (14NW) (SLADAPT3) (12X1SMSPHPH) (14021BHCS) (LTBSF4P) (LTBSFP) (516181BHCS) (M616SHCS_ (516183BHCS) PATCH) TOOLS NEEDED... - Page 3 Install your light, adapter or box onto the light bar by following the instructions that came with the optional accessory. Insert the four nuts into the adapter plate. This has most likely been done for you. Drill small pilot hole for #12 screws.
- Page 4 Secure the camera or search light assembly to the light bar using the four 1/4-20x1” bolts and nylon shoulder washers. Drill holes for M6 bolts. Refer to the drill template on the last page for drill location. Using an Allen wrench, screw in the six M6 - 16mm bolts to secure the camera to the...
- Page 5 Secure the camera or search light assembly to the light bar using the four 1/4-20x1” bolts and nylon shoulder washers. Insert the light bar into the light bar hole located on the back of the Seaview mount.
- Page 6 Using the four 5/16x1” bolts and nylon shoulder washers, secure the light bar by bolting it to the top plate. When using the Seaview #SP1-MOD or #SP2-MOD Spreader Kits use the 5/16x3” bolts.
- Page 8 EUROPEAN OFFICE Tel: 800-655-7922 Tel: +33 4 94 53 27 70 www.seaviewglobal.com www.seaviewprogress.com...
