- Page 1 INSTALLATION INSTRUCTIONS For Seaview Camera Mount: PM5-FMD-8 Refer to website for most up to date instructions and videos. WWW.SEAVIEWGLOBAL.COM...
- Page 2 PARTS INCLUDED TOOLS NEEDED Sudbury Elastomeric Marine Sealant is recommended. To purchase call 800-655-7922 or visit www.seaviewglobal.com...
- Page 3 Mark the four base holes for drilling. Drill the four holes. Using a hole saw, drill a hole for the cable.
- Page 4 Apply marine adhesive sealant to the top of the mount as shown. Place the adapter plate onto the mount making sure that the four mounting holes line up. Apply marine adhesive sealant to the inner edge of the adapter plate as shown.
- Page 5 Route the cables through the center channel and mount the camera to the adapter plate. Using the hardware that came with your camera secure the camera to the adpater plate. Apply marine adhesive sealant to the base of the mount.
- Page 6 Route the cables through the mounting surface. Place the mount onto the mounting surface. Apply marine adhesive sealant to the four nylon shoulder washers and insert into the four bolt holes on the base. Use your own hardware to secure mount into place.
