- Page 1 INSTALLATION INSTRUCTIONS For Seaview Light Bar Top: LTBU1ALED12 Refer to website for most up to date instructions and videos. WWW.SEAVIEWGLOBAL.COM...
-
Page 2: Parts Included
PARTS INCLUDED (LTBU1APLID) (LTBRVT) (LTBU1APBASE) (1058PFHSMS) (101PPHSMS) (10NW) TOOLS NEEDED Sudbury Elastomeric Marine Sealant is recommended. To purchase call 800-655- 7922 or visit www.seaviewglobal.com... - Page 3 Drill a hole to run cables for the light. This may have already been done for you. Apply marine adhesive sealant around the top of the light bar as shown, then slide on to the light bar. Apply marine adhesive sealant to the mounting holes.
- Page 4 Apply marine adhesive sealant into the groove as shown. Make sure the GPS & light wires are running through the lid and down the hole into the light bar. Apply marine sealant to the bottom of the light post and then screw this to the lid and base (use screws 101PPHSMS).
-
Page 5: Optional Accessories
WEDGES SP1-MOD Compensates for plane angle. Allows user to mount GPS units or Available in 2, 4 or 6 degree wedges. antennas onto a Seaview Modular Mount. HINGES Seaview Hinge Adapters fold in any direction necessary for added height clearance. - Page 6 LTBLED12 LED Combination Masthead and All-Round White (Anchor) Light The above light is designed for use on sail or power driven vessels under 20 meters (65.6 ft.) in length operating on a nominal 12 volt system. In order to comply with ‘72 COLREGS and U.S.
-
Page 7: European Office
EUROPEAN OFFICE Tel: 800-655-7922 Tel: +33 4 94 53 27 70 www.seaviewglobal.com www.seaviewprogress.com...
